RCS -433MDT2 Operation User's Manual

RCS-433MDT2
Thank you for choosing a RCS transmitter. It is recommended
that you read this manual carefully before using the transmitter.
CONTENTS
1 - TRANSMITTER INTRODUCTION
1A - General Information
1B - Technical Specifications
1C - Main Features
1D - Model Types
2 - CODING
3 - MEMORIZATION
4 - BATTERY AND DIP-SWITCH ACCESS
5 - TROUBLESHOOTING
All manuals and user guides at all-guides.com
1 - TRANSMITTER INTRODUCTION
1A - General Information
1B - Technical specifications
• The radio control, RCS-433MDT2 has been designed for the
control of automatic closing systems and anti-burglar systems.
The operating frequency is 433,92 MHz.
• The receiver can be used to control automatic gates, rolling
shutters, awnings, anti-burglar appliances, lighting etc.
• The transmitter security code is obtained by means of a
9 way three-state dip-switch, which allows up to 19683 codes
combinations. All the receivers can store up to 50 different
dip-switch code combinations.
• Each transmitter (or its different keys) can be stored into
different receivers and hence can do more functions.
• In order to use the unused keys of the transmitter connect the
dedicated receiver to the mechanism to drive (i.e. electro lock
of a pedestrian gate, a buzzer, etc. ).
• The product fully complies with Part 15 of FCC Regulations.
Number of keys: . . . . . . . . . . . . . . . . . . . . . . . . . .2
Battery duration: . . . . . . . . . . . . . . . . . .12 - 24 months
Battery type: . . . . . . . . . . . . . . . . . . . . . . . .23A (L1028)
Current consumption: . . . . . . . . . . . . . . . . . . . . .25 mA
Operating frequency: . . . . . . . . . . . . . . . . .433.92 MHz
Security code combinations number: . . . . . . . . .19683
Modulation: . . . . . . . . . . . . . . . . . . . . . . . . . . .AM/ASK
E.r.p.: . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50 - 100 uW
Range in open space: . . . . . . . . . . .from 100 to 200 m
Operating temperature: . . . . . . .from -10 °C to +55 °C
Dimensions: . . . . . . . . . . . . . . . . . . . . .1.75 x 1 x .3 in.
Weight: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..7 oz.
