Epson PowerLite 74c Specifications page 2

Epson PowerLite 74c Specifications
Projection System
Projection Method
LCDs
Size 0.7"
Driving method Epson high-temperature Poly-silicon TFT
Active Matrix
Pixel number 786,432 dots x 3 (1024 x 768) LCDs
Native resolution XGA
Aspect ratio 4:3 (supports 16:9, 5:4)
Pixel arrangement Stripe
Projection Lens
Type Manual: zoom/focus
F-number 1.70 - 1.87
f-number 21.3 - 25.6mm
Zoom ratio 1.0:1.2
Lamp
Type 200W UHE
Life* (typical) 2000H
(High Brightness)
Screen Width Ratio
(Distance/Width)
Screen Size
(Projected Distance)
Keystone Correction Vertical: ±15 degrees, Auto Keystone Correction
Brightness 2000 ANSI lumens, 1500 ANSI lumens
(Typical)
Contrast Ratio
(High Brightness)
Brightness Uniformity
(Typical)
Color Reproduction
Audio Output
Operating Temperature
Power Supply Voltage 100-120V/200-240V ±10%, 50/60Hz AC
Power Consumption
Dimensions
(Includes lens and feet)
Dimensions
(Excludes lens and feet)
Weight
Fan Noise
Effective Scanning Frequency Range
Pixel clock
Horizontal
Vertical
Remote Control
Features Keystone, source selection, power, page up/
page down, color mode, zoom, a/v mute,
freeze
Operating angle Right/Left ± 30 degrees
Upper/Lower ± 15 degrees
Operating distance 20 ft (6m)
RGB
Analog RGB I/O
Display performance
Native 1024 x 768
Resize 1600 x 1200
1280 x 1024
800 x 600
640 x 480
Input terminal
Video Mini D-sub 15 pin x 2
Audio Stereo mini jack
Output terminal
Video Mini D-sub 15pin
(monitor out)
®
EPSON
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
3771 Victoria Park Avenue, Toronto, Ontario M1W 3Z5
Specifications and terms are subject to change without notice. Epson is a registered trademark of Seiko Epson Corporation. PowerLite is a registered trademark, SizeWise is a trademark, and Epson Connection,
PrivateLine and Presenters Online are service marks of Epson America, Inc. All other product and brand names are trademarks and/or registered trademarks of their respective companies. Epson disclaims any and
all rights in these marks. © Copyright 2003 Epson America, Inc. CPD-16544R1 15K 9/03 CL
Epson original LCD technology
Front/rear/ceiling mount
, 3000H
(Low Brightness)
1.48 to 1.71:1
30" to 300" (0.9m to 10.5m)
(Low Brightness)
500:1
85%
24 bit; 16.7 mil
1W Monaural
41ºF to 95ºF (5ºC to 35ºC)
280W, 3W at sleep mode
9.45" x 12.41" x 3.43"
9.45" x 12.41" x 3.82"
6.4 lb/2.9kg
38db, 33db
(Low Brightness)
13.5MHz to 162MHz
15KHz to 92KHz
50Hz to 85Hz
Video I/O
Display performance NTSC: 550 line
PAL: 550 line
(depends on observation of the
multi burst pattern)
Input signal NTSC/NTSC4.43/PAL/M-PAL/
N-PAL/PAL60/SECAM
HDTV: 480i, 480p, 720p, 1080i
Input terminal
Video Composite video: RCA (Yellow) x 1
S-Video: Mini DIN
Component video: Mini D-sub 15pin
(in common with Analog RGB connector) x 2;
Video-RGB: Mini D-sub 15pin (in common
with Analog RGB connector) x 2
Audio Stereo mini jack
Audio signal 500m Vrms/47Kohm
Control I/O
I/O terminal USB connector type B
Serial: Mini D-sub 9pin, RS-232C
Security Kensington
Supplied Accessories
Power cable, card type remote control with lithium battery, computer cable,
RCA video cable, USB A/USB B Mouse Cable, Start Here Kit, soft carrying case
Product/Accessory Part Numbers
Epson PowerLite 74c Projector
Replacement lamp
Air Filter Set
Replacement remote control
Samsonite wheeled soft case for projector and laptop
Samsonite Notebook/projector soft shoulder bag
ATA molded hardshell case
Ceiling mount
Suspension adapter
False ceiling plate
Component video cable
S-Video cable
Mac adapter set
50" portable screen
60" portable pop-up screen
80" portable pop-up screen
High resolution document imager
High resolution document camera
Kensington security lock
Warranty
Two-year limited warranty, 2-year international warranty, 90-day lamp warranty,
Epson Road Service Program and Epson PrivateLine dedicated toll-free
support (U.S. and Canada only)
Support–The Epson Connection
SM
Pre-Sales Support U.S. and Canada
Automated Technical Support
Internet Web Site
SM
*Lamp life results will vary depending upon mode selected, environmental conditions, and usage.
® -style lock provision
V11H136020
V13H010L27
V13H134A05
V12H007T13
ELPKS35-S
ELPKS43
ELPKS45
ELPMB39
ELPMBAPL
ELPMBFCP
ELPKC19
ELPSV01
ELPAP01
ELPSC06
ELPSC07
ELPSC08
ELPDC02
V12H064020
ELPSL01
800-463-7766
800-922-8911
www.epson.com
presentersonline.com
Printed on Recycled Paper
