IPS home inverters with UPS function
Suitable for UPS:
-
IPS300-SIN
-
IPS300-SIN-WM
-
IPS300-SIN-DC
-
IPS600-SIN
-
IPS600-SIN-WM
-
IPS600-SIN-DC
-
IPS1000-SIN
-
IPS1000-SIN-DC
-
IPS1600-SIN
-
IPS1600-SIN-DC
-
IPS2500-SIN
-
IPS3500-SIN
www.ips-ups.eu
1
info@ips-ups.eu
IPS home inverter manual
USER MANUAL
4.09.2017
IPS-home-inverter-manual_ENG-R1
Advertisement
Table of Contents
Related Manuals for IPS IPS300-SIN
Summary of Contents for IPS IPS300-SIN
- Page 1 IPS home inverter manual USER MANUAL IPS home inverters with UPS function Suitable for UPS: IPS300-SIN IPS300-SIN-WM IPS300-SIN-DC IPS600-SIN IPS600-SIN-WM IPS600-SIN-DC IPS1000-SIN IPS1000-SIN-DC IPS1600-SIN IPS1600-SIN-DC IPS2500-SIN IPS3500-SIN www.ips-ups.eu 4.09.2017 info@ips-ups.eu IPS-home-inverter-manual_ENG-R1...
-
Page 2: Table Of Contents
IPS home inverter manual Table of Contents 1 Safety Information ....................1 2 Product Overview ....................4 2.1 Specifications ....................4 2.2 Front panel features ..................6 2.3 Rear panel features ..................6 3 Installation Instructions ..................8 3.1 Unpacking Inspection................... 8 3.2 Installation .................... -
Page 3: Safety Information
IPS home inverter manual Models quick description IPS300-SIN IPS300-SIN-DC Standalone metal case IPS600-SIN IPS600-SIN-DC with DC output and PV IPS1000-SIN IPS1000-SIN-DC Standalone metal input case IPS1600-SIN IPS1600-SIN-DC IPS2500-SIN IPS300-SIN-WM Wall mounted metal case IPS3500-SIN IPS600-SIN-WM 1 Safety Information CAUTION Non-qualified electricians are forbidden to open the case due to hazard of electrical shock. -
Page 4: Product Overview
IPS home inverter manual 2 Product Overview 2.1 Specifications MODEL 300W 600W 1000W 1600W 2500W 3500W DC Input (the inverter must be connected to batteries to work properly) Nominal input voltage DC input range 10 ~ 15V 20 ~ 30V... - Page 5 IPS home inverter manual Max. PV input 40 V 60 V voltage(Voc) PV optimum operating 18 V ~ 32 V 29V ~ 48 V voltage(Vmp) 120W / 240W / 240W / 480W / Max.PV. power 360W / 480W 720W / 960W DC Outputs (for –DC series only)
-
Page 6: Front Panel Features
IPS home inverter manual 2.2 Front panel features 300W ~ 1600W front panel 300W ~ 600W front panel Tower type Wall mounted type 2500W ~ 3500W front panel 2.3 Rear panel features 300W ~ 1600W rear panel ① AC input socket ②... - Page 7 IPS home inverter manual ⑧ DC output fuse ⑨ MPPT (optional) ⑩ DC output (optional) Optional model (with MPPT / DC modules 2500W ~ 3500W rear panel ① Input/output terminal block ② Overcurrent protector ③ Battery breaker ④ Buzzer for battery reverse ⑤...
-
Page 8: Installation Instructions
IPS home inverter manual 3 Installation Instructions 3.1 Unpacking inspection Inspect the contents upon receipt. Notify the carrier and dealer if the unit is damaged. 300W ~ 1600W package contents Operation manual 300W ~ 1600W Inverter AC input power cords... - Page 9 IPS home inverter manual 3.2.2 Connect external battery 300W / 600W / 1000W inverter battery connection Optional model (with MPPT modules (Note that the red cable is connected to the positive terminal, black cable is connected to the negative terminal)
-
Page 10: Operations
IPS home inverter manual 4 Operations CAUTION Turn on the inverter in battery mode first. Be sure that the load has no problem (overload, short-circuit ect.) before connecting to utility power. 4.1 Turn the inverter On/Off Without connecting to utility power, press and hold “ON” button for 3 seconds, release it until the buzzer beeps, the inverter starts up. - Page 11 IPS home inverter manual In normal mode and starting state, press “OFF” button to mute. If there is failure and failure is solved, press “OFF” button first and release it to press “ON” button, and restart the inverter for normal use.
- Page 12 IPS home inverter manual INLS: Inverter no-load shutdown function Note: If select “Y”, check whether the Y / N configured load rate in “ Inverter shutdown load rate” is correct or not, if not, change it. (option) INLS: Setting of the load rate of UPS...
-
Page 13: Troubleshooting
IPS home inverter manual 4.4 Troubleshooting This section lists the status and alarm messages that the UPS might display. A suggested corrective action is listed with each display message to help you troubleshoot problems. Problem Display Corrective Action Description Message AC output short Check if the load is short circuited. - Page 14 IPS home inverter manual Contact the dealer or supplier from whom it Soft-start fault was purchased. BUS voltage is too high (Battery Check the battery voltage. Contact the is overchargered dealer or supplier if the problem persists. ） Charging over-...
