Summary of Contents for ShadeLab ILIOS RAY
- Page 1 Installation manual...
-
Page 3: Table Of Contents
2.1 - General safety information ......................pag. 4 2.2 - Working environment ......................... pag. 4 3 - ILIOS RAY - ASSEMBLY TECHNICAL TABLES AND DRAWINGS ............pag. 5 3.1 - Motor power table ........................pag. 5 3.2 - Table of cutting dimensions ....................... pag. 5 3.3 - Technical sheet .......................... -
Page 4: Introduction
1 – INTRODUCTION This “assembly manual” for ILIOS - awnings has been produced by SHADELAB to supply the indications necessary for the operations of assembling the components that make up the product. Assembly must be carried out by personnel with suitable technical and professional qualifications, in accordance with the respective national laws or regulations (see Par. -
Page 5: Equipment Necessary
1.2 - Equipment necessary To ensure the correct assembly of the mechanical part, of the textile part, and consequently the optimum operation of the finished product, it is necessary to be in possession of the following equipment: » fabric rolling frame; »... -
Page 6: Safety
IMPORTANT SHADELAB guarantees the EC marking only for products supplied by the company itself. If any parts have to be replaced with other components not guaranteed by SHADELAB, the product guarantee will automatically become void and SHADELAB shall not answer for any malfunctions of the product. -
Page 7: Ilios Ray - Assembly Technical Tables And Drawings
3 – ILIOS RAY - ASSEMBLY TECHNICAL TABLES AND DRAWINGS 3.1 – Motor power table Width [cm] 15/17 Nm 3.2 – Table of cutting dimensions Cutting dimensions COMPONENT/motor Cutting ration in [mm] COVER PROFILE L-88 CASSETTE PROFILE L-88 TERMINAL PROFILE... -
Page 8: Technical Sheet
3.3 - ILIOS RAY Technical sheet Sizes – side view Fixing bracket ILIOS RAY INSTALLATION – REV 00... - Page 9 Foot kit Foot fixing bracket ILIOS RAYI INSTALLATION – REV 00...
- Page 10 Sizes – front view, closed awning ILIOS RAY INSTALLATION – REV 00...
- Page 11 Sizes – front view, opened awning ILIOS RAYI INSTALLATION – REV 00...
-
Page 12: Installation
3.4 – ILIOS RAY Installation Brackets position Mark the bracket position on the wall. The distance from the outer edge of the bracket is 30 mm less than the awning length (L) in mm, with a ± 5 mm tolerance. - Page 13 Awning installation Place the box in correspondence of the brackets Screw the M8 nuts until they are firmly tight Fixing screws – detail Tighten the screw until it reaches the bracket 11 I ILIOS RAYI INSTALLATION – REV 00...
- Page 14 Block the wire to the wire lock. ATTENTION: block the wire with the nuts without letting it go out from the wire lock Block the wire with the 2 lateral screws in the cassette support ILIOS RAY INSTALLATION – REV 00...
- Page 15 Wire lock – detail Please see here above the correct position of the wire lock Foot position Position of the foot on the floor and wall Size between wire axis and outside awning = 58 mm Size between foot anchoring bracket edge and outside awning = 48 13 I ILIOS RAYI...
- Page 16 ATTENTION: Block the wire while keeping the tensioning kit upwards. PHASE 3: While keeping the tie-rod tight, screw the nut with the ring combination spanner until the spring is compressed about 5 mm ATTENTION: the spring MUST NOT be totally compressed ILIOS RAY INSTALLATION – REV 00...
- Page 17 Regulation of the limit switch Ensure that the awning is working by opening and closing it totally a few times ATTENTION: in case of motorized awning, the limit switch is set at about the middle of the height. To change it and check the correct functioning of the product, please refer to the manual of the motor supplied with the awning.
- Page 18 NOTES...
- Page 19 Art direction Last revision: 05.2017...
- Page 20 REVISION DER MONTAGEANLEITUNG DURCH via Lazio, 42 31045 Motta di Livenza (TV) - Italy t: +39 0422 1786080 f: +39 0422 1788073 info@shadelab.it www.shadelab.it...
