AIR EXCHANGE EQUIPMENT
INSTALLATION AND USER
MANUAL
DIVK-C220 DEMA and DIVK-C220 DEMA VKL
THE QUALITY GOALS OF AIR CONDITIONING COME TRUE
WITH THE RECOVERY SYSTEM
TALTERI removes used air from interior and brings in fresh air.
Humidity and impurities are exhausted through thermal recovery
unit that heats the filtered ambient air cost-effectively. The fresh
warm air is channelled draught-free and noise-free into the
premises in necessary quantities.
ENSURE THE QUALITY OF AIR EXCHANGE!
DEEKAX Air Oy
TALTERI
QUALITY TESTED
Patruunapolku 4
79100 LEPPÄVIRTA
R
Puh. 0207 912550
www.deekaxair.fi

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DIVK-C220 DEMA and is the answer not in the manual?

Questions and answers

Summary of Contents for Deekax DIVK-C220 DEMA

  • Page 1 AIR EXCHANGE EQUIPMENT INSTALLATION AND USER MANUAL TALTERI DIVK-C220 DEMA and DIVK-C220 DEMA VKL QUALITY TESTED THE QUALITY GOALS OF AIR CONDITIONING COME TRUE WITH THE RECOVERY SYSTEM TALTERI removes used air from interior and brings in fresh air. Humidity and impurities are exhausted through thermal recovery unit that heats the filtered ambient air cost-effectively.
  • Page 2 Talteri heat recovery system SYSTEM COMPONENTS EXHAUST AIR DLVS-125/240 **** Picture 1 1 Air exchange unit..DIVK-C220 DEMA 2 Adjustment cover..DX-ULTRA 3 Exhaust air outlets……………. 250 DIVK SUPPLY AIR EXTRACT AIR OUTDOOR AIR 4 Channel noise deductor..250 DLT-150 5 Exhaust air for the system..250 ULTRA-PG EC 6 Outdoor air for the system..
  • Page 3 INSTALLING THE CHANNELLING The channels for exhaust air and incoming air should be installed, if possible, in a warm space below the vapour barrier to suspended ceilings or casing. The vapour barrier remains intact and the channels do not need heat insulation.
  • Page 4 TALTERI INSTALLATION The air exchange unit is meant for warm inner facilities. Suitable installation spots are, among others, office, dressing or household facilities and technical or warm storages. In case the temperature of the installation location is lower than room temperature, the factory settings of the appliance must be changed to obtain faultless functioning. The unit can not be installed into cold outer premises or garages.
  • Page 5: Electrical Connections

    ELECTRICAL CONNECTIONS The following can be connected as accessories: - Carbon dioxide transmitter; Electrical connections must be done following the installation manual - Humidity transmitter; and wiring diagram. - Separate Overload or Extended Period switch (pulse switch); ELECTRICAL CONNECTIONS CAN BE DONE ONLY BY - Separate Boost switch (pulse switch);...
  • Page 6 C 220 DEMA tip extract fan information max. 2A 250V tip supply fan information max. 2A 250V 0-10v 0-10v A/D+ B/D- O O O ON OFF BIAS B O O O ON OFF Term O O O ON OFF BIAS A PRE- Circuit board HEATER...
  • Page 7 When installing TALTERI equipped with a water radiator (VKL model): - During the design phase, the temperatures of the water used should be taken into account and the adequacy of the heating capacity under sizing conditions should be checked. - The heating coil is connected to a 15 mm copper or similar plastic tube - Future Machine of water must be pre-adjusted after the boiler going water heating coil is connected to the actuator, which controls water flow to the radiator - Radiator return water pipe installed in the top of the vent valve...
  • Page 8 INTRODUCTION OF THE AIR EXCHANGE SYSTEM BEFORE OPERATING YOUR AIR EXCHANGE SYSTEM, USAGE AND CORRECT LEVEL OF AIR EXCHANGE MAKE SURE THAT: The air exchange level is regulated by changing the - There are no loose objects within the unit or the air impeller; working speed of the air impeller from the operating panel.
  • Page 9: Service Menu

    INTRODUCTION OF THE AHU CONTROL PANEL Settings are applied via the service menu SERVICE MENU Note: swipe right at SETTINGS the top of the screen 0-10V external control (0-10V hood,remote monitoring) select the deployment SENSOR 1 "EXT" or SENSOR 2 "EXT" External control controls the basic speed , replaces the fan speed set in the menu.
  • Page 10: Touch Screen Buttons

    OPERATING PANEL USER INSTRUCTION MAIN DISPLAY AND ADJUSTMENT OF BLOWING SPEED CLOCK THE DISPLAY ALSO SHOWS POSSIBLE INCREASED EFFICIENCY AND MALFUNCTIONS EDIT Touch screen buttons: HUMIDITY AND CARBON DIOXIDE VALUE Fan speed adjustment 1..5 IF SENSORS ARE INSTALLED (accessory equipment) TEMPERATURE DISPLAY FOR TEMPERATURE OFOUTSIDE AIR, Out-of-house mode...
  • Page 11: Setup Menu

    SETUP MENU SETTINGS Fan speed adjustment 1..5 Touch screen buttons: Fan speed adjustment 1..5 Out-of-house mode Fireplace switch (pressure compensation) Boosting The button can be used to browse menu upwards and change settings. Maintenance interval and reset The button can be used to browse menu downwards and change setting value.
  • Page 12: Maintenance Menu

    MAINTENANCE MENU SETTINGS Touch screen buttons: Fan speed adjustment 1..5 Out-of-house mode Extended time (office mode) SWIPE RIGHT AT THE TOP OF THE SCREEN Boosting HOME overpressure activated The button can be used to browse menu upwards and change settings. OFFICE continuation time activated The button can be used to browse menu downwards and change setting value.
  • Page 13 Regulation of Inlet Air and Pre-heating value The value of pre-heating should be regulated to be approx 5 C higher than the Freeze-alert settings -10…10 limit of cold exhaust air Overpressure duration specification 0 and 5...20min. In 0 position with different pre-data Overpressure limit regulation 1...4 (inlet air impeller Anti-freeze appliance’s control higher than outlet air impeller)
  • Page 14: Operational Description

    OPERATIONAL DESCRIPTION 1. Operating panel The operation is directed according to settings inserted by the user or installer/manufacturer through the operating panel as well as according to temperature sensors and set periods. The operating panel returns from processing state to basic state 2 minutes after the last button pressing. The return time from normal position is 2 minutes.
  • Page 15: Setting The Temperature

    3.7. Office mode The installer can select the office mode from the maintenance menu – this is useful in case the air exchange system is installed into an office where activities take place mostly during daytime. The speeds are controlled by the weekly clock. The mode is equipped with continuation switch that enables persons who remain in the office for longer to prolong the functioning of the appliance by set interval.
  • Page 16 The channels must be checked if the impeller works but the air exchange is inadequate or the temperature changes in the channels between the interior and the machine. Temperature changes and humidity concentration in channels must be prevented by improving the isolation. DEEKAX Air Oy Patruunapolku 4 Puh. 0207 912550 79100 LEPPÄVIRTA...

This manual is also suitable for:

Divk-c220 dema vkl
