Replacing Ink Cartridges (continued)
Replacing Ink Cartridges (continued)
5
Hold the cartridge with the arrow mark pointing
toward the printer. Then insert the cartridge into the
slot. Don't force it.
Note: If you can't insert the cartridge smoothly,
you may have the wrong cartridge. Check the
package and product code. If the Ink light remains
on after installing the cartridge, try removing and
then reinserting it.

Replacing Printer Parts

Replacing Printer Parts

Replacing the Cutter Blade

If you notice that the paper isn't cut cleanly, you may need
to replace the cutter blade (part # C12C815291). You can
check its status as described below:
1
Press the Menu button on the printer, then press
until you see PRINTER STATUS.
2
Press Menu, then press
SERVICE LIFE.
3
Press Menu, then press
E*****F indicates a new cutter. If no stars are
displayed, the cutter needs to be replaced.
Caution: Do not use the cutter for the
following media:
• Fine art paper (such as Epson UltraSmooth™ ,
Textured, or Velvet)
• Canvas
• Backlight film
• Vinyl
until you see
until you see CUTTER.
6
Return the ink lever to its locked position.
7
If you're using 110 ml cartridges, close the ink
compartment cover. If you're using 220 ml
cartridges, you'll have to leave the cover open.
Follow these steps to replace the cutter:
1
Press the Menu button on the printer, then
until you see MAINTENANCE.
press
2
Press the Menu button. You see CUTTER REPL.
3
Press Menu to display EXEC, then press Menu
again. The print head moves to the cutter
replacement position.
4
Open the top cover.
6
Continue
