Hamlet ZELIG XZR751U User Manual

ZELIG READER
75 in 1 Memory Card Reader
User Manual
XZR751U
www.hamletcom.com
Dear Customer,
thanks for choosing an Hamlet product. Please carefully
follow the instructions for its use and maintenance and,
once this item has run its life span, we kindly ask You to
dispose of it in an environmentally friendly way, by putting
it in the separate bins for electrical/electronic waste, or to
bring it back to your retailer who will collect it for free.
We inform You this product is manufactured with materials
and components in compliance with RoHS Directives
2011/65/EU & 2015/863/EU, WEEE Directive 2002/96/CE,
2003/108/CE Italian Legislative Decree 2005/151 and
EMC Directive 2014/30/EU for the following standards:
EN 55032: 2015, EN 55024: 2010 + A1: 2015.
The complete CE declaration of conformity of the product
can be obtained by contacting
info@hamletcom.com.
Visit www.hamletcom.com for complete information on all
Hamlet products and to access downloads and technical
support.
Imported by: CARECA ITALIA SPA - Scandiano (RE) . Italy.
All trademarks and company names mentioned in this
manual are used for description purpose only and remain
property of their respective owners.
The material in this document is for information only.
Contents, specifications and appearance of the product
are indicative and may change without notice.
Introduction
The new Zelig Memory Reader is a 75 in 1 memory card
reader that reads and save data from Compact Flash
Type I/II, Micro Drive, Secure Digital, Multi Media Card,
Smart Media, Memory Stick, Memory Stick Pro and XD.
Its small dimensions make this product ideal also to be
carried. Thanks to the USB hot plug, connecting to your
computer is easy and no adapter is needed.
With the aid of card adapter it can read Mini-SD, Micro
SD, MMC mobile, MMC Micro, RS MMC and T-Flash.
System Requirements
• One available USB port
• Windows 7/8 and 10, Mac OS 10.4 or later,
Linux (kernel 2.4.0 or later)
Features
• High Speed USB 2.0 interface up to 480 Mbps
• USB 1.1 backward compatible
Hamlet at • USB bus powered
• Plug&Play, supports Hot-Swapping
• LED indicators for power and activity
Installation
Connect the card reader to the PC thought the USB cable;
Zelig Reader will be automatically recognized from the
system and the icon of the supported memory will be
visualized in "Windows Explorer" and on the "Desktop"
(Mac OS - when you insert a memory card in the reader).
NB: Support one slot at the time only.
