HL-EL070RC
Manual
Before using the light, read this manual
thoroughly and keep it for future reference.
Design Pat. Pending
Copyright© 2016 CATEYE Co., Ltd.
3
HLEL070RC-161006
PRECAUTIONS ON USE
• Before your trip, please make sure the light is firmly
mounted to the bracket, it lights up, and the light is
not blocked by baggage, etc.
• Do not place it within children's reach.
• In preparation for unexpected battery shutoff, we
recommend you carry a spare light.
• Mounting the light unit too close to a wireless
computer may adversely affect the reading of the
computer.
• Charging, discharging, and storing in high tempera-
tures will cause the rechargeable battery to
deteriorate faster.
Do not place the light inside a vehicle or near a
heater.
• This product is water-resistant under normal daily
use and can be used in the rain. However, do not
intentionally submerge it in water.
• If the light unit or parts become dirty with mud, etc.,
clean with a soft cloth which is moistened with mild
soap.
Never apply paint thinner, benzine or alcohol;
damage will result.
PRECAUTIONS ON CHARGING
• We recommend using 500+mA (USB2.0) USB battery
charger.
• Avoid charging in direct sunlight or in a vehicle
parked under direct sunlight, and make sure to
charge only when the ambient temperature is
between 5 and 40°C (41°F and 104 °F).
• Before charging, be sure that no dust or other foreign
objects attach to the USB plug.
• Do not subject the light to vibrations while charging.
• When your PC is in sleep state, the unit cannot be
charged.
• Once charging is complete, be sure to disconnect the
USB plug.
• Charging and lighting times are approximate values,
and will vary by environmental and user conditions.
• If the illumination time is significantly reduced even
after proper charging, the rechargeable battery may
be nearing the end of its service life. Dispose of the
battery as described in "PRECAUTIONS ON
DISPOSAL".
PRECAUTIONS WHEN MOUNTING
Check periodically to ensure that the light unit is
attached securely. Do not use a damaged rubber band.
STORAGE PRECAUTIONS
Cool and dry storage is recommended.
For long period storage, it is important to charge the
battery 30 minutes every 6 months.
PRECAUTIONS ON DISPOSAL
When disposing of the light unit, remove the internal
rechargeable battery and dispose of it according to
local regulations.
1
ENG
HOW TO CHARGE
Always charge the product before use.
3.6 v
Charge jack cover
USB cable
2
To PC or USB battery charger
2
HOW TO MOUNT
Attach securely in the mounting position.
Rubber band
ø
22 mm 〜
ø
32 mm
〜
3
SWITCH OPERATION
Switch
1.5 h
Approx.
( 400 lm )
High
High
*1 When you turn the light on, it lights up in the last lighting mode you used. (Mode memory function)
* When the switch (indicator) lights up, the remaining battery power is 20% or less. Please charge as soon as possible.
1
1
Hook
Press and hold
OFF
OFF
ON
( *1 )
10 h
Approx.
Approx.
( 100 lm )
( 400 / 100 lm )
Low
Low
Switch (Indicator)
Charging is
Charging
completed
Standard
charging time
360°
This light rotates 360 degrees
to adjust angle.
Double-click
1.5 h
Approx.
( 400 lm )
High
High
10 h
100 h
Approx.
( 100 lm )
HyperConstant
HyperConstant
Flashing
Flashing
7h
Approx.
( USB 2.0 )
2
Click
