KLIQ METROTUNER+ Quick Start Manual page 2

HOW TO USE THE METRONOME
METRONOME
Tempo Range: 40-208 BPM
Beats: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9
Rhythm:
Metronome "bell" sound adjustment
Tap Function
Earphone: 3.5mm jack, stereo
Volume Control
1. Move Mode Switch to METRO/TUNER mode.
2. Press and hold the button to switch between
the Metronome and Tuner Function.
(Make sure the metronome function is on.)
3. Press the button to select tempo (from
or
40PBM to 208BPM) or press the TAP button to
manually input your own tempo (the unit will take
an average of the inputs and calculate the BPM).
4. Press the button to select beat. (from 0-9).
5. Press the button to select the rhythm.
Rhythm options:
6. Press the button to start the METRONOME.
(The screen indicators will now move to the beat
and LED indicators will flash to tempo and beat
settings. (Press the again to stop metronome.)
7. Once the METRONOME is functioning, press the
button to change the sound of the "bell." Press
again to cycle through the various "bell" options.
8. Use the volume control switch to adjust the
metronome volume.
9. Optional: Use a 3.5mm gauge headphone to
connect to the metronome. (If headphone jack is
connected, the speaker will be muted.)
Note: if the power switch is turned to the OFF position, all
settings will revert to factory presets
HOW TO USE THE TUNER
TUNER
Tuning mode: Chromatic
Tuning range: A0 (27.5Hz)-C8 (4186.00Hz)
Tuning method: built-in microphone pick-up
Reference pitch: 430Hz-450Hz
Tuning tolerance: +/- 0.5cent
Tuning indication screen meters LED indicators
Tuning Cent indicator
1. Move Mode Switch to METRO/TUNER mode.
2. Press and hold the button to switch between
the Metronome and Tuner Function.
(Make sure the tuner function is on.)
3. Press the button to select the reference pitch
or
(440Hz -standard, range from 430Hz-450Hz)
4. Place the tuner as close to the instrument as
possible to make sure the built-in microphone picks
up the instrument sound. (Ambient noise may
affect tuning accuracy)
5. Tuning process:
• IN TUNE: Note name appears, green LED on the
screen lights up, cent indicator shows +/- 3
cents or less
• FLAT: Red tuning indicators stay left, red LED on
the unit lights up, cent indicator shows in the
negative range
• SHARP: Yellow tuning indicators stay right, red
LED on the unit lights up, cent indicator shows
in the positive range
Note: if the power switch is turned to the OFF position, all
settings will revert to factory presets
HOW TO USE THE CLOCK
CLOCK
12 hours standard, AM/PM
Alarm function
1. Move Mode Switch to CLOCK position.
2. For the first use it is necessary to set the clock. Setting the
alarm is optional.
TIME:
•
Press and hold the TAP button for 2 seconds to enter
the time setting mode. The minutes will begin to
flash. Press the button to set the correct
or
number of minutes.
•
Press the TAP button to set hour digit. When hour
digit flashes, press the button to set the right
or
hour. AM/PM will change as the hours are cycled
through.
• If no input is received, after 5 seconds the clock will
revert to standard mode.
ALARM:
•
Press and hold the button to set alarm. The
screen will show a red alarm clock symbol,
• Press and hold the button for 2 seconds to enter
the alarm setting mode. Once minute digits flash,
press the button to set the minutes.
or
• Press TAP button, once the hour digits will flash, press
the button, to set the hour. AM/PM will
or
change as the hours are cycled through.
•
All the settings will now be saved automatically.
• When the alarm sounds, press the
the alarm. Otherwise, the alarm will sound for 5
minute and then turn itself off.
Note: if the power switch is turned to the OFF position, all
settings will revert to factory presets
.
button to stop
