Instructions for Installation of
Tools Supplied
Open extension kit and check that all parts were included.
Drain Hose
Step
1.
Unplug machine or disconnect power before servicing.
2.
Remove Drain Hose outlet from the collection tank fitting.
W11422896B
Extended Drain Hose Kit
Description
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Failure to do so can result in death or
electrical shock.
Figure
1
Advertisement
Related Manuals for Whirlpool WCD3090JW
Summary of Contents for Whirlpool WCD3090JW
- Page 1 Instructions for Installation of Extended Drain Hose Kit Tools Supplied WARNING Open extension kit and check that all parts were included. Drain Hose Electrical Shock Hazard Disconnect power before servicing. Failure to do so can result in death or electrical shock. Step Description Figure...
- Page 2 Step Description Figure Slowly but firmly pull out the drain hose from its fitting in the pump outlet. Discard the drain hose. Slowly but firmly push the longer drain hose on the fitting of the pump outlet. Plug in machine or connect power after servicing. Insert hose so that the end of the hose extends 4.5"...
- Page 3 Instructions pour l’installation de la trousse de prolongement de tuyau de vidange Outils fournis AVERTISSEMENT Ouvrir la trousse de prolongement et vérifier que toutes les pièces sont incluses. Tuyau de vidange Risque de choc électrique Déconnecter la source de courant électrique avant l'entretien.
- Page 4 36 po (910 mm) du bas de la sécheuse. S’assurer de ne pas plier le prolongement du tuyau de vidange lors de la remise en place de la sécheuse. ©2021 Whirlpool. All rights reserved. Used under license in Canada. ® é...
