- Page 1 ZICO ® QUIC-RELEASE Horizontal Strapless Cylinder Bracket ® 3030PM18 Model QR-E-1/H Parts and Instruction Manual Rev. 10-12-20 WT./@ MODEL DESCRIPTION IN LBS. QR-E-1/H Horizontal Strapless "E" Cylinder Bracket...
- Page 2 Parts Diagram ITEM PART NO. DESCRIPTION QTY. 3030-114-103 E-CYL. BRACKET RETAINER 3030-114-101 E-CYL. BRACKET BASE 9110-361608 #8 x 1/2" FLAT HD, SOCKET HD. S.S. 3030-113-109 D-CYL. BRACKET CAM (LEFT) 3030-113-111 D-CYL. BRACKET CAM (RIGHT) 3030-113-113 D-CYL. BRACKET CAM SPRING 3030-113-115 D-CYL. BRACKET CAM SPACER 3030-113-117 D-CYL.
- Page 3 Operating Instructions To store standard and steel "E" cylinders: Place bottom of cylinder against Return Spring Assembly (8 & 9). Lower cylinder through the latches (4 & 5), until both click into the locked position. Check that the cylinder is now secure against the latches. Note: For additional security, extra holes are provided in E-Cyl.
- Page 4 TOLL FREE: 800-711-3473 10 West College Avenue, P.O. Box 337, Yardley, PA 19067-0587 • (215) 493-3618 • FAX: (215) 493-1401 Copyright Ziamatic Corp. 10-20 *ZICO is a registered trademark for fire, safety and marine products made by Ziamatic Corp. Page 4...
