Next 976480 Assembly Instructions Manual

Barlow corner tv

Advertisement

Quick Links

IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
Tools Needed
Helpline
If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: 0844 844 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found
to be faulty. Should you need to return the unassembled product, please repack in the original packaging.
IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of 2 persons is required to assemble this product.
PRODUCT INFORMATION
• Made from particleboard,MDF with a wood effect finish.
• Made in Indonesia.
CARE INSTRUCTIONS
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent
scratching
or damage.
• Ensure the mats and coasters used do not have an abrasive surface underneath.
• Do not put hot dishes directly on the surfaces of the item.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration or
warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should always be tightened properly
and periodically check all fixings and tighten if necessary.
976480
ASSEMBLY INSTRUCTIONS.
1 of 9
BARLOW CORNER TV

Advertisement

loading
Need help?

Need help?

Do you have a question about the 976480 and is the answer not in the manual?

Questions and answers

Summary of Contents for Next 976480

  • Page 1 976480 BARLOW CORNER TV ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0844 844 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
  • Page 2 FITTINGS 15x12 mm. 7.5X32 mm. 8x32 mm. 25x30 mm. P4x15 mm. F6x13 mm. Ax20 Bx20 Cx31 300 mm. 300 mm. F6x31 mm. 7.5x53 mm. 7x19 mm. F 8x50 mm. F10X70 mm. GRx2 GLx2 PARTS 4Rx1 4Lx1 6Rx1 6Lx1 10Lx2 10Rx2 11x2 12x2 2 of 9...
  • Page 3 STEP ONE - Insert 6x cambolts (B) into the holes of panel 1.Tighten with a screwdriver. - Insert 2x camlocks (A) into the holes of panel 2 and ensure that arrow indicator is pointing towards the panel edge before tightening with a screwdriver. - Insert 2 x wooden dowels ( C ) into the end on panel 2.
  • Page 4 STEP FOUR - Insert 2x camlocks (A) into the holes of panel 7 and ensure that arrow indicator is pointing towards the panel edge. - Insert 1x wooden dowel (C) into the holes of panel 7. - Insert 2x wooden dowels (C) into the holes of panel 8. STEP FIVE - Attach panel 7 to the panel 5 and secure by tightening 1x screws (K) clockwise with a cross-blade screwdriver...
  • Page 5 STEP SEVEN - Attach the assembled unit (4L - 6L) and (4R - 6R) to the panel 2 by tightening 2 x camlocks (A) clockwise with a flat-blade screwdriver. STEP EIGHT - Attach the assembled unit (panel 5 and 7) to assembled unit by tightening 1x screw (L) clockwise with a cross- blade screwdriver.
  • Page 6 STEP TEN - Carefully lift the unit upright. This should be lifted by 2 persons. - Attach panel 1 to the assembled unit by tightening 6x camlocks (A) clockwise with cross-blade screwdriver. STEP ELEVEN - Attach panel 8 to assembled unit by tightening 4x screws (H) clockwise with a cross-blade screwdriver.
  • Page 7 STEP THIRTEEN - Insert 2 x camlock (A) into the hole of panel 10R (x2). - Turn over panel 10R and insert 2 x cambolt (B), 4 x wooden dowels ( C ). - Insert 4 x camlocks (A) and 8 x wooden dowels (C) into the holes of panel 11 (x2).
  • Page 8 - Repeat this step for the remaining a assembled drawer. STEP EIGHTEEN - Insert the drawer unit to the assembled unit. - And now, this cabinet is ready for use. Next Retail Ltd, Desford Road, Leicester, LE19 4AT 8 of 9...
  • Page 9 Note : Whilst position foil stickers to cover the holes. Ensure that you arrange them on the centre of the holes before sticking. And ensure the grain direction of foil sticker have to be in the same direction as current surface area. Next Retail Ltd, Desford Road, Leicester, LE19 4AT 9 of 9...
