- Page 1 Ink-jet Printer E400HP MANUAL...
-
Page 2: Table Of Contents
Table of contents Safety Instruction Packing List Technical Data Environment/Electrical Requirement Installation & Testing Switch On/Off Operation <The main screen> <system> 1 “Print head management” 2. “Authority” 3 “disk” 4.Ink look 5.Appearance 6. System information 7 “date time’ 8 “calibrate” <Parameter>... - Page 3 Declare Ø Please read the manual seriously before running machine. Any mistake or damage caused by user’s incorrect operation, shall be not on our responsibility. Ø In any circumstances, the ink-jet printer shall uses the accessories and consumables (include inks &...
-
Page 4: Safety Instruction
Safety Instructions Personal Safety Ø Some inks & cleaners are harmful, please installing & running machine in well ventilated conditions. Ø Some inks & cleaners are flammable, keep away from all sources of heat and ignition. Fire-extinguisher shall be equipped with nearby the machine. Ø... -
Page 5: Packing List
Packing List Name Quantity E400HP controller 1 PC Ink tank System 1 PC Print head System 1 Set Sensor & Clip 1 PC Stands & Fittings 1 Set Power Cord 1 PC Manual 1 Copy Injector 1 PC (only used in solvent printer) The Manual of Ink-jet Printer... -
Page 6: Technical Data
Technical Data Ø System: 32-bit high-speed processor Ø print head: 150height, 600dpi in vertical. Ø print head number: 1 Ø Print height from 1mm to12.7mm by one print head Print Lines capability: Multi-lines(up to character height) Ø Ø Line speed capability: Max.60mt/min. Ø... -
Page 7: Environment/Electrical Requirement
Environment/Electrical Requirement Ø Electrical requirement：AC, 110V±10% 50/60Hz,connect the ground cord. Ø Max Power：15W (average﹤8W) Ø Temperature：5-40 Ø Humidity：10-90%(non-condensing) Electromagnetic interference: far away from electromagnetic radiation zone Ø The Manual of Ink-jet Printer... -
Page 8: Installation & Testing
Installation & Testing Only trained technicians are authorized to carry out installation. Before install, confirm the machine was stay in a solid & smooth place without electromagnetic radiation. Installed as stipulated in manufacturer’s specification, do not change the relative position of ink system and print head. - Page 9 Install & Test 6、 Photoelectric Sensor Installation: 1. Screw the photoelectric clip on the print head stand. 2. screw the photoelectric sensor on the clip or other position as request, or use different types of sensor. When using solvent-base inks, the sensor shall be fixed in front of print head. 7、...
-
Page 10: Switch On/Off
Switch on/off Ø Switch on： Checked up the power connection status before switch on. After switch on, it will enter into the operation system within 15 seconds. Remove the print head cap and press PRINT key to start printing when using oil-based inks. -
Page 11: Operation
Operation Ø <The main screen> Power on the printer, it will display <the main screen > as photo 2. Pic 2 On the operator interface, you will clearly find five menu items： System , Parameter 、 Edit 、print 、File Preview Area with scale is located in the middle of screen. 150 dots height *20000 dots width with graduated scale. -
Page 12: Print Head Management
Pic 3 1. Print head management Click this button will open the interface of print head management. You can set the value of idle-jet. A. Idle-jet If you choose solvent ink system, in order to prevent the ink on the surface of the print head becoming dry out which will cause illegible printing result you may need to start idle-jet printing function according to the chosen ink type, temperature, moisture and air flow rate to set the period and line for idle-jet printing. -
Page 13: Authority
B. Continual number function The continuous number will increase on each successive print activation no matter when power off has been done. See section 4 for setup of this function. Pic 5 2. Authority （Password123456） Click the button “Authority” opens a screen as shown. and then, click <OK> button to open screen as photo 6. -
Page 14: Disk
3. Disk Insert a storage unit into USB interface and click the button “Load” opens a screen as photo5. Pic 7 It just can upload and download a bmp format single color files from a storage disk through USB interface. Click the required file from the left side of screen, and click an arrow <rightwards>... -
Page 15: Appearance
5. Appearance Click the button “Appearance” opens a screen as shown. Pic 9 You can set the length of screen saver and the screen display format. 6. Date & time Pic 10 You can adjust time and date when click “date & time” button. Final value should be confirmed with button <setting>... -
Page 16: "Calibrate
8. Calibrate (Touch Screen Calibration) Click the button<Calibrate> to open screen as shown. Pic 11-1 If the keypad is not aligned, select System on main interface and then click icon Calibrate for adjustment. Click on the screen as shown above to start calibrate. Pic 11-2 Use nib to click the cross center as shown above. -
Page 17: Parameter
Parameter Enter parameter by pressing in the home screen. Pic 12 Change "Print speed ,print delay, print direction, horizon bold, quantity of files you want to print, interval of each file you choose to print and whether to operate with synchronizer. Print head parameter 1. - Page 18 Pic 13 2.2 Interval This setting sets the interval distance between consecutive same prints. 2.3 Print Direction 3. How to choose a photoelectric sensor In order to print in the exact position and prevent from error of printing, you are recommended to choose a photoelectric sensor according to the size and color of the product and speed of production line 4.
- Page 19 Pic 14 5. File Link In certain circumstance, there will be requirement for print several files together after sensed by the sensor. Select File link and then push the set button to proceed. Pic15-1 Pic 15-2 Use Load button to display possible files. Click on the file name to select the file. Then push OK. Repeat load button and select to load all the files want to print.
-
Page 20: Print
Ø Print Note: No editing is possible while printer is in printing mode. If you want to print what you have edited, please click Print. The icon shows red and yellow frame, that means it is under print condition if you choose sensor to print, the printer can print directly with what you have edited. -
Page 21: Edit
See photo 3. After setting the parameter of Idle Jet Gap (interval of time) and Idle-Jet Column, the printer will spray out ink automatically at regular intervals Edit Ø Ø “Edit” including：Text、Special symbol ； Image file ；Bar Code ；Date、 Time、serial number、shift group、BMP generation ,New file creation etc. - Page 22 Pic 20 Note: Image file can only be single color BMP file. The bit map size should not over 160KB. 2. Bar Code Pic 21-1 Pic 22-2 If you want to choose a bar code, choose , then choose the type of the bar code you want to print form the dialog box, you can preview the bar code you choose in the bottom of the dialog box.
- Page 23 Operation 3.Date&Time If you want to generate a new date&time, click ,then choose "date" in the dialog box. Pic 23 Click Set Up Icon to set property of Date, then select the date&time format in the "date setting" dialog box. then set the offset of the date&time on below dialogue box as your actual request. You can preview the date what you have edited in the preview area at the bottom of the dialog box, Click OK to confirm.
- Page 24 Operation Pic 25 Date format: 18 different date formats can be chosen. Date offset：Date offset is available date as your requirement such as period of validity 1, period of validity 2. 4.Serial No ( Continuous number) If you want to generate a Serial No, click ，choose serial No in the dialog box.
- Page 25 Pic 27 Enter edit zone by selecting now make your selection of file content by selecting An edit function These f unctions b elow a re w here t he c ontents o n F iles a re e ntered o r s et/changed. Basic ...
- Page 26 Operation 5.Shift group Pic 28 Click if you want to generate shift group, then choose shift group in the dialog box. Click “Set Up” icon to set shift group，set the name and duration of the shift group in the "shift group" dialog box.
-
Page 27: Text &Text Feature
Operation 7.Text feature After you finish text editing, you can change the parameter of the text. Choose "Font" and then you can adjust the font type& font size. If you want to print with dot matrix , please select "dot" and then set the dot width and dot height, horizontal distance of dots ,vertical distance of dots, dot matrix size and round dot. -
Page 28: Module Operation
Ø Module operation Module operation can work together with "Edit" to work out with perfect printing result. 5 main items ： Select 、 location adjustment 、 Setting 、delete 、rotate 。 1. Select Select the text you need firstly, then the text you are choosing will become blue. Then click , you can choose the text according to the order of the text you have edited. - Page 29 Operation Pic 34 4. Delete：Choose the text you want to print firstly and then click to delete the text. Pic 29 5. Rotate ： Choose the text you want to print firstly and then click ， to 90 degree counterclockwise rotate the text Pic 35 Note: Module operation work’s together with "Edit"...
-
Page 30: Frequent Troubles Elimination
Frequent Troubles Elimination System troubles： Ø Trouble Reason Solution print content The distance from print head to completed, however product surface is too far; or Shorten the distance fuzzy and shadowed. running in fast airflow condition. The surface of print head & Purge the print head by cleaner;... - Page 31 Working condition temperature The working condition temp, should be is too low higher than 5℃ The data cable of print head is Power off, connect the data cable loose once again Electromagnetic radiation Far away from the source of radiation interference.
