VX280 Instruction Manual
Quick Start Guide
For Gauge Hole Receivers
Not all features listed in this QSG
are available on all models.
THIS PACKAGE CONTAINS
Marine Media Player with Bluetooth
U mounting bracket (Pre-installed)
Screw Posts (Pre-installed)
Hex Nuts (Pre-installed)
User Manual
www.velextech.com
x 1
x 1
x 2
x 2
x 1

Advertisement

Table of Contents
loading

Related Manuals for Velex VX280

Summary of Contents for Velex VX280

  • Page 1 VX280 Instruction Manual Quick Start Guide For Gauge Hole Receivers Not all features listed in this QSG are available on all models. THIS PACKAGE CONTAINS Marine Media Player with Bluetooth U mounting bracket (Pre-installed) Screw Posts (Pre-installed) Hex Nuts (Pre-installed) User Manual www.velextech.com...

  • Page 2: Wire Connection Diagram

    WIRE CONNECTION DIAGRAM ISO CONNECTOR SIDE B SIDE A 2.: PINK 1.: VIOLET BREAK(-) REAR RIGHT SP. 4.: YELLOW 2.: VIOLET/BLACK 5.: BLUE 3.: GRAY FRONT RIGHT SP. BACK UP(+) 7.: RED 4.: GRAY/BLACK AUTOANT(+) FRONT LEFT SP. 8.: BLACK 5.: WHITE 6.: WHITE/BLACK REAR LEFT SP.

  • Page 3: Mounting And Wiring

    Mounting &Wiring Please read entire manual before installation. Before You Start Disconnect negative battery terminal. Consult a qualified technician for instruction. Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration. Mounting Bracket Getting Started Once a suitable location has been decided, drill the hole and secure the stereo...

  • Page 4: Installation

    5.5 Inch Wide 2.5 Inch Deep 3.6 Inch Tall Mounting the Radio VX280 1.Choose a mounting location on the dash board or instrument panel that will allow room behind to run radio cables to the power source. Consider how you will use the AUX IN, LINE OUT and USB connectors and route the appropriate extension cables to an accessible area.

  • Page 5: Control Locations - Receiver

    Control Locations - Receiver IPX6 VX-280 WATERPROOF 45W x 4 CH BAND MUTE SCAN Setting/Clock Power/Source MUTE/DIM Tune Down/Previous Track Tune Up/Next Track 1/PLAY/PAUSE Volume Up 2/INTRO SCAN Volume Down 3/REPEAT Band/Scan 4/RANDOM...

  • Page 6: General Operation

    Pick up Preset: Short press numeric button and jump to next Preset station. Storing of Stations in Memory: Once the desired station has been selected by manual tuning, press and hold one of the four preset station memory button for 1 second to save to VX280 memory.

  • Page 7: Bluetooth Operation

    Pairing To pair your smart phone to VX280, press the SRC button to select BT mode, the BT CONNECT will be flash on the LCD screen. Activate the Bluetooth on your smartphone to search for new devices. Connect with the device name VELEX;...

  • Page 8: Specifications

    Specifications General Power supply requirements: DC 12V Negative Ground Load impedance: 4-8 Ohms/channel Maximum output power: 40W x 4 (CH) Operate temperature: -10-50℃ FM Tuner: Tuning range: 87.9MHz-107.9MHz (USA) 87.5MHz-108MHZ (EUR) AM Tuner: Tuning range: 530KHz-1710 KHz (USA) 522KHz-1620 KHz (EUR) USB playback Signal to Noise Ratio: 55dB Frequency Response: 50Hz- 20KHz...
