Cornwell Tools CSE-1000A Operating Manual

• Operating Manual
• Warning Information
• Parts List
Capacity . . . . . . . . . . . . . . . . . . . . . . . 1000 Lbs.
Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36"
Folded Height . . . . . . . . . . . . . . . . . . . . . 20.5"
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37"
Width . . . . . . . . . . . . . . . . . . . . . . . . . . .36-1/2"
Shipping Weight . . . . . . . . . . . . . . . . . . 92 Lbs.
Do NoT overloaD. overloaDiNg caN cause Damage To, or
failure of The sTaND.
This sTaND is DesigNeD for use oNly oN harD level sur­
faces capable of supporTiNg The loaD. use oN oTher
ThaN harD level surfaces caN resulT iN sTaND iNsTabiliTy
aND TippiNg of loaD.
lock The mouNTiNg­plaTe roTaTiNg mechaNism before
applyiNg a loaD. release roTaTioNal lockiNg Device sloW­
ly aND carefully.
alWays use high sTreNgTh sae graDe 8 bolTs for eNgiNe
mouNTiNg bolTs.
make sure WiDesT seT of mouNTiNg heaD fiNgers are
NearesT The grouND WheN mouNTiNg aN eNgiNe To The
sTaND.
alWays be sure ThaT The loaD is ceNTereD aND secureD
To The mouNTiNg plaTe. off­ceNTer loaDs may make The
loaD aND haNDle roTaTe iN eiTher DirecTioN WheN The
roTaTioNal lockiNg Device is releaseD.
Never looseN mouNTiNg bolTs uNless eNgiNe is supporTeD
by a craNe or hoisT.
Do NoT use sTaND To Dolly or TraNsporT eNgiNes.
No alTeraTioNs To The sTaND or aDapTers shall be maDe.
Do NoT roTaTe moTor uNless rear legs are secureD from
TippiNg.
reaD, sTuDy aND uNDersTaND all iNsTrucTioNs before
operaTiNg.
failure To heeD These WarNiNgs may resulT iN loss of
loaD, Damage To sTaNDs, aND/or failure resulTiNg iN
properTy Damage, persoNal or faTal iNJury.
CSE-1000A CSE-1000A
CSE-1000A_man_080807.indd 1
CSE-1000A SPECIFICATIONS
CSE-1000A
Engine Stand
Meets or exceeds ASME PALD-1997
standards for performance & safety.
This operaTing manual conTains imporTanT
safeTy informaTion.
read carefully and undersTand all
informaTion before operaTing This Tool.
save This manual for fuTure use.
do noT crawl under engine or place any parT
of your body under engine aT any Time during
mounTing of engine, use of sTand, or removal
of engine.
refer To engine service manual for correcT
lifTing poinTs, mounTing poinTs and mounTing
bolTs! mounTing bolTs should be Torqued aT
appropriaTe amounT To mainTain load.
1 1
1000 Lb.
Geared
