IMPORTANT: Please read these instructions carefully.
Note the safe operational requirements, warnings, and cautions.
Use this product correctly, and with care for the purpose for which it is intended.
Failure to do so may cause damage and / or personal injury and will invalidate the warranty.
1. INTRODUCTION
This powerful and compact cordless polishing machine is made for polishing of small surfaces. This
well-balanced tool has a speed setting and comes with battery and charger.
2. SPECIFICATION
No-Load Speed:
approx. 1500 - 3000 rpm (stepless adjustable)
Pad diameter:
100 mm
Machine weight:
approx. 820 g
LpA: 71 dB(A) / KpA: 3 dB
Noise level:
LwA: 82 dB(A) / KwA: 3 dB
ah= 2.68 m/s²
Vibration:
K= 1.5 m/s²
Battery pack:
10,8 V Li-ion / 1.3Ah
Mains charger:
Input: 100 - 240 VAC / 50 – 60 Hz / 30 W
Shaft thread:
M10
SW-Stahl und Werkzeugvertriebs GmbH
L
e
v
e
k r
u
s
r e
t S
a r
s
s
e
6
5
D
4 -
2
8
9
7
R
e
m
s
c
h
e
d i
Cordless Polishing Machine
Tel. +49 (0) 2191 / 46438-0
F
ax +49 (0) 2191 / 46438-40
- E
M
a
: l i
n i
o f
@
s
w
s
a t
l h
d .
e
Art. 9259
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BGS technic 9259
Summary of Contents for BGS technic 9259
- Page 1 Art. 9259 Cordless Polishing Machine IMPORTANT: Please read these instructions carefully. Note the safe operational requirements, warnings, and cautions. Use this product correctly, and with care for the purpose for which it is intended. Failure to do so may cause damage and / or personal injury and will invalidate the warranty.
- Page 2 3. SAFETY INSTRUCTIONS 3.1. GENERAL SAFETY Follow all workshop safety rules, regulations and conditions when using the cordless tool. Remove the battery pack from the cordless tool before servicing or performing any maintenance. Maintain the cordless tool and battery pack in good condition. Check moving parts for alignment on a regular basis.
- Page 3 3.3. MAINS POWER ELECTRICAL SAFETY (In relation to the battery charger) WARNING! It is the responsibility of the owner and the operator to read, understand and comply with the following: Ensure that the insulation on cables is safe before connecting it to the power supply. Do not pull or carry the appliance by the power cable.
- Page 4 4.2. CHARGING THE BATTERY PACK 4.2.1. Remove the battery pack from the wrench, by depressing the two side retaining clips (fig.1). WARNING! Do not touch metal terminals. 4.2.2. Place the cordless tool to side and take the battery charger. 4.2.3. The battery pack and charger have the positive (+) and negative (-) terminals marked. Align the correct terminals and insert the battery into slot (fig.3 &...
- Page 5 Test Report No.: 160302169SHA-001 / Charger: 160302169SHA-001 08.11.2016 Wermelskirchen, den ppa. Frank Schottke, Prokurist BGS technic KG, Bandwirkerstrasse 3, D-42929 Wermelskirchen SW-Stahl und Werkzeugvertriebs GmbH Tel. +49 (0) 2191 / 46438-0 ax +49 (0) 2191 / 46438-40 : l i...
