SiliconDust LinkSquare1 Quick Start Manual

<1> Introduction

LinkSquare is Stratio's low-cost, handheld, smartphone-compatible spectrometer.

LinkSquare analyzes an object's response to light in order to determine the "spectral

signature" of the object, and identify the object or reveal information about its

composition that cannot be seen with the naked eye.

<2> Production Specification

Product Name LinkSquare

Model LinkSquare1

Power Input Micro USB Power / 5V

Controller CC3200MOD(ARM Cortex-M4 Core at 80 MHz)

Wi-Fi IEEE802.11b/g

Battery 720mAh / 3.7V

Size 24mm x 114mm x 24mm (L x W x H)

Weight 57g

Table of Contents

Need help?

Do you have a question about the LinkSquare1 and is the answer not in the manual?

Page 1 <2> Production Specification Product Name LinkSquare Model LinkSquare1 Power Input Micro USB Power / 5V Controller CC3200MOD(ARM Cortex-M4 Core at 80 MHz) Wi-Fi IEEE802.11b/g Battery 720mAh / 3.7V...
Page 2 <3> Steps for the normal sample test 1) Charge LinkSquare device. It is possible to operate LinkSquare device while charging, but it is recommended to charge the device at least an hour if the battery was totally depleted. 2) The micro USB port does not support data transfer. 3) Press power/scan button for 5 second or more, then status indicator leds with green is going to be blink.
Page 4 FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
