TP active fun Zoomee Instructions For Assembly Maintenance And Use page 13

6
6
FC4029 - 8ft
6
FC4030 - 10ft
8
FC4031 - 12ft / 14ft
x6
8ft / 10ft - 3 legs
x8
12ft / 14ft - 4 legs
TP439 440 441 442 Zoomee Trampoline IN5009 Issue-D 04 15.indd 13
8ft - 75mm bolt
10ft, 12ft & 14ft
85mm bolt
8ft - 75mm bolt
10ft, 12ft & 14ft
80mm bolt
13
8ft 10ft 12ft & 14ft
M6 x 75mm M6 x 80mm
Allen Bolt Allen Bolt
M6 x 85mm
Allen Bolt
