The Illusion
Gas Log Fire
with
®
PYROGLOW
OWNERS INSTRUCTION & INSTALLATION MANUAL. PLEASE KEEP FOR FUTURE REFERENCE
PYROGLOW® Gas Logs: ADVANTAGES- Realistic surface textures & colours. Radiant
natural glow of an actual fire when burning. Natural looking logs when idle. Superior strength
versus ceramic fibre.
virtually no fume emission. Thermal shock resistant. Contains no asbestos.
THESE APPLIANCES HAVE BEEN TESTED IN ACCORDANCE WITH AG 103 FOR
INSTALLATION AND OPERATION AS DESCRIBED IN THIS MANUAL AND HAVE BEEN
All Illusion Gas Log Appliances MUST be installed and serviced by an authorised installer or technician.
Unauthorised installation, service or maintenance may cause a hazardous situation.
FREESTANDING MANUAL JAN- 2014
ESPRIT MODELS 63-70
Inert refractory formulation is ceramic fibre free. Pyroglow® logs create
CERTIFIED BY THE AUSTRALIAN GAS ASSOCIATION.
Illusion Australia Pty. Ltd.
HEAD OFFICE
145 STH GIPPSLAND HWY
DANDENONG STH.
VICTORIA AUSTRALIA 3175
PH: (613) 9793 7520
Email service@Illusionfires.com.au
www.Illusionfires.com.au
WARNING:
Advertisement
Table of Contents
Related Manuals for Illusion Esprit EGL63NG
Summary of Contents for Illusion Esprit EGL63NG
- Page 1 INSTALLATION AND OPERATION AS DESCRIBED IN THIS MANUAL AND HAVE BEEN CERTIFIED BY THE AUSTRALIAN GAS ASSOCIATION. WARNING: All Illusion Gas Log Appliances MUST be installed and serviced by an authorised installer or technician. Unauthorised installation, service or maintenance may cause a hazardous situation. FREESTANDING MANUAL JAN- 2014...
-
Page 2: Table Of Contents
The Illusion Esprit Gas Log Fire provides you with continuous warmth, and the traditional charm of a wood fired heater, without the hard work generally associated with a wood fuelled appliance. Safe and economical, you can rest easy knowing the Illusion Esprit Gas Log Fire has been fully tested and approved AUSTRALIAN STANDARD AG 103. - Page 3 Va l u e & Q u a l i t y I n G a s L o g F i r e s EGL63NG, EGL63LP DIMENSIONS 478mm 670mm 451mm 549mm 36mm 50mm 478mm GAS INLET RHS REAR FREESTANDING MANUAL JAN- 2014...
- Page 4 Va l u e & Q u a l i t y I n G a s L o g F i r e s EGL70NG, EGL70LP DIMENSIONS 478mm 770mm 451mm 549mm 36mm 50mm 478mm GAS INLET RHS REAR FREESTANDING MANUAL 2014...
- Page 5 (for example, the flame failure device, limit thermostat and the like) must cut off the power supply to the thermoelectric circuit of the gas valve. Caution: After making the connections, check gas tightness. LABELLING Illusion GAS LOG FIRES - MODELS EGL63NG, EGL70NG, EGL63LP AND EGL70LP Model EGL70LP EGL63NG...
-
Page 6: Lighting Instructions
NEVER ATTEMPT TO LIGHT THE APPLIANCE IF YOU CAN SMELL GAS. IF IN DOUBT, CONTACT YOUR GAS SUPPLIER, APPLIANCE INSTALLER AND OR Illusion SERVICE DEPARTMENT FROM A NEIGHBOURS HOME. IF YOU CAN SMELL GAS, DO NOT USE MOBILE PHONES OR ANY ELECTRICAL APPLIANCE, OR ELECTRIC SWITCH IN THE BUILDING. - Page 7 Your Illusion sales representative can advise on the best position to maximize the performance of the appliance. In most cases, an Authorised Illusion Installer can be arranged to install the unit, however if this is not possible, a suitably qualified gas fitter must be used. These appliances are not designed to be installed by the homeowner.
-
Page 8: Installation Instructions
Va l u e & Q u a l i t y I n G a s L o g F i r e s INSTALLATION INSTRUCTIONS NOTE THAT THIS GAS APPLIANCE MAY ONLY BE INSTALLED BY AN AUTHORISED GAS FITTER. CONTACT YOUR DEALER TO ARRANGE INSTALLATION. INSTALLATION PROCEDURE INSTALLERS CHECKLIST IMPORTANT: BEFORE COMMENCING THE INSTALLATION, ESTABLISH THE OPTIMAL POSITION... -
Page 9: Installation Clearances
Va l u e & Q u a l i t y I n G a s L o g F i r e s INSTALLATION CLEARANCES IMPORTANT: All distances shown are MINIMUM. Illusion Gas Log appliances EGL63NG ,EGL63LP, EGL70NG and EGL70LP must only be installed with the minimum distances shown below. -
Page 10: Installation Examples
Va l u e & Q u a l i t y I n G a s L o g F i r e s INSTALLATION EXAMPLES PLEASE NOTE: ALL ILLUSION GAS HEATERS MUST BE INSTALLED BY A QUALIFIED GASFITTER... -
Page 11: Fitting The Logs & Coals Egl63 (Continued)
Va l u e & Q u a l i t y I n G a s L o g F i r e s FITTING THE LOG SET - MODELS EGL63NG, EGL63LP, EGL62NG, EGL62LP FITTING THE LOGS & COALS NOTE THAT THE COALS MUST BE PLACED ONTO THE MESH SUPPORT DURING INSTALLATION OF THE LOGS AND ARRANGED SO THAT BURNER HOLES ARE NOT BLOCKED. - Page 12 Va l u e & Q u a l i t y I n G a s L o g F i r e s FITTING THE LOG SET - MODELS EGL63NG, EGL63LP, EGL62NG, EGL62LP INSTALLATION SEQUENCE = 1-2-3-4-5-6 ADD COALS AS THE LOGS ARE NUMBERED ON THE LOGS ARE FITTED UNDERSIDE...
- Page 13 Va l u e & Q u a l i t y I n G a s L o g F i r e s FITTING THE LOG SET - MODELS UGL70NG, UGL70LP, UGL69NG, UGL69LP FITTING THE LOGS & COALS NOTE THAT THE COALS MUST BE PLACED ONTO THE MESH SUPPORT DURING INSTALLATION OF THE LOGS AND ARRANGED SO THAT BURNER HOLES ARE NOT BLOCKED.
- Page 14 Va l u e & Q u a l i t y I n G a s L o g F i r e s FITTING THE LOG SET - MODELS EGL70NG, EGL70LP, EGL69NG, EGL69LP INSTALLATION SEQUENCE = A-E-F-B-D-G-C ADD COALS AS THE LOGS ARE FITTED LOGS ARE NUMBERED ON THE UNDERSIDE...
-
Page 15: Pressure Testing
Va l u e & Q u a l i t y I n G a s L o g F i r e s PRESSURE TESTING IMPORTANT: IF THE APPLIANCE CANNOT BE ADJUSTED TO OPERATE CORRECTLY, CONTACT YOUR SUPPLIER AND DO NOT OPERATE THE APPLIANCE UNTIL THE PROBLEM IS RECTIFIED. PRESSURE TESTING: ENSURE THE HEATER IS ISOLATED FROM THE GAS SUPPLY BY CLOSING THE MANUAL SHUTOFF VALVE DURING ANY PRESSURE TESTING. -
Page 16: Installation Flue Spillage Test
Va l u e & Q u a l i t y I n G a s L o g F i r e s INSTALLATION FLUE SPILLAGE TEST IF THE FLUE IS BLOCKED OR NOT PRODUCING SUFFICIENT DRAW, THE HEATER MUST NOT BE USED UNTIL THE PROBLEM IS RECTIFIED. -
Page 17: Maintenance
Replacing Logs The unit should never be used with broken logs. Always turn the gas valve off. And allow the unit to cool before opening door. Remove logs carefully.Logs should only be replaced by an Authorised Illusion representative. Note: Improper positioning of logs may create soot build up and carbon monoxide, which will affect performance. - Page 18 Va l u e & Q u a l i t y I n G a s L o g F i r e s DOOR REMOVAL PROCEDURE REMOVE TOP PANEL OF HEATER AS SHOWN ABOVE SWING BOTH LEFT AND RIGHT HAND SIDE PANELS OPEN. WHILST PRESSING THE DOOR FORWARD, PULL FOUR TOGGLE CLAMP LEVERS TOWARDS THE FRONT OF HEATER AND UNCLIP AS SHOWN REMOVE THE HEATER DOOR (HEATER SHOWN IS FOR ILLUSTRATIVE PURPOSES ONLY)
-
Page 19: Parts Assembly Exploded View
Va l u e & Q u a l i t y I n G a s L o g F i r e s PARTS ASSEMBLY EXPLODED VIEW DOOR ASSEMBLY Spare Parts TOP PANEL TOP MOUNTING PANEL Spare parts are available from FIREBOX your supplier. -
Page 20: Thermostatically Controlled Fan
Va l u e & Q u a l i t y I n G a s L o g F i r e s THERMOSTATICALLY CONTROLLED FAN Your new Illusion Gas Space Heater is fitted with a THERMOSTATICALLY CONTROLLED fan. EXPLANATION What this means is that other than initially setting the fan to the desired position,ie: Low High or Boost, it will no longer be necessary to turn the fan on or off whilst the unit is operating. - Page 21 Va l u e & Q u a l i t y I n G a s L o g F i r e s ILLUSION ESPRIT REMOTE CONTROL UNIT INSTRUCTIONS OPTIONAL RADIO FREQUENCY PROGRAMMABLE REMOTE CONTROL Illusions OPTIONAL thermostatically controlled remote controller can be operated from anywhere in the house and does not require line of sight.
-
Page 22: Abnormal Operation
Va l u e & Q u a l i t y I n G a s L o g F i r e s ABNORMAL OPERATION THE FOLLOWING INDICATES SITUATIONS OF ABNORMAL OPERATION OF THE APPLIANCE. WHEN THE HEATER IS OPERATING : 1. -
Page 23: Troubleshooting
Va l u e & Q u a l i t y I n G a s L o g F i r e s TROUBLESHOOTING •The pilot flame goes out. SYMPTOM. •First check that the gas is on, usually with another appliance such as a POSSIBLE CAUSE. - Page 24 Va l u e & Q u a l i t y I n G a s L o g F i r e s Illusion Gas Log Fires State Dealer Contact List Head Office 145 Sth. Gippsland Hwy.. Dandenong Victoria Australia 3175 Phone.
- Page 25 Email: service@Illusionfires.com.au WEB: www.Illusionfires.com.au Illusion Australia Pty. Ltd. reserves the right to alter specifications contained in this publication without notice. Illusion Australia Pty. Ltd. admits no responsibility for printing errors or omissions within this publication. Copyright Illusion Australia Pty. Ltd. 2014...
