EEI-2549
LEISURE CHAIR
Please take the seat off the Chair Body (3) and take the legs and hardware from package on the bottom of
STEP1:
Chair seat cushion. There are numbers shown on legs and each corner of the bottom of Chair body (3).
Please match them correctly. Attention the label '' Insert bolt from this side'' on the legs and insert the legs at
correct side.
Insert 1 piece of Front Leg (1) with 2 pieces of Bolt (A), 2 pieces of Spring Washer (B), and 2 pieces of Flat
Washer (C) into the bottom of Chair Body (3) as shown. Repeat the same steps for other Front Leg (1).
Do not fully tighten Bolts (A) for either leg.
Hardware Package
A×4
Insert 1 piece of Back Leg (2) with 2 pieces of Bolt (A), 2 pieces of Spring Washer (B), and
STEP2:
2 pieces of Flat Washer (C) into the bottom of Chair Body (3) as shown.
Repeat the same steps for other Back Leg (2).
Do not fully tighten Bolts (A) for either leg.
A×4
insert
Legs Package
bolt from
+
this side
(1)
B×4 C×4
insert
bolt from
this side
(2)
(1)
B×4 C×4
(1)
D×1
(2)
(1)
D×1
