- Page 1 ® ZICO QUIC-RELEASE ® LIdE yLIndER RACkEt QR-d-S 3030PM24 OdEL ARtS And nStRUCtIOn AnUAL WT./@ MODEL DESCRIPTION IN LBS. QR-D-S Slide-Out Cylinder Bracket...
- Page 2 Parts Breakdown ITEM PART NO. DESCRIPTION QTY. 3030-102-101 STOP BLOCK 3030-102-103 SPRING 3030-102-105 STOP PLATE 3030-102-107 HOLDER, D CYLINDER 9180-002526 CLEVIS PIN, 1/4" x 1-5/8" 9140-111218 SPRING PIN, 1/8" x 1-1/8" 3030-102-901 STRAP ASSEMBLY 9260-001802 RIVET, 3/16" x .188/.250 9114-101800 WASHER, #10 9070-000612 COTTER PIN, 1/16"...
- Page 3 TOLL FREE: 800-711-3473 10 West College Avenue, P.O. Box 337, Yardley, PA 19067-0587 • (215) 493-3618 • FAX: (215) 493-1401 *ZICO is a registered trademark for fire, safety and marine products made by Ziamatic Corp. Copyright Ziamatic Corp. 2-17 Page 3...
