Califone PresentationPro PA150 Specifications

Califone battery-powered wireles speaker specifications

Advertisement

Quick Links

Ideal for mobile presenters, classroom and athletic uses
Lightweight with built-in handle for easy mobility
16-channel UHF selectability for wireless mic
Green, red and amber LEDs on front give visual
confirmation of power, signal and reception
Rechargeable 12V sealed lead-acid battery
Separate bass, treble controls for quality sound
Aux in and line inputs connect with LCD projectors,
multimedia players, computers and whiteboards
CE/C-UL approved safe for school, church, government uses
Available wireless handheld (Q316), hands-free (M316
transmitter) and wired microphones
Includes volume / mute remote control (not shown)
The battery-powered Wireless
PresentationPro is an AC/DC powered,
wireless PA system. With 16 selectable
UHF channels and an internal battery, it
can be used as a single, portable setup
for presentations, emergency response
situations, police needs, in meetings and
for use by rental facilities.
"Project Intercept"
Please contact us immediately if you experience any difficulties
with your PA150. Our "Project Intercept" customer service
program will quickly repair or replace items under warranty.
Simply contact us via phone or email warranty@califone.com
Visit our website at www.califone.com to learn more about the
complete line of Califone
audio enhancing and visual techno-
®
logy products including: Wired and Wireless public address
systems and lecterns, wireless microphones, headphones &
headsets, group listening centers, multimedia players and
computer peripheral products.
We are proud of helping teachers enhance student
understanding and achievements since 1947, with your
satisfaction as our first priority.
The PresentationPro carries a limited six-year warranty and
service support available through authorized dealers nation-
wide. Its warranty covers school use - unlike some other PA
products whose warranties would be voided if used in schools.
Distributed by:
Battery-Powered Wireless
PresentationPro
Model PA150

Specifications

Rated Power Output:
Sensitivity for Rated Output:
Frequency Response:
Dispersion Angle:
Speakers:
Crossover:
Inputs:
Line Output:
AC Power Requirements:
Dimensions (HWD):
UHF Receiver Specifications
Channels:
Frequency:
Oscillation:
Modulation:
Sensitivity:
Frequency Response:
Wireless Transmission Range:
Dynamic Range:
Battery
Weight:
Safety Approvals:
Warranty
Califone
15 watts RMS
Line:125 mVrms
Microphone: 4 mVrms
Auxiliary:
250 mVrms
60 Hz – 20 kHz ± 3dB
90º H x 120º V
Woofer:
5-1/4" High efficiency
Tweeter:
13mm mylar dome
L/C – 6dB/Octave @ 4 kHz
Line inputs (2):Hi-Z, RCA (summing L+R)
Balanced mic: Hi or lo-Z,
with phantom power (+15 volts D.C.)
Unbalanced mic: Lo –Z, 1/4"-phone
Auxiliary:
Hi-Z Mono 1/4"-phone
250mv constant
110 – 125 VAC, 50/60 Hz
6-1/4" x 10" x 8-1/2"
16 Selectable
740 - 801.80mHz
Phase Lock Loop, Synthesized
FM (Frequency Modulation)
7 microvolts
90 Hz - 17 KHz
Approximately 160 ft.
100 dB
12V sealed lead-acid, rechargeable
4 hour run time, 6 hour recharge cycle
10 pounds, shipping weight 14 lbs.
C-UL/CE approved safe for use in
school, business, government and
church facilities
6 years from date of purchase (PA
only, all other parts one year)
International Inc. 800-722-0500
®
www.califone.com
PA150, June 2006
