- Page 1 Swimming Pool Heat Pump INSTALLATION AND USER MANUAL Model: PH20V ~ PHC75Vs...
- Page 2 Thank you for choosing our product and trusting our company. This manual is to provide you with necessary information for optimal use and maintenance, please read it carefully and keep it for subsequent use.
-
Page 3: Table Of Contents
Content I． Introduction Safety precaution··············································································1 Important features of this product····················································1 Parameters of product range·····························································3 II． Installation guide Transporting your unit·····································································6 Determining optimum installation position········································· 6 Water pipe connection······································································9 Electric connection··········································································10 Trial after first installation·······························································12 III． Operation guide LED controller ···········································································13 Permanent display···········································································14 Common Setting··············································································14 Automatic on/off··············································································15... -
Page 4: Safety Precaution
Ⅰ . Introduction Safety precaution Caution: Danger of electric shock Always switch off power supply before working on the heat pump and stop the hydraulic circuit. - The swimming pool heat pump must be installed by a qualified electrician. - Always install a differential protective device with a sensitivity of 30 mA on the distribution unit before the electrical box. - Page 5 High / Low Refrigerant Pressure Switches • The high-pressure switch senses the refrigerant pressure in the sealed refrigeration system and shuts the heat pump down in the event unsafe operating pressures are reached. The heat pump will automatically reset after the system pressure drops back to normal operating pressures.
-
Page 6: Parameters Of Product Range
Parameters of product range Specification of Vertical Type Model PH20V PHC30V PHC45V PHC60V PHC60Vs PHC75Vs Heating capacity KW (air 26℃,water 26℃) C.O.P. ≥6.0 ≥6.0 ≥6.0 ≥6.0 ≥6.0 ≥6.0 (air 26℃,water 26℃) Heating capacity KW (air 15℃,water 26℃) C.O.P. ≥4.5 ≥4.5 ≥4.5... - Page 7 Dimension: PH20V PHC30V PHC45V PHC60V(s) PHC75Vs Above data is subject to modification without notice...
-
Page 8: Installation Guide
Ⅱ . Installation Guide Attention! This swimming pool heat pump must be installed by a skilled team. Transport it in proper manner 1. Transport it in original package. 2. When moving the machine, do not lift the water nozzle since the titanium heat exchanger in side the machine will be damaged. - Page 9 Avoidance of air recirculation Easy for wire and pipe connection and Water pipe line of long water lines (not longer than 10m.) from heater to pool. Easy for maintenance. Drainage of condensation. Pay attention to the following points: 1． The heat pump must be installed OUTSIDE in a well ventilated place to avoid air recirculation or in a place with adequate room area both for installation and maintenance.
- Page 10 2． The heater should be located on a solid, level and non-corrodible structure that is capable of supporting the weight of the heat pump. It must be fixed by bolts (M10) to concrete foundation. At least 300mm !!Warning: The machine must not be hung onto the wall with soft pipe since the inlet/outlet At least 300mm union on the machine can’t hold weight.
-
Page 11: Water Pipe Connection
Water pipe connection - The water flow through this machine needs to be driven by an appended water pump (Prepared by the user). The recommended pump specification-flux is shown on the product specification and Max. lift ≥10m; - Pipe length between heat pump and swimming pool should not be longer than 10m. Noted: The drawing is just for demonstration, and layout of the pipes for reference. -
Page 12: Electric Connection
Electric connection - Wiring must be handled by a professional technician according to the circuit diagram as following. - Connect the heat pump to appropriate power supply and the voltage should comply with the rated voltage of each model stated on the specification. - Make sure the machine is ground well. -
Page 13: Trial After First Installation
Recommendation for protecting devices and cable specification MODEL PH20V PHC30V PHC45V PHC60V PHC60Vs PHC75Vs Rated Current A Rated Breaker Residual Action Current mA Fuse A Power Cord （mm ） 3×2.5 3×4 3×4 3×6 5×2.5 5×4 Signal cable （mm ） 3×0.5 3×0.5... - Page 14 - Press power on/off on LED controller to turn on/off machine. - During the first start of machine, please check if there is any water leakage in the piping connection system. Then set suitable temperature. - After the swimming pool heater runs, check if there is any abnormal noise or smell. In any abnormal situation, such as serious noise, smell or smoking please cut the power supply immediately and inform resellers, never try to repair it by yourself.
-
Page 15: Operation Guide
Ⅲ . Operation guide LED controller Power on/off CLOCK Set local time. TIME OFF Set the time required for machine to auto-stop. Light A Shows the auto-stop time being set. TIME ON Set the time required for machine to auto-operate Light B Shows the auto-operate time being set. -
Page 16: Common Setting
Common setting 1． Heat/Cool Mode Press the Mode button to switch from one mode to another. （ ） Available only in heat and cool machine. 2． Required pool water temperature It can be adjusted both when the machine is on or off. Press UP-ALLOW key or DOWN-ALLOW key to set to your required pool... -
Page 17: Automatic On/Off
Automatic on/off This function can make the machine work or stop automatically in your required time. 1. Time on Press to set timer on. When the indicator light is on and the time is flashing , press again to set hour. to adjust. -
Page 18: Maintenance
Ⅳ. Maintenance Caution: Danger of electric shock “Cut off” power supply of the heater before cleaning, examination and repairing A． In winter season when you don’t swim: Cut off power supply to prevent any machine damage Drain water clear of the machine. !!Important: Unscrew the water nozzle of inlet pipe to let the water flow out. -
Page 19: Trouble Shooting
Ⅴ. Trouble shooting Common faults Phenomenon Possible reason A. The fan motor stops automatically for defrost. B. There will be sound from the solenoid valve when A.Noticeable White vaporous machine starts or ends to defrost. cold air or water. C. During machine working or just stopping, a sound like water flow, in 2~3 minutes of starting the machine. -
Page 20: Failure Code
Failure code Failure Failure description Action code EE 1 High pressure protection Contact your dealer. EE 2 Low pressure protection Contact your dealer. 1. Check if there is no water through the machine; make EE 3 Low water pressure protection sure the pump is on. -
Page 21: Warranty Condition
WARRANTY CONDITIONS The warranty must comply with the following terms: The unit can only be repaired by Aquatight Pool Equipment personnel or an authorized dealer. Maintenance must be carried out periodically, or as required. Only genuine Aquatight spare parts should be used NOTE: Failure to comply with these recommendations will void warranty. - Page 22 State Health Departments, we will not be responsible for damage done by corrosion, scaling and stress cracking of the equipment. ● If, in the opinion of Aquatight Pool Equipment, the equipment has been subjected to other than normal swimming pool use or has been improperly serviced or maintained.
- Page 23 Contact Details: Aquatight Pool Equipment. Website: www.autopool.com.au Email: info@autopool.com.au Western Australia 115 Belmont Avenve,Belmont Western Australia, 6104 Phone: 08 9362 4022 Fax: 08 9361 3913 New South Wales 35/15 Valediction Road, Kings Park, NSW, 2148 Phone: 02 9671 7041 Fax: 02 9671 7963...
- Page 24 Version: H23-100707...
