PROGRAMMABLE LOOP POWERED, CURRENT OUTPUT, INDUSTRIAL
Model Number
649A04
Performance
Measurement Range(Velocity)
Measurement Range(Acceleration)
Measurement Range(Displacement)
Output(± 5 %)
Output(± 10 %)
Frequency Range(-6 dB)
Frequency Range
Frequency Range
Frequency Range
Frequency Range
Frequency Range
Environmental
Temperature Range
Electrical
Excitation Voltage
Settling Time(within 2% of value)
Electrical Isolation(Case)
Physical
Size (Hex x Height)
Weight
Mounting Thread
Mounting Torque
Sensing Element
Sensing Geometry
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
Electrical Connections(Pin A)
Electrical Connections(Pin B)
[11]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
VIBRATION SENSOR
ENGLISH SI
0.5 to 3 in/sec pk 12.7 to 76.2 mm/s pk
1 to 10 g pk 9.8 to 98.1 m/s² pk
4 to 20 mil pk - pk 0.1 to 0.5 mm pk - pk
4 mA 4 mA
20 mA 20 mA
180 to 60,000 cpm 3 to 1000 Hz
180 to 300,000 cpm 3 to 5000 Hz
180 to 600,000 cpm 3 to 10,000 Hz
600 to 60,000 cpm 10 to 1000 Hz
600 to 300,000 cpm 10 to 5000 Hz
600 to 600,000 cpm 10 to 10,000 Hz
-40 to +185 °F -40 to +85 °C
15 to 30 VDC 15 to 30 VDC
<30 sec <30 sec
8 8
>10 Ohm >10 Ohm
1.0 in x 2.6 in 25.4 mm x 66 mm
4.6 oz 129 gm
1/4-28 UNF No Metric Equivalent
3 to 5 ft-lb 4 to 7 Nm
Ceramic Ceramic
Shear Shear
Stainless Steel Stainless Steel
Welded Hermetic Welded Hermetic
2-Pin MIL-C-5015 2-Pin MIL-C-5015
Top Top
4-20 mA Pos (+) 4-20 mA Pos (+)
4-20 mA Neg (-) 4-20 mA Neg (-)
[1][2][3][4]
Optional versions have identical specifications and accessories as listed for the standard model
[5][2][4]
except where noted below. More than one option may be used.
[6][2][4]
M
- Metric Mount
Supplied Accessory : Model M081A61 Mounting Stud 1/4-28 to M6 X 1 (1) replaces Model
081A40
[7][8][4][9]
[7][8][4]
RV
- Buffered Analog Signal Output - 100 mV/g (±20%)
[7][8][4]
Electrical Connector
[4][7][8]
Electrical Connections(Pin A)
[7][8][4]
Electrical Connections(Pin B)
[7][8][4]
Electrical Connections(Pin C)
NOTES:
[1] Conversion Factor 1 in/sec = 25.4 mm/sec.
[2] FS - Full Scale.
[3] Factory set, 1 in/sec peak.
[4] USB Programmable with 600A21 kit.
[5] Conversion Factor 1g = 9.81 m/s².
[10]
[6] Conversion Factor 1 mil = 0.0254 mm
[7] Current will fluctuate at frequencies below 5 Hz.
[8] 1Hz = 60 cpm (cycles per minute).
[9] Factory Set
[10] Typical.
[11] See PCB Declaration of Conformance PS124 for details.
SUPPLIED ACCESSORIES:
Model 081A40 Mounting Stud (1)
Entered: AP Engineer: LAB
Date: 1/14/2014 Date: 1/14/2014
3425 Walden Avenue, Depew, NY 14043
Revision: B
ECN #: 42229
OPTIONAL VERSIONS
3-Pin MIL-C-5015 3-Pin MIL-C-5015
4-20 mA Pos (+) 4-20 mA Pos (+)
4-20 mA Neg/Signal Output 4-20 mA Neg/Signal Output
Neg Neg
Signal Output Pos Signal Output Pos
Sales: SA Approved: NJF
Date: 1/14/2014 Date: 1/14/2014
Phone: 800-959-4464
Fax: 716-684-3823
E-Mail: imi@pcb.com
Spec Number:
45987
