P/N 901008-00 Rev. NC 07/2019
Ce manuel est disponible en francais, simplement
en faire la demande. Numéro de la pièce 901008-02.
P901008-00
This book is valuable. In addition to instructing you on how to install and maintain your appliance, it also
contains information that will enable you to obtain replacement parts or accessory items when needed. Keep
it with your other important papers.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
This wood burning fireplace complies with UL127
CAN/ULC-S610-M87 standard as a FACTORY
BUILT FIREPLACE.
This fireplace is approved for use as a wood burning fireplace or for use with a vented gas log approved to
ANSI Z21.60 or Z21.84 standards or for use with a vent-free gas log heater approved to ANSI Z21.11.2 standard .
FOR CANADA: The authority having jurisdiction
(such as the municipal building department, fire
department, etc.) should be contacted before
installation to determine the need to obtain a permit.
This installation manual will enable you to obtain a safe, efficient and dependable installation of your fireplace
system. Please read and understand these instructions before beginning your installation.
Do not alter or modify the fireplace or its components under any circumstances. Any modification or alteration of
the fireplace system, including but not limited to the fireplace, chimney components and accessories, may void the
warranty, listings and approvals of this system and could result in an unsafe and potentially dangerous installation.
IMPORTANT! TO ASSURE PROPER ALIGNMENT OF GLASS DOORS: INSTALL THIS FIREPLACE IN A SQUARE
AND PLUMB CONDITION, USING SHIMS AS NECESSARY AT SIDES AND/OR BOTTOM.
PFS
C
REPORT NO. F09-095
SAVE THIS BOOK
NOTE: DIAGRAMS AND ILLUSTRATIONS THROUGHOUT THE MANUAL ARE NOT TO SCALE.
Installation and Operation Instructions
Outdoor Wood-Burning Fireplace
®
US
WRE6036
Installateur : Laissez cette notice avec l'appareil.
Consommateur : Conservez cette notice pour consultation ultérieure.
Ce foyer au bois est conforme aux UL 127 CAN/ULC-
S610-M87 norme comme une USINE CONSTRUITE
CHEMINÉE.
POUR LE CANADA: L'autorité compétente (comme le
service municipal du bâtiment, les pompiers, etc.) doit
être contacté avant l'installation afin de déterminer la
nécessité d'obtenir un permis.
Models
WRE6042
WRE6050
Advertisement
Table of Contents
Related Manuals for Superior WRE6036
Summary of Contents for Superior WRE6036
- Page 1 Outdoor Wood-Burning Fireplace P/N 901008-00 Rev. NC 07/2019 Models Ce manuel est disponible en francais, simplement ® en faire la demande. Numéro de la pièce 901008-02. WRE6036 WRE6042 WRE6050 REPORT NO. F09-095 P901008-00 SAVE THIS BOOK This book is valuable. In addition to instructing you on how to install and maintain your appliance, it also contains information that will enable you to obtain replacement parts or accessory items when needed.
-
Page 2: Table Of Contents
Thank you for your purchase. We appreciate your TABLE OF CONTENTS business! Safety .....................2 Please carefully read and follow all instructions in this manual. Pay Specifications .................4 special attention to all warnings and safety information. Fireplace Installation ..............7 Following these safety, care, and operation instructions will help Venting Installation ................9 ensure many years of dependable and enjoyable service from your Mosaic Brick Panel and Estate Refractory Panel Installation..16... - Page 3 SAFETY Continued WARNING: CONTINUED OVERFIRING CAN PER- WARNING: BURNING IMPROPER FUEL (I.E. CHAR- COAL) CAN RESULT IN CARBON MONOXIDE POISON- MANENTLY DAMAGE YOUR FIREPLACE SYSTEM. ING, WHICH MAY LEAD TO DEATH! SOME EXAMPLES OF CONDITIONS THAT COULD CAUSE OVERFIRING ARE: Carbon Monoxide Poisoning –...
-
Page 4: Specifications
" 7" (267 mm) (178 mm) (242 mm) " 36" (915 mm) " (115 mm) (89 mm) 11" 1" (26 mm) " (1159 mm) (280 mm) " (185 mm) " (388 mm) Figure 1 - 36" Model WRE6036 SuperiorFireplaces.us.com 901008-00_NC... - Page 5 SPECIFICATIONS Continued 42" MODEL " (775 mm) " (578 mm) " (400 mm) " (670 mm) 29" (737 mm) 23" " (585 mm) (553 mm) " (Ref.) (448 mm) " (32 mm) " (1051 mm) 42" HEARTH " (16 mm) "...
- Page 6 SPECIFICATIONS Continued 50" MODEL " (978 mm) 24" (610 mm) " " (489 mm) (874 mm) " " 23" (724 mm) (553 mm) (585 mm) (Ref.) " (448 mm) " " (32 mm) (1255 mm) 50" HEARTH " (112 mm) 67"...
-
Page 7: Fireplace Installation
FIREPLACE INSTALLATION SELECTING LOCATION raised platform, a Z-type ember protector (not supplied) must be fabricated to fit your required platform height. Ember protector To determine the safest and most efficient location for the fireplace, should extend under fireplace a minimum of 1 ". - Page 8 FIREPLACE INSTALLATION Continued HEARTH EXTENSION MANTELS A hearth extension projecting a minimum of 20" in front of and a A mantel may be installed if desired (see Figure 7). Woodwork such as minimum of 12" beyond each side of fireplace opening is required wood trims, mantels or any other combustible material projecting from to protect combustible floor construction in front of fireplace.
-
Page 9: Venting Installation
VENTING INSTALLATION LINEAL GAIN OPTIONAL OUTSIDE AIR KIT (MODEL AK4/AK4F) PART NO. DESCRIPTION GAIN The installation of an outside air kit should be performed during Signature Fireplace " the rough framing of the fireplace due to the nature of it's location. 12-12DM Pipe Section "... - Page 10 VENTING INSTALLATION Continued USING ELBOW OFFSETS (30E-12DM) OFFSET RISE CHIMNEY LENGTH 12" 18" 24" 36" 48" 1. To achieve desired offset, you may install combinations of 12", " " ELBOW SET ONLY 18", 24", 36" and 48" length of double wall pipe (see offset chart "...
- Page 11 VENTING INSTALLATION Continued Return Return Elbow Return Elbow Elbow Offset Offset Elbow Elbow 6' (1.88 m) 6' (1.88 m) Ceiling Max. Max. Support Pipe Return Return 12S-12DM Elbow 6' (1.88 m) Elbow Max. 6' (1.88 m) Offset Offset Max. Elbow Elbow 6' (1.88 m) 6' (1.88 m)
- Page 12 VENTING INSTALLATION Continued FLASHING INSTALLATION (V6F-10DM OR V12F-10DM) 17" Determine the flashing to be used with the roof opening chart. Slide (432 mm) 30" (762 mm) flashing over pipe until base is flat against roof. Replace as many Min. 1" (26 mm) Min.
- Page 13 VENTING INSTALLATION Continued Terminations/Spark Arrestor 10 FOOT RULE The fireplace system must be terminated with the listed round top or All flue gas outlet chimney terminations must extend a minimum of chase terminations. In any case, refer to the installation instructions 3 feet in height above the highest point where it passes through the supplied with the termination.
- Page 14 VENTING INSTALLATION Continued Secure flashing through sides with 8-penny nails or sheet rock Termination screws. Place galvanized sleeve through hole in flashing and around last Sheet Metal Screw section of chimney (see Figure 23). 1" Noncombustible Place termination cap over opening and slip stainless steel inner Spacer pipe into stainless steel chimney section.
- Page 15 VENTING INSTALLATION Continued Attach noncombustible spacers at each corner and place flashing Note: Do Not Seal Termination Cap over chase (see Figure 27). Secure flashing through sides with Ventilation Openings 8-penny nails or sheet rock screws. Caulk Place termination cap over opening. Slip stainless steel inner pipe of termination into inner stainless steel chimney section Storm Collar 6"...
-
Page 16: Mosaic Brick Panel And Estate Refractory Panel Installation
CAUSE INJURY. USE ASSISTANCE WHEN MOVING OR LIFTING. NOTE: A Mosaic Masonry panel kit is required for use with your WRE6036, WRE6042, or WRE6050 Firebox. (Not supplied, see page 24 for models available). Hearth MOSAIC MASONRY BRICK INSTALLATION Figure 32 - Slots for Firebrick Walls... - Page 17 MOSAIC MASONRY BRICK PANELS INSTALLATION Continued Retaining Bracket INSTALLING SCREEN Slide round end of screen rod into rings at top of screen. Attach one push-on nut to end of rod before attaching last ring of screen. Insert the round end screen rod into hole on the left and right side of smoke shelf (Figure 35).
-
Page 18: Optional Gas Line Installation
OPTIONAL GAS LINE INSTALLATION Gas line hook up should be done by your supplier or a qualified CAUTION: All gas piping and connections must be service person. tested for leaks after the installation is completed. Note: Before you proceed, make sure your gas supply is turned off. After ensuring that the gas valve is on, apply soap and Use only a 1/2"... -
Page 19: Glass Door Installation
OPTIONAL GAS LINE INSTALLATION Continued GLASS DOOR INSTALLATION Side DOOR FRAME MODELS Outside of Firebrick Fireplace BDMO36E/G/C, BDMO42E/G/C AND BDMO50E/G/C Finished Incoming 1/2" Side Installation Black Iron 1. Remove screws from smoke shelf (see Figure 39). Gas Line Pipe Conduit 2. -
Page 20: Operation And Maintenance Guidelines
GLASS DOOR INSTALLATION Continued OPERATION AND MAINTENANCE GUIDELINES GLASS DOORS INSTALLING GLASS DOORS Glass doors are optional with the fireplace. When fireplace is in operation, Spring clips have been installed but some adjustments may be doors must be fully opened or fully closed position only or a fire hazard needed. -
Page 21: Technical Service
OPERATION AND MAINTENANCE GUIDELINES TECHNICAL SERVICE Continued You may have further questions about installation, operation, or troubleshooting. Please contact your IHP dealer for any questions or concerns a. When contacting your dealer please have your model and serial numbers of your fireplace ready. You can also visit our web site at SuperiorFireplaces.us.com Doors Fully Closed REPLACEMENT PARTS... -
Page 22: Parts
PARTS MODELS 36", 42", AND 50" MODEL CATALOG NO. WRE6036 F4222 WRE6042 F4223 WRE6050 F4224 16/17 SuperiorFireplaces.us.com 901008-00_NC... - Page 23 WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP. Use of non-approved parts can result in poor performance and safety hazards. KEY NO. CATALOG NO. DESCRIPTION WRE6036 WRE6042 WRE6050 QTY. FACE ASSEMBLY •...
- Page 24 PARTS MOSAIC MASONRY BRICK KITS A Mosaic Masonry panel kit is required for use with your WRE6036, WRE6042, or WRE6050 Firebox. Catalog numbers are included for convenience. WARNING: Use only Masonry brick panels approved by IHP. Never use substitute materials. Use of non- approved parts can result in poor performance and safety hazards.
-
Page 25: Accessories
ACCESSORIES BI-FOLD GLASS DOORS (For Use With Mosaic Brick Only) CAT NO. MODEL DESCRIPTION F1011 BDMO36E GLASS DOOR, 36" EBONY F1012 BDMO36G GLASS DOOR, 36" PEWTER F1013 BDMO36C GLASS DOOR, 36" OILED BRONZE F1014 BDMO42E GLASS DOOR, 42" EBONY F1015 BDMO42G GLASS DOOR, 42"... - Page 26 ACCESSORIES Continued OPTIONAL OUTSIDE AIR KIT FOR SIDEWALL INSTALLATION F1093 AK4F Outside Air Kit Collar, Hood & 3' Flex for Floor Venting STORM COLLAR F0946 SC2-1 Storm Collar FIRESTOP SPACER J4384 1100EFS-10DM 1" Clearance Firestop Spacer F0940 FS-10 2" Clearance Firestop Spacer ROOF FLASHING F0942 V6F-10DM...
-
Page 27: Important Notices Canada
IMPORTANT NOTICES IMPORTANT NOTICE Canadian code CAN/ULC-S610-M87 and other NOTICE: The firebox canopy (hood) A manufactured shroud which pertinent codes require stainless steel chimney for must not be modified or replaced with the installation of this fireplace. A Cold Air Climate Kit has been approved by a national a canopy that may be provided with is also required in Canada and is recommended for... -
Page 28: Draft Smoke Guidelines
APPENDIX A Draft Requirements take into account all variables within the installation and install the appliance in such a manner that satisfies the draft requirements of Your wood-burning appliance is dependent upon a properly func- the appliance. See Chimney Guidelines to assist you in selecting the tioning chimney for optimum performance. - Page 29 APPENDIX A Continued Smoking – Causes And Troubleshooting Location Recommended To reduce the likelihood of smoking when opening the door, open Marginal Location the combustion air control or damper before opening the door. Wind Direction Your appliance has been designed and tested to provide smoke free Tree operation.
- Page 30 NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ SuperiorFireplaces.us.com 901008-00_NC...
-
Page 31: Warranty
® 20 Year Limited Warranty THE WARRANTY Innovative Hearth Products ("IHP") 20 Year Limited Warranty warrants your Superior Brand wood burning fireplace ("Product") to be free from defects in materials and ® workmanship at the time of manufacture. The Product body, firebox and ceramic glass carry the 20 Year Limited Warranty. Ceramic glass carries the 20 Year Limited Warranty against thermal breakage only. - Page 32 SuperiorFireplaces.us.com. Record the following important information about your fireplace: Fireplace model number Fireplace serial number Date fireplace was Installed Dealer name P901008-00 Innovative Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distributor for fireplace code information.
