Type C 2SP remote
controller
REF 819756/819757
The type C 2-speed remote controller is a safety device for controlling air flow regulation
at low and high speed depending on the position of the sash.
A speed sensor is used to determine the flow rate. Audible and visual alarm is set off in
case of insufficient speed or too high sash height and other malfunctions. The controller
engages the second gear by means of a contactor placed in the path of the sash.
The remote HMI is used to control the fume cupboard ventilation and to carry out the
following adjustments on site.
This controller complies with EN 14175 and RoHS Standards.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Seat C 2SP
Summary of Contents for Seat C 2SP
- Page 1 Type C 2SP remote controller REF 819756/819757 The type C 2-speed remote controller is a safety device for controlling air flow regulation at low and high speed depending on the position of the sash. A speed sensor is used to determine the flow rate. Audible and visual alarm is set off in case of insufficient speed or too high sash height and other malfunctions.
-
Page 2: Table Of Contents
Table of contents Presentation ............................ 3 1.1. HMI (Human Machine Interface) ....................3 1.2. CPU (Central Processing Unit) ..................... 3 1.3. Schematic diagram ........................4 1.4. Connector specifications ......................5 Installation and mounting ....................... 6 2.1. Dimensions ..........................6 2.2. Positioning on the fume hood ..................... -
Page 3: Presentation
1. Presentation The remote type C 2SP remote controller consists of a small HMI, easily installed on a fume hood, and a central processor. 1.1. HMI (Human Machine Interface) Display (Option) Yellow LED: Ventilation ON/OFF Push button: ON/OFF ventilation Green LED: air flow OK... -
Page 4: Schematic Diagram
1.3. Schematic diagram 220v power supply Velocity probe Switch sash position Deported HMI Second CPU box velocity switch The remote type C 2-speed controller is used to control the airflow of a fume hood. Pressing the ventilation ON/OFF button on the remote HMI closes the two relays VENT 1 and 2, which unlocks the drive. -
Page 5: Connector Specifications
1.4. Connector specifications Power supply Electrical transformer 230v/12v 500mA. (delivered with) VENT1/FAN1 ON/OFF Ventilation relay driving by Disconnection voltage: 120v Disconnection current: 0.5 A VENT2/FAN2 Same VENT1 0/10v 0/10v output which returns a voltage according to the speed measured by the sensor. This output must be sent to the frequency inverter. -
Page 6: Installation And Mounting
2. Installation and mounting 2.1. Dimensions 65 mm 28 mm 40 mm 22 mm Speed sensor... -
Page 7: Positioning On The Fume Hood
2.2. Positioning on the fume hood The controller is delivered with You can install the CPU in the false ceiling of a 2,5 meters cable. the fume cupboard. ◌ Vertical HMI are usually attached to the side frame of fume hoods. Horizontal HMI’s can be set at the user’s convenience. -
Page 8: Cutting Template
2.3. Cutting template If you want to install your fume hood controller without the surface bow mounting, you will need to make the following cuts: 31mm 110mm... -
Page 9: Installation Tips
2.4. Installation tips • Do not install the sensor on the extraction tube above the fume hood • Avoid installing the sensor in a dead zone of the fume cupboard • The probe must pass entirely through the fume cupboard ceiling. Otherwise, you must use a 25mm PVC tube to extend the outlet. -
Page 10: Wiring Diagram
3. Wiring diagram 220v power supply ON/OFF ventilation 0/10V 220v power Switch sash supply position Second velocity Switch sash position speed switch switch... -
Page 11: Adjustment Procedure
4. Adjustment procedure This controller requires a 0/10v setpoint setting for low and high speed and a display setting in case you have the display option. Low speed adjustment Sash Switch on ventilation with closed Put the sash in down position. Wait 15 seconds for the speed to stabilize Enter the setting mode: Press and hold for at least 3 seconds on release and then... - Page 12 High speed adjustment Guillotine ouverte Put the sash in the upper position (400 or 500 mm) The second speed switch is then sets off. Wait 15 seconds for the speed to stabilize. Enter the setting mode again: Press and hold for at least 3 seconds on release and press simultaneously on shortly.
-
Page 13: Factory Rest
IF DIGITAL DISPLAY MODEL Press the push-button on the rear face to synchronize the speed reading on the anemometer and the speed displayed on the controller. One push increases by 0.1 m/s over a range of 0.3 à 0.7 m/s Once the setting has been made, a long press on allows to both enter and exit the adjustment mode. -
Page 14: Change The Audible Alarm Delay
7. Change the audible alarm delay It is possible on the rear face to change the buzzer’s trigger time with the two switches. 1 = ON: Alarm still active 1 = OFF: Alarm disabled if ventilation is off 2 = ON: Delay set as 30s 2 = OFF: Delay set as 15s 8. -
Page 15: Maintenance
Have an anemometer 11. Warranty SEAT Ventilation guarantees that its equipment, products and parts are free from manufacturing defects under normal conditions of use for a period of two years after delivery to the first user. If a factory return is required within the two-year period from the date of purchase, contact your distributor. - Page 16 SEAT VENTILATION SAS PARC TECHNOLOGIQUE DELTA SUD 09340 VERNIOLLE France E-mail: info@seat-ventilation.com Site Web: www.seat-ventilation.com...
