DOBLO'
USER MANUAL MULTIMEDIAL SYSTEM

Advertisement

Table of Contents
loading

Related Manuals for Fiat DOBLO'

Summary of Contents for Fiat DOBLO'

  • Page 1 DOBLO’ USER MANUAL MULTIMEDIAL SYSTEM...

  • Page 2: Tips, Controls And General Information

    TIPS, CONTROLS AND GENERAL INFORMATION ROAD SAFETY Learn how to use the various system functions before setting off. Read the instructions for the system carefully before setting off. WARNING It can be dangerous if the volume is too high. Adjust the volume so it can still be heard background noises (e.g.

  • Page 3: Front Panel Controls

    Video Codec Name Profile Level Limitation Simple Profile For Advanced Simple profile, only MPEG4 one point GMC is supported. Advanced Simple Profile For Baseline profile with SGM, Baseline profile the width limitation is 1280. H264 L 4.1 Main profile For Baseline profile without SGM, the width limitation is 4096.
  • Page 4 Button Function Description Press the button to turn on the device, press and hold for 2 Switching On/Off, seconds to turn it off. Increase or decrease the volume via Volume Adjustment & turning the knob left or right respectively. Press the button to go Back to Main Menu back to main menu in any selected menu.

  • Page 5: Steering Wheel Controls

    STEERING WHEEL CONTROLS Button Function Description Press the button for the activation/deactivation of the volume. To cut off the microphone device during BT (Bluetooth®) call, press the button to activate mute function. This allows to hear Mute Button the interlocutor but not being heard from it. Press the mute button again to deactivate the function.
  • Page 6 Radio Mode Selection In radio main screen, press RADIO button on the front panel or “FM/AM, AM/DAB (if available), DAB (if available)/FM” to switch to the bands AM,FM and DAB (if available). Each tuning mode can have a specific preselection set. Radio Station Selection In radio main screen turn button/knob or press...
  • Page 7 AM/FM/DAB (if available) Radio Station Tuning Press the icon to enter Direct Tune menu. The graphic keyboard on the display is used to enter the frequency of the station. In this mode, use buttons + and – to fine-tune the frequency. Press button to delete a wrong number (and enter the correct station frequency).

  • Page 8: Media Mode

    All stations Press “all stations”, to see all the DAB (if available) broadcasts. Genres Press “Genres”, to choose various types of DAB (if available) radio programs, such as weather, finance, children, religion, etc. Ensembles Press “Ensembles”, to scroll through the DAB (if available) ensembles groups MEDIA MODE Press MEDIA button located on the faceplate or press the icons on the home page to activate media...

  • Page 9: Song Information

    To play audio/photo files via USB, the corresponding device must be connected to the USB port on the radio, if needed via a required cable (only in the case of device other than USB stick). When a USB / iPod device is plugged in while the system is on, tracks stored on USB/iPod are available to play.
  • Page 10 Shuffle Press button to play the tracks in a random order. Press again to deactivate this function. Shuffle function can be available only if the USB or Bluetooth® device supports this function. Repeat Song Press button repeatedly to cycle between Repeat One, Repeat All and Repeat OFF in loop. Repeat function can be available if the USB or Bluetooth®...

  • Page 12: Phone Mode

    PHONE MODE Activating Phone Mode Press PHONE button on the front panel or the button on the main screen to activate phone mode. Key Features: ➢ Dialing the number of the person wanted to be called. ➢ Contacts on the phone book of the cell phone can be viewed and called. ➢...
  • Page 13 ➢ Activate Bluetooth® function of the mobile phone. ➢ Press PHONE button of the radio in front panel . ➢ Press Button. ➢ Press the button to start the pairing process. ➢ Search for “FIAT_XXXX” on mobile phone . ➢ If the pairing process doesn’t go automatically enter the PIN code that is displayed on the screen of the radio, using the mobile phone, after mobile phone requires it.
  • Page 14 If your mobile phone has a function for sending the phonebook via Bluetooth® technology, during the pairing procedure a pop-up screen will appear with the following request. Answer "Yes" to copy the whole phonebook and the list of recent calls to the system. Answer "No" to carry out the operation later.
  • Page 15 After the first phone data transmission, the procedure for transmitting and updating the phonebook (if supported) starts as soon as a Bluetooth® connection is established between mobile phone and system. This downloaded phonebook cannot be edited on the multimedia system. It can only be edited on the mobile phone.
  • Page 16 Deleting A Phone or Audio Device To delete a mobile phone or Bluetooth® audio device from a list, proceed as follows: ➢ Press the PHONE button on the front panel. ➢ Select button on the display. ➢ Select the specific device from the "Paired Devices List”. ➢...

  • Page 17: Phone Call Features

    PHONE CALL FEATURES The following features can be accessed through the Multimedia system if the feature(s) are available and supported by Bluetooth® on your mobile service plan. For example, if your mobile service plan provides three-way calling, this feature can be accessed through the Multimedia system. Check with your mobile service provider for the features that you have.
  • Page 18 Dialing the phone number using the "keypad" button Enter the phone number using the graphic keyboard displayed. Proceed as follows: ➢ Press the button on the touchscreen in Phone Main Menu; ➢ Use the numbered buttons to enter the number; ➢...
  • Page 19 Answering an incoming call during an active conversation To answer an incoming call while another phone conversation is in progress, press the "Hold” button to put the ongoing call on hold and answer the new incoming call. Press “Reject” button to close the ongoing call and answer the new incoming call. Press “Ignore”...
  • Page 20 Managing two Phone Calls If two calls are in progress (one active and one on hold), it is possible to switch between them pressing the "Switch”" button or to merge the two calls in a conference pressing the "Join" button. Note Check whether the telephone in use supports the management of a second call and the "Conference"...

  • Page 21: Activation/Deactivation Of The Microphone

    Continuing a Phone Call After the engine is switched off, if in the power off delay setting it is selected the 20 minutes option it is still possible to continue a phone call. The call continues until it is ended manually or for a maximum period of about 20 minutes.
  • Page 22 WARNING! When Apple Car play/Android Auto apps are enabled by the user, the scrolling function via rotary knob is not available. Android Auto APP Setup Before use, download the Android Auto application to your smartphone from Google Play Store. The application is compatible with Android 5.0 (Lollipop) and later versions.
  • Page 23 To return to the system contents with the Android Auto app enabled select the last item on the Android Auto system bar and select “Back to Fiat". To end the Apple CarPlay or...
  • Page 24 APP navigation (if available) settings Align to the navigation applications, the driver can use the navigation system to plan and navigate. For more details on how to use this application, refer to the navigator user manual. WARNING When the navigation system is activated is not possible to scroll the lists by the rotary.
  • Page 25 RVC (if available) Align in reverse gear (R) and your display will automatically show the rear of your car. RVC will be shown when the radio is in stand by. WARNING Check the rear door has been closed, before to use the rear view camera. Settings Press button to enter the Settings menu.
  • Page 26 Touch Sound Press the relevant button to activate/deactivate the acoustic signal when the buttons on the display are pressed. Loudness To activate/deactivate the "Loudness" function to improve the sound quality at low volumes.
  • Page 27 Equalizer Select "Equalizer" on the display to adjust the bass, middle and treble tones. Use the "+" or "–" buttons to carry out the settings desired. Tapping on the bass middle or treble bar also is possible to change the value. Then press button to return to the "Audio"...
  • Page 28 Volume Press the “Volume” button to enter into the volume settings interface and to adjust the volume of multimedia (music and radio), phone, ringtone and speech. WARNING If the user sets the volume level below 5 or greater than 25, on the next boot up these values will not be stored in the memory, and the radio will boot up with volume at level 5 (if the level was less than 5 when the radio was switched off) or at level 25 (if the level was greater than...
  • Page 29 Speed Volume Control "Off" and "1, 2 or 3". The option selected is displayed. Choose "1, 2 or 3" to increase the volume proportionally to vehicle speed. Then press button to return to the "Audio" menu. Press button to cancel and exit this screen. Radio Alternative Frequency and Traffic Announcement functions can be activated/deactivated under Radio settings.
  • Page 30 AF Setting Press the “AF Setting” button for activation/deactivation of the automatic tuning of the strongest signal for the currently broadcasted station. TA Setting Press the “TA Setting” button for activation/deactivation of the automatic tuning of the traffic announcements. DAB (if available) Announcements Press the "DAB (if available) announcements"...

  • Page 31: Android Auto

    Luminance Press the "Luminance" button to set the display brightness according to "Day", "Night" condition. AutoPlay AutoPlay is a feature of the multimedia system that automatically begins playing music of the USB device, as soon as it is connected. This feature can be turned on or off in this menu. Its default setting is on. Power Off Delay To keep the radio on for 20 minutes after the ignition key is turned to STOP.
  • Page 32 Restore Settings Reset the radio to the factory settings will erase all the settings previously defined by the user. Confirm to reset the device to the factory settings. Wait for a short time for the factory settings to be restored. Notes: Please read this manual thoroughly and keep this manual as a reference before the use of this device.
  • Page 33 RED Homologation information С настоящото Daiichi Elektronik San. ve Tic. A.S. декларира, че този тип Aš, Daiichi Elektronik San. ve Tic. A.S., patvirtinu, kad radijo įrenginių tipas D7131AD български Liettuviy радиосъоръжение D7131AD е в съответствие с Директива 2014/53/ЕС. atitinka Direktyvą 2014/53/ES. [Bulgarian] [Lithuanian] Цялостният...
