Fimco DMS-3PT-12V-4.5-TSC Owner's Manual

Owner's Manual
Model: DMS-3PT-12V-4.5-TSC (1014616)
Warranty/Parts/Service
For home usage, products are warranted for one year from date
of purchase against manufacturer or workmanship defects.
Commercial users have a 90 day warranty.
Your authorized dealer is the best source of replacement parts
and service. To obtain prompt, efficient service, always
remember to give the following information...
- Correct Part Description and/or part number.
- Model number/Serial number of your sprayer.
Part descriptions and part numbers can be obtained from the
illustrated parts list section(s) of this manual.
Whenever you need parts or repair service, contact your
distributor/dealer first. For warranty work, always take your
original sales slip, or other evidence of purchase date, to your
distributor/dealer.
(4.5 Cubic Ft, 3-Point, Dry Material Spreader)
General Information
Thank you for purchasing this product. The purpose of this
manual is to assist you in operating and maintaining your dry
material spreader. Please read it carefully, as it furnishes
information which will help you achieve years of trouble-free
operation.
This dry material spreader is used to spread all types of dry
material, such as fertilizer, seed, bait, powders, granular
insecticides, granular fungicides, granular herbicides, pellets,
and ice melting pellets.
Technical Specifications
• Hopper Capacity: 4.5 Cu. Ft.
• Spread Width: 5 Feet to 45 Feet
• 12 Volt Motor with Variable Speed Control (VSC)
• Stainless Steel 6-Blade Radial Fan
• Adjustable Slide Gate
• Approximate Shipping Weight = 53 lbs.
Operating Safely
Read this owner's manual before you assemble or operate the
Dry Material Spreader.
Use eye, hand, and breathing protection appropriate to the
materials that you are spreading. Read the manufacturers or
suppliers labels for proper protective equipment
Read and follow the manufacturers' instructions and notes for
spreading and handling materials used for spreading.
Do not allow anyone to ride on or sit with you while operating
the spreader.
Do not modify Dry Material Spreader or safety devices and
guards.
Assembly
1. Remove all parts and hardware packages from the carton.
Lay out all parts and hardware and identify using the
illustrations later in this manual.
2. Any additional assembly of loose parts should be
assembled onto the spreader per the exploded view drawing.
www.fimcoindustries.com
1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049
Toll Free Phone: 800-831-0027 : Toll Free Fax: 800-494-0440
Form No. 2055 [5008330 (10/11)] Printed in the U.S.A.
