  • Page 1 Assembly manual...

  • Page 3: Table Of Contents

    2.1 - General safety information ......................pag. 4 2.2 - Working environment ......................... pag. 4 3 - HEKK - ASSEMBLY TECHNICAL TABLES AND DRAWINGS ..............pag. 5 3.1 - Table of cutting dimensions ....................... pag. 5 3.2 - HEKK Technical sheet ....................... pag. 6...

  • Page 4: Introduction

    SHADELAB reserves the right to update the production and the respective manuals, without being obliged to update the previous production and manuals. SHADELAB reserves all rights to this manual: no total or partial reproduction is allowed without authorisation in writing.

  • Page 5: Equipment Necessary

    » complete set of tools. 1.3 - Before starting assembly IMPORTANT Some components must be cut to suit the dimensions of the awning that is to be obtained (see Par. 3.3 “Table of cutting dimensions”). HEKK ASSEMBLY – REV 00...

  • Page 6: Safety

    IMPORTANT SHADELAB guarantees the EC marking only for products supplied by the company itself. If any parts have to be replaced with other components not guaranteed by SHADELAB, the product guarantee will automatically become void and SHADELAB shall not answer for any malfunctions of the product.

  • Page 7: Hekk - Assembly Technical Tables And Drawings

    3 – HEKK - ASSEMBLY TECHNICAL TABLES AND DRAWINGS 3.1 – Table of cutting dimensions Cutting dimensions COMPONENT/motor Cutting ration in [mm] COVER PROFILE L-88 CASSETTE PROFILE L-88 TERMINAL PROFILE L-110 ROLLER TUBE L-70 FABRIC L-125 ATTENTION : THE POSITION OF A FABRIC is 30 mm FROM THE EDGE OF THE...

  • Page 8: Hekk Technical Sheet

    3.2 - HEKK Technical sheet Sizes – side view Fixing bracket HEKK ASSEMBLY – REV 00...
  • Page 9 Sizes – front view, closed awning HEKK ASSEMBLY – REV 00...
  • Page 10 Sizes – front view, opened awning HEKK ASSEMBLY – REV 00...
  • Page 11 Componests HEKK ASSEMBLY – REV 00...

  • Page 12: Hekk Assembly

    3.3 – HEKK Assembly Brackets position for Hekk on the wall Define the distance of the brackets and position them on the awning assembly frame. Hekk frontal opening HEKK ASSEMBLY – REV 00...
  • Page 13 ATTENTION: On the top the support written DX, and in the opposite site the support written SX ATTENTION: Use the existing holes number 2 11 I HEKK ASSEMBLY – REV 00...
  • Page 14 Example assembling Hekk to frontal opening Plate side Spring side HEKK ASSEMBLY – REV 00...
  • Page 15 ATTENTION: used the holes number 2 assembling the roll and the fabric ATTENTION: look the direction of the fabric 13 I HEKK ASSEMBLY – REV 00...
  • Page 16 ATTENTION: make two holes Ø6,5 and two holes Ø10 in the right position assembling the cover profile HEKK ASSEMBLY – REV 00...
  • Page 17 ATTENTION: How to lock the cover profile Assembling coupling gasket ATTENTION: there are two gaskets to insert 15 I HEKK ASSEMBLY – REV 00...
  • Page 18 Assembling the terminal bar Assemble the terminal bar inserting the fabric in the ogive in the terminal bar End caps and adaptors for terminal bar ATTENTION: assembling the end caps and the adaptor as in picture HEKK ASSEMBLY – REV 00...
  • Page 19 ATTENTION: insert the spring on the roller tube and rotate the support 9 laps ( step1). ATTENTION: locked the support with the screws (step 2) Fixing the cover profile ATTENTION: Open little the terminale bar and locked the cover profile 17 I HEKK ASSEMBLY – REV 00...
  • Page 20 Awning installation Hekk to frontal opening ATTENTION: Place the box in correspondence of the brackets (1) ATTENTION: Screw the M8 nuts until they are firmly tight (2) HEKK ASSEMBLY – REV 00...
  • Page 21 Awning installation Hekk to frontal opening ATTENTION: install the column or attach the hook to the wall Ensure that the awning is working by opening and closing it totally a few times 19 I HEKK ASSEMBLY – REV 00...
  • Page 22 Hekk lateral opening HEKK ASSEMBLY – REV 00...
  • Page 23 ATTENTION: On the top the support written DX, and in the opposite site the support written SX ATTENTION: Use the existing holes number 1 21 I HEKK ASSEMBLY – REV 00...
  • Page 24 Example assembling Hekk to laterall opening Plate side Spring side HEKK ASSEMBLY – REV 00...
  • Page 25 ATTENTION: used the holes number 1 assembling the roll and the fabric ATTENTION: look the direction of the fabric ATTENTION: follow the others steps like assembling Hekk frontal opening 23 I HEKK ASSEMBLY – REV 00...
  • Page 26 Awning installation Hekk lateral opening ATTENTION: Place the box in correspondence of the brackets (1) ATTENTION: Screw the M8 nuts until they are firmly tight (2) HEKK ASSEMBLY – REV 00...
  • Page 27 Awning installation Hekk lateral opening ATTENTION: install the column or attach the hook to the wall Ensure that the awning is working by opening and closing it totally a few times 25 I HEKK ASSEMBLY – REV 00...
  • Page 28 NOTES...
  • Page 29 NOTES...
  • Page 30 NOTES...
  • Page 31 Art direction Last revision: 05.2017...
  • Page 32 REVISION DER MONTAGEANLEITUNG DURCH via Lazio, 42 31045 Motta di Livenza (TV) - Italy t: +39 0422 1786080 f: +39 0422 1788073 info@shadelab.it www.shadelab.it...
