- Page 1 BRENTWOOD Base II OWNER’S MANUAL Installation & Operation Serial No.
-
Page 3: Table Of Contents
CONTENTS Safety & Warranty Warnings Parts List Electronics Quick Reference Guide Installa on Guide Remote Control Instruc ons Se ng Programmable Posi ons and Pairing Remote Se ng Preset posi ons Emergency Ba ery Backup Synchronizing Two Bases To Operate The Beds Separately Again Bluetooth Intruc ons Troubleshoo ng... -
Page 4: Safety & Warranty Warnings
Safety & Warranty Warnings : READ THE FOLLOWING INFORMATION CAREFULLY BEFORE USING THIS PRODUCT If unable to understand warnings, cau ons, and/or instruc ons, contact the dealer or technical personnel if applicable, before a emp ng to use the equipment. Otherwise, injury or damage may result. SAFETY WARNINGS: •... - Page 5 WARRANTY WARNING! Do not open or tamper with control box, motors, or remote (with the excep on of ba ery compartments). The warranty will be void if the internal workings of these components are tampered with. Product Ra ng: The motors are not designed to operate con nuously for more than [2] minutes in an [18] minute me period or approximately 10% duty cycle.
- Page 6 RADIO FREQUENCY:2.4 GHz FCC COMPLIANCE: This device complies with Part 15 of the FCC Rules. Opera on is subject to the following two condi ons: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired opera on. To comply with the FCC RF exposure requirements, no change to the antenna or the device is permi ed.
-
Page 7: Parts List
Parts List All electronics and components that need to be installed are located in boxes under the founda on or a ached to the frame. Before discarding the packing materials, ensure that all the parts are accounted for. AAA Ba eries (3) Power Supply (1) Adjustable Legs (6) Retainer Bar (2) -
Page 8: Electronics Quick Reference Guide
Electronics Quick Reference Guide Head Motor Control Box Foot Massage Motor USB Ports Head Massage Motor LED Light Foot Motor... - Page 9 Control Box Pairing Bu on Power Supply Power Cord Head Motor LED Light Foot Motor USB Ports Remote Head Massage Motor Foot Massage Motor...
-
Page 10: Installa On Guide
Installation Guide STEP 5 Note: For safety reasons, lifting of the adjustable bed frame must be performed by two (2) people; and the NOTE: To avoid damage to the foundation, position. Take the clip out from the control box which is used to lock the plugs. STEP 1 STEP 3 Plug the Foot motor cable into the... - Page 11 Attaching the bed legs Installing the retainer bar Remove the six (6) bed legs from the accessory box. Hand tighten the legs by threading them clockwise into the pre-threaded holes on the bed frame. STEP 1 Turn the bed frame over carefully, top side up. STEP 2 Insert the ends of the retainer bar into the quick connect brackets located at the foot of the bed.
-
Page 12: Remote Control Instruc Ons
Remote Control Instructions An Snore Preset Posi on Zero-G Preset Posi on Memory Posi ons Li s Head & Foot Lowers Head & Foot Li s and Lowers Head Li s and Lowers Foot Under Bed LED ON/OFF Flat Bu on Head Massage On (3 intensi es) Foot Massage on (3 intensi es) Massage Modes Select (3 modes) - Page 13 ADJUST ONE TOUCH BUTTONS MASSAGE FEATURE An Snore Preset Posi on Head Massage On (3 intensi es) Li s and Lowers Head Zero-G Preset Posi on Foot Massage on (3 intensi es) Flat Bu on Massage Modes Select (3 modes) Li s and Lowers Foot The bu on will select a 10, 20 or 30 minute se ng.
-
Page 14: Se Ng Programmable Posi Ons And Pairing Remote
Setting Programmable Positions and Pairing Remote SETTING PROGRAMMABLE POSITIONS The adjustable base has a programmable feature that allows you to save custom posi ons. Please read all the instruc ons below before se ng your custom presets on the remote. STEP 1 Adjust the head and foot to your desired posi on. - Page 15 PAIRING REMOTE The original remote that comes in the box is already paired to the base. No further ac on is required. In the event that the remote is not paired with the base, follow the steps below. STEP 1 Make sure the ba eries work ne.
-
Page 16: Se Ng Preset Posi Ons
Setting Preset positions SETTING PRESET POSITIONS The adjustable base has a programmable feature that allows you to modify preset posi ons. Please read all the instruc ons below before se ng your preset posi ons on the remote. STEP 1 Adjust the head and foot to your desired posi on. -
Page 17: Emergency Ba Ery Backup
Emergency Battery Backup Overview Important: The backup ba ery is only to be used in case of a power outage. Ba eries are not to be used for normal opera on of the base. The backup ba ery will not support repeated movement for an extended period of me. Backup Ba ery Use: Use two 9V ba eries only (not included). - Page 18 -15-...
-
Page 19: Synchronizing Two Bases
Synchronizing Two Bases (for Twin XL and Split sizes only) Step 2: 1. Make sure Remote A was already paired to Base A and Remote B was paired to Base B. If not, please pair them by following the pairing remote instruc ons on page 12. Step 1: 2. - Page 20 Two remotes control two bases simultaneously. For example: 1. If you want to use Remote A to control two bases, slide the On Remote B, press and hold Head Down and Foot side bu on to "O" posi on on Remote A. Up at the same me, within 5 seconds, the Remote 2.
-
Page 21: To Operate The Beds Separately Again
TO OPERATE THE BEDS SEPARATELY AGAIN Step 1: On Remote A, press and hold the Head Down and Foot Up bu ons simultaneously un l the backlit LED lights blink. The Remote A now only controls Base A and the sync toggle no longer func ons. Step 2: Next, on Remote B, press and hold the Head Down and Foot Up bu ons simultaneously un l the backlit LED lights blink. -
Page 22: Bluetooth Intruc Ons
Brentwood Base Op on 1) 1. Go to APP Store (IOS SYSTEM)/ Google Store (ANDROID SYSTEM) 2. Type “Brentwood Base” into search eld and select APP, press “install” to install APP onto cell phone as shown below Op on 2) Scan this QR code to APP stores for download。... - Page 23 Step 4: Control device via Brentwood Base APP. Step 5: Open control center and select desired op ons. 1) Open Brentwood Base APP that was previously installed on cell phone as shown in picture below. 2) Refresh list and select your device as shown in picture below.
-
Page 24: Troubleshoo Ng
Troubleshooting In the event that the base fails to operate, assess the symptoms and possible solu ons provided in the chart below. SYMPTOMS SOLUTIONS Verify that the power cord is plugged into a working, grounded electrical outlet. Test the Remote control illuminates and appears to be outlet by plugging in another working appliance. - Page 25 Troubleshooting SYMPTOMS SOLUTIONS Check ba eries in wireless remote control, replace with two (2) new AAA ba eries if necessary. Make sure that you are following the duty cycle of the motors (do not operate more than two minutes over a 18-minute period, or approximately 10% duty cycle). Head &...
- Page 26 Troubleshooting SYMPTOMS SOLUTIONS A clicking noise is heard under the base when This is normal. The li motor relays “click” when they are engaged. No ac on is required. raising or lowering. If the vibra on motor overheats, the thermal protec on will turn the motor o . Wait 30 Massage motor overheats or stops.
