MEDC DB1PUL Technical Manual page 4

TONE FREQ/DESCRIPTION
1 Alt Tones 800/970 Hz at 1/4 sec
2 Sweeping 800/970 Hz at 7Hz
3 Sweeping 800/970 Hz at 1 Hz
*
4 Continuous at 2850 Hz
5 Sweeping 2400-2850 Hz at 7 Hz
6 Sweeping 2400-2850 Hz at 1 Hz
7 Slow Whoop
8 Sweep 1200-500 Hz at 1 Hz
9 Alt Tones 2400/2850 Hz at 2 Hz
10 Int Tone of 970 Hz at 1 Hz
11 Alt Tones 800/970 Hz at 7/8 Hz
12 Int Tone at 2850 Hz at 1Hz
13 970Hz at 1/4 sec on 1 sec off
*
14 Continuous at 970 Hz
15 554Hz for 100mS / 440 Hz for 400mS
16 Int 660 Hz 150 mS on 150 mS off
17 Int 660 Hz 1.8 sec on 1.8 sec off
18 Int 660 Hz 6.5 sec on 13 sec off
*
19 Continuous 660 Hz
20 Alt 554/440 Hz at 1 Hz
21 Int 660 Hz at 7/8 Hz
22 Int 2850 Hz 150 mS on 100 mS off
23 Sweep 800-970 Hz at 50 Hz
24 Sweep 2400-2850 Hz at 50 Hz
25 3 970Hz pulses 0.5on/0.5off, 1.5 off
26 3 2850Hz pulses 0.5on/0.5off, 1.5 off
27 Int 3100 Hz 0.32s on / 0.68s off
28 Spare/Customer Tone
29 Spare/Customer Tone
30 Spare/Customer Tone
31 Spare/Customer Tone
32 Spare/Customer Tone
* DB1P Tone 4 is acceptable for ublic mode use. DB1P Tones 14 & 19 are acceptable for
rivate mode use. DB1HP Tones 4 & 14 are acceptable for ublic mode use.
07/17
DB1HP Tone 19 is acceptable for rivate mode use
SWITCH
SETTING
12345
11111
11110
11101
11100
11011
11010
11001
11000
10111
10110 Back-Up Alarm(LF)
10101
10100 Back Up Alarm(HF)
10011
10010
10001 French Fire Sound
10000 Swedish Fire Alarm
01111 Swedish Fire Alarm
01110 Swedish Fire Alarm
01101 Swedish Fire Alarm
01100 Swedish Fire Alarm
01011 Swedish Fire Alarm
01010 Pelican Crossing
01001
01000
00111
00110
00101
00100
00011
00010
00001
00000
TONE
DESCRIPTION
Fast Sweep(LF)
Med Sweep(LF)
Fast Sweep
Slow Whoop
Din Tone
Low Freq Buzz
High Freq Buzz
© Eaton MEDC Ltd 2017
