- Page 1 3PH ON-GRID solar inverter User Manual Grid-Connected PV Inverter IPSPV33-ONGI-4k0-KTSI IPSPV33-ONGI-5k0-KTSI IPSPV33-ONGI-6k0-KTSI IPSPV33-ONGI-8k0-KTSI IPSPV33-ONGI-10k0-KTSI IPSPV33-ONGI-13k0-KTSI IPSPV33-ONGI-16k0-KTSI...
-
Page 2: Table Of Contents
3PH ON-GRID solar inverter Legal Disclaimer ● No all or part of this document may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, without the prior written permission of our company. ● The products, services or features you purchased shall be subject to the commercial contract and terms. - Page 3 3PH ON-GRID solar inverter 5.2 Cable Requirements .......................... 13 5.3 DC Connection........................... 13 5.4 AC Connection ........................... 15 5.5 Second Protective Earth Connection ....................17 5.7 Connection of Anti-Backflow Meter (Optional) ................17 6 Installing the Communication Module ............... 20 7 Operation .........................
-
Page 4: General Information
Frame or chassis Refer to the manual terminal description Caution, risk of electric Warning of danger shock Danger alert electric shock. Energy storage timed discharge Caution, hot surface (time to be indicated adjacent to the symbol) www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... -
Page 5: Validity
● Carefully read the safety precautions in this manual. DANGER! Do not touch the contacts or terminals connected to the grid or the equipment, or it may result in electric shock to death or outbreak of a fire! www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... - Page 6 All operations and wiring must be made by qualified personnel only to ensure that all electrical installations meet the electrical installation standards. In order to ensure safe operation, the device should be grounded properly and provided with necessary short circuit protection. www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020...
-
Page 7: Product Overview
Monocrystalline silicon, polycrystalline silicon, and thin-film batteries with Ⅱ A PV modules level protection and no need to be grounded B Inverter 5kW/6kW/8kW/10kW/13kW/16kW C Electric meter Standard measuring tools for inverter output power TT, TN-C, TN-S, TN-C-S D Utility grid www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... -
Page 8: Schematic Diagram
RS485, GPRS and Wi-Fi. 2.3 Appearance of Inverter Description Explanation To display the inverter running state / communication ① LED display panel status ② DC input terminals To connect inverter to PV modules www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... -
Page 9: Weights And Dimensions Of Inverter
To fix the inverter on the wall mounting bracket 2.4 Weights and Dimensions of Inverter Dimensions (W×D×H) Inverters Weight 515 mm × 166.5 mm × 435 mm 5kW/6kW/8kW/10kW/13kW/16kW 25 kg Dimensions of 6kW/ inverter: 5kW/ 8kW/10kW/13kW/16kW www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... -
Page 10: Specifications
＜3%(rated power) ＜0.5%In Output current DC component ＞0.99(rated power) Power factor Power factor adjustable 0.8 leading～0.8 lagging EFFICIENCY Max.efficiency 98.65% European efficiency 98.2% PROTECTION DC switch Available DC reverse polarity protection Available Ground insulation resistance Available detection www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... -
Page 11: Unpacking And Storage
Notify the carrier and dealer If any damage is found or any component is missing. Scope of delivery: Designation Quantity Grid-Connected PV inverter 1 pcs User manual 1 pcs Quick guide 1 pcs PV input terminal 3 sets www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... -
Page 12: Storage
Do not tilt or invert the packaging box. After long-term storage, the inverter can’t be put into operation until the comprehensive inspection and testing is made by qualified personnel. www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... -
Page 13: Installation
(such as typhoons and monsoons) or terrains (such as dams and hills). CAUTION Ambient temperature range shall be -25°C to +60°C. It will affect the inverter output power when the temperature exceeds the limit. Environmental relative humidity must be in the range of 0% ~ 100%. www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... -
Page 14: Mounting The Inverter
2. Drill holes on the markings for them. 3. Secure the wall mounting bracket to the wall using expansion screws. Tighten the screws with a minimum torque of 30Nm, and M6 x 50 expansion bolts are recommended for use. www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... -
Page 15: Electrical Connection
5. The Wall mounting bracket reserved a padlock hole to prevent the inverter from being stolen. The anti-theft lock needs to be prepared by the user himself. 5 Electrical Connection 5.1 Safety Precautions DANGER! www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... -
Page 16: Cable Requirements
5.3 DC Connection DANGER ! Before electrical connection, cover the PV battery modules with light- proof material and disconnect the circuit breaker on the DC side. www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... - Page 17 2. Loosen the terminal cover and pass the cable through the terminal cover. Insert the die into the wiring slot till you hear a sound indicating that the connection is in place. Tighten the terminal cover (As shown in the figure below). www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu...
-
Page 18: Ac Connection
7 mm (As shown in the figure below). 2. Fix L1,L2,L3,N and PE wires to the corresponding AC terminals with a screwdriver and ensure that the PE wire is properly grounded (As shown in the figure below). www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... - Page 19 4. Push the locker onto the socket housing completely, then rotate the locker according to the direction instructed by the marks on the lock. CAUTION Making the inverter output cable and installation instructions is only for reference. Please note that IPSPV33-5-16KTSI output wiring is 3W + N + PE. www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020...
-
Page 20: Second Protective Earth Connection
Before using the anti-backflow function, the user should read the instructions carefully and correctly connect the cables as shown in the figure.Connection error may lead to unpredictable consequences, contact the maintenance personnel in this case. www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... - Page 21 (that is, close to the public power grid). The direction of the current transformer (CT) is from the user side to the public power grid side. Definition and wiring of the anti-backflow meter terminal are shown below. www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020...
- Page 22 CT-Live-C Black wire RS485-A No special requirements RS485-B No special requirements As shown in the above figure, the anti-backflow meter terminals 24 & 25 are separately connected to the pin 8 and pin 6 of COM2. www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020...
-
Page 23: Installing The Communication Module
The enlarged image of the meter communication interface and DRM communication interface is as shown below: Meter communication interface (COM2) is illustrated as follows: Definition Blank Blank DICOM1 DI 1 Blank Blank DRM communication interface (COM3) is illustrated as follows: www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... - Page 24 2. Insert the RJ45 crystal plug into the RJ45 port at the bottom of the inverter chassis then tighten the screw nut. 3. Tighten the sealing nut at the tail of the waterproof terminal. www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020...
-
Page 25: Operation
AC circuit breaker and the DC switch of the inverter if emergency shutdown is require. 7.3 LED Indicator Lights The current status of operating and communications of the inverter can be viewed via the three LED indicator lights on the panel (as shown in following table). www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... -
Page 26: Auto Test Function（For Italy
2. Connect the inverter communication interface of COM1 via transferring USB to RS-485 with computer. 3. Closed DC side circuit breaker and AC side circuit breaker. Start program of sunny bee, test function of auto test as following picture. www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... -
Page 27: Monitoring
This series of inverters doesn’t have an LCD display screen, therefore the wireless communication module is required to view the running state. Please refer to section 6 for the installation of wireless communication module. After installing the Wi-Fi www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu... -
Page 28: Professional Edition App
Registration: Enter App after downloading “solarmanPro”. Click on [Free Account], then enter registration information and follow [Next] procedures until [Applied], as shown below. Login: Click on [Log in] in the App home page, and enter your email and password. www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... - Page 29 Method 2: click the [Plant] icon first to enter the plant list, then click [+] in the upper right corner to add the plant, then scan the serial number of the stick logger. www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020...
- Page 30 Select your plant type. Select your grid type. Fill in plant capacity. (You many keep the default settings in the rest of blank because App has received local electricity prices and subsidies) www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020...
- Page 31 3PH ON-GRID solar inverter 3. Enter the plant name. It is suggested to create a plant name like “location + name + capacity”, then click on [Done]. 4. Then the plant you added is shown on the homepage. www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020...
-
Page 32: Home Edition App
Search “solarman” in Apple Store to download the App for iPhones, Search “solarman” in Google Play to download the App for Android phones. 8.2.2 Registration & Login Click on [Register] to create new account, and enter your email to register. www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... - Page 33 Select your plant type. Select your grid type. Fill in plant capacity. (You many keep the default settings in the rest of blank because App has received local electricity prices and subsidies) www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020...
-
Page 34: Troubleshooting For Fault Messages Displayed On App
Fault Messages Description Corrective Action Grid overvoltage / Voltage on AC side Check if the grid voltage is within the exceeds the allowable allowable range. Contact the local undervoltage range operation and maintenance personnel for any help. www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020... - Page 35 Leakage current Leakage current Check the connection of PV arrays abnormality exceeds the allowable and earth wire, then restart the value inverter. Contact the local operation and maintenance personnel for any help. www.ips-ups.eu IPSPV33-ONGI-manual_ENG-R0 info@ips-ups.eu 7.10.2020...
