- Page 1 User’ s Guide D845GVSR Motherboard C C O O N N T T E E N N T T S S Chapter 1 Chapter 2 Chapter 3 Appendix A Specifications Motherboard Description Using the BIOS Setup Program Installing Board Options...
-
Page 3: Safety Information
Safety Information Battery Warning Instruction Caution Attention Vorsicht Fuse Warning Instruction Caution Vorsicht Attention Atencion... -
Page 4: Before You Read
Before You Read NOTE... - Page 5 Chapter 1 Motherboard Description Chapter 2 Using the BIOS Setup Program CONTENTS...
- Page 6 Chapter 3 Installing Board Options Appendix A Specifications Motherboard Description...
-
Page 7: Motherboard Description
Motherboard Description Motherboard Description Motherboard Description... - Page 8 NOTE Motherboard Description...
-
Page 9: Motherboard Overview
Motherboard Overview Rear chassis fan connector Auxiliary 12V power supply connector Back panel I/O connectors CD audio connector Video audio connector Front panel audio connector Realtek ALC202A audio codec Intel 82562ET 10/100 Mbps (PLC) device NOTE mPGA478 socket Intel 82845GV Graphics Memory Controller Hub(GMCH) CPU fan connector PCI slots... -
Page 10: Rear Panel Connectors
Rear Panel Connectors Parallel port connector USB connectors PS/2 mouse connector PS/2 keyboard connector Serial port (COM1) connector Motherboard Description Video connector LAN connector Line-in jack Line-out jack Microphone jack USB connectors... -
Page 11: Using The Bios Setup Program
Using the BIOS Setup Program Using the BIOS Setup Program About the Setup Program Using the BIOS Setup Program... -
Page 12: Entering The Setup Program
Entering the Setup Program NOTE NOTE Setup Menu Screen Description Main Allocates resources for hardware components. Advanced Specifies advanced features available through the chipset. Security Specifies passwords and security features. Power Specifies power management features. Boot Specifies boot options and power supply controls. Exit Saves or discards changes to the Setup program options. -
Page 13: Help Window
Setup Key Description <F1> or <Alt-H> Brings up a help screen for the current item. <Esc> Exits the menu. < > or < > Selects a different menu screen. < > or < > Moves cursor up or down. <Home> or <End> Moves cursor to top or bottom of current menu. -
Page 14: Bios Setup Program
BIOS Setup Program Main Menu Feature Options BIOS Revision No options Processor Type No options Processor Speed No options System Bus Speed No options System Memory No options Speed Cache RAM No options Total Memory No options Memory Bank 0 No options Memory Bank 1 No options... -
Page 15: Advanced Menu
Advanced Menu Feature Options Boot Configuration No options Peripheral Configuration No options IDE Configuration No options Diskette Configuration No options Video Configuration No options USB Configuration No options Boot Configuration Submenu Feature Options Plug & Play O/S • No • Yes Description Configures Plug and Play. -
Page 16: Peripheral Configuration Submenu
Peripheral Configuration Submenu Feature Options Serial Port A • Disabled • Enabled • Auto Parallel Port • Disabled • Enabled • Auto Mode • Output only • Bi-directional • EPP • ECP Audio Device • Disabled • Enabled LAN Device •... -
Page 17: Diskette Configuration Submenu
Primary/Secondary IDE Master/Slave Submenus Feature Options Drive Installed No options Type • Auto • User Maximum Capacity No options LBA/Mode • Disabled • Auto Block Mode • Disabled • Auto PIO Mode • Auto • 0/1/2/3/4 DMA Mode • Auto •... -
Page 18: Video Configuration Submenu
Video Configuration Submenu Feature Options AGP Aperture Size • 4MB • 8MB • 16MB • 32MB • 64MB • 128MB • 256MB Primary Video • Integrated Adapter • PCI Frame Buffer Size • 512MB • 1MB • 8MB USB Configuration Submenu Feature Options High Speed USB... -
Page 19: Deleting Or Changing A Password
Password set Supervisor mode Neither Can change all options Supervisor Can change only all options Both Can change all options NOTE Deleting or Changing a Password Changes have been saved. User mode Password during boot Can change all options None Supervisor Can change a limited Supervisor or User... -
Page 20: Power Menu
Power Menu Feature Options ACPI No options ACPI Submenu Feature Options ACPI Suspend • S1 State State • S3 State Wake on LAN • Stay Off from S5 • Power On Boot Menu Feature Options Boot from Network • Disabled •... -
Page 21: Boot Device Priority Submenu
Boot Device Priority Submenu Hard Disk Drives Submenu Feature Options 1st Drive Dependent on installed hard drives Removable Devices Submenu Feature Options 1st Drive Dependent on installed removable devices Description Specifies the boot sequence from the available hard disk drives. To specify boot sequence: 1. -
Page 22: Exit Menu
ATAPI CD-ROM Drives Submenu Feature Options 1st Drive Dependent on installed ATAPI CD-ROM drives NOTE Exit Menu Feature Exit Saving Changes Exit Discarding Changes Load Setup Defaults Discard Changes 2-12 Using the BIOS Setup Program Description Specifies the boot sequence from the available ATAPI CD-ROM drives. To specify boot sequence: 1. -
Page 23: Installing Board Options
Installing Board Options Installing Board Options Before You Begin WARNINGS CAUTION Installing Board Options... -
Page 24: Installing And Removing The Processor
Installing and Removing the Processor Installing the Processor NOTE WARNING Installing Board Options ZIF handle Triangle mark Blank corner... - Page 25 NOTE NOTE Installing Board Options...
-
Page 26: Removing The Processor
Removing the Processor CPU fan connector NOTE Installing Board Options... -
Page 27: Installing And Removing Memory Modules
Installing and Removing Memory Modules DIMM Size Non-ECC Configuration 64MB 8 Mbit × 64 16 Mbit × 64 128MB 256MB 32 Mbit × 64 512MB 64 Mbit × 64 128 Mbit × 64 1 GB ZIF handle Installing Board Options... -
Page 28: Installing A Memory Module
Installing a Memory Module Notch Crossbar Retaining clips Removing a Memory Module Installing Board Options... -
Page 29: Changing The Jumper
Changing the Jumper Function/Mode Jumper Setting Normal Configure Recovery None CAUTION The BIOS uses current configuration information and passwords for booting. After the POST runs, Setup runs automatically. The maintenance menu is diplayed. The BIOS attempts to recover the BIOS configuration. A recovery diskette is required. -
Page 30: Replacing The Battery
Replacing the Battery Battery Battery socket Installing Board Options... -
Page 31: The Things To Do In Post-Installation
The Things to do in Post-installation Installing Board Options... - Page 32 3-10 Installing Board Options...
-
Page 33: Specifications
Specifications Specifications Feature Form Factor Processor Memory Main Chipset I/O Controller Specifications Micro ATX • Intel ® Pentium ® 4 processor • 533 MHz and 400 MHz system bus with an integrated 256K L2 cache NOTE • Two 184-pin 2.5 V DIMM sockets •... - Page 34 Feature Built-in Audio Controller Built-in LAN Controller Expansion Slots Other Features Power Supply Environmental Requirement Specifications Specifications Integrated Audio Controller in Intel ® • AC '97 2.2 Compliant • AC '97 Link for Audio CODEC • Separate Independent PCI Function for Audio Realtek ALC202A Audio Codec ‘97 •...
