Ansul AUTOPULSE IQ-301 Installation, Operation And Maintenance Manual page 91

How to Enter Program Change
Verify=
To change, enter a timer value as
follows: 0–30 seconds (for systems
with Release 1.2 software or higher)
or 0 to 60 seconds (only permitted in
systems with Release 1.0 and 1.1
software)
ANNUN=
To change, press the Up or Down
key to scroll through the selections
(See Table 27 on page 90).
BLINK=Y
To change the value between Y and
N, press the Up or Down key.
IQ-301 PN 50036:F 10/29/2001
Selection Specifies
LocT (default) A local CRT terminal or computer in the same room as the control panel that
provides Read Status, Alter Status, Acknowledge, Silence, Drill, and
System Reset functions.
LocM Functions in the same manner as LocT except that it requires a password to
execute the Acknowledge, Silence, Drill, and System Reset functions.
RemT A remote terminal located away from the control panel that only allows the
user to execute the Read Status function.
Table 28 EIA-232 Operating Mode Selections
How To Edit System Functions
This section contains instructions for editing system function fields. To do so, follow
these steps:
1. From the Program Change screen (Figure 53 on page 71), select 7=SYSTEM to
display the System Function screen. Figure 82 shows a System Function screen
with default system values.
2. Edit the system function values as shown in Figure 82. For additional information
on each value, refer to "Understanding System Functions" on page 89.
3. When finished editing, press the
screen.
SIL@INH=000@AUTO=000
VERIFY=30@@@USA@TIME
ANNUN=NONE SUPV@@LOCT
BLINK=Y@ST=4@AVPS=N
Figure 82 Editing System Functions
key to return to the Program Change
ENTER
Sil Inh=000
To change the timer value, enter a timer value
between 000–300 seconds.
Auto=
To change the timer value, enter 000 none
(default) or 600–900 seconds.
AVPS=4 (or APS-6R)
To switch the value between Y and N,
press the Up or Down key.
ST=4
To switch the value between ST=4 and ST=6,
press the Up or Down key.
Programming
USA TIME (default)
To switch the value between
USA and EUR, press the Up
or Down key.
LocT (default)
To change, press the Up or
Down key to scroll through
the selections: LocT, LocM,
or RemT.
91
