- Page 1 PPS11 INSTRUCTION BOOK User Guide...
- Page 2 CONTENTS Getting Started Package Contents Part Names Power Management Charging Connections Updating Firmware Using the Device Basic Operations Home Screen Notification Panel Purchasing or Streaming Music from Store AK Connect Listening to Music Playlist Management USB DAC Installation How to Use USB Audio Settings Connecting to a Wireless Network Using Bluetooth...
- Page 3 User Guide Package Contents may be changed without prior notice to improve the performance or quality of the product. Contents PPS11 5-Pin Micro Quick Start Guide -USB Cable & Warranty Card 5-Pin Micro-USB Cable: Connects the product to a computer or utilize to charge the product.
- Page 4 User Guide Part The appearance of the product, as well as the printed and engraved information, may vary depending on the model. Names 5-Pin Micro-USB Port Earphone Jack 3.5mm Unbalanced Power Previous/Rewind Volume Play/Pause Next/Fast- Forward Touchscreen microSD Home Card Slot Button 5-Pin Micro-USB Port: - DC Power symbol.
- Page 5 User Guide Power Turning on/off Power Manage- 1. Long-press the [Power] button of the device to turn it ON. 2. While the device is on, long-press the [Power] button to ment shut down the device. A confirmation message will appear. 3.
- Page 6 User Guide Charging Charging via Computer 1. The device will charge automatically when connected to a computer via the 5-pin micro-USB cable. Depending on computer specifications, the device will charge only when the computer is turned on. When charging via computer connection, the charging time may vary depending on whether the device is turned on or off.
- Page 7 User Guide Connec- Connecting to a 3.5mm Unbalance Port tions 1. Connect earphones or headphones to the 3.5mm unbalanced port. Connecting to a Computer 1. Turn on the device and your computer. 2. Connect the product to the computer with the 5-pin micro -USB cable to transfer media files.
- Page 8 User Guide Disconnecting from the Computer 1. Disconnect the 5-pin micro-USB cable after the transfer between the product and computer is completed. Disconnecting the device from the computer during an operation (e.g., file transfer) may corrupt data on the device. Safely remove/eject the device from your computer, if applicable.
- Page 9 User Guide Delete Files (or Folders) from the Device via Computer 1. Right-click the desired file/folder and then select [Delete]. 2. Select [Yes] in the [Confirm File/Folder Deletion] window to delete the selected files/folders. Insert/Remove a microSD Card 1. Refer to the diagram and gently insert a microSD card into the microSD card slot.
- Page 10 User Guide Recommended microSD cards SanDisk, Transcend Maximum Capacity: 400GB Notes on Inserting a microSD Card Do not force the microSD card into the slot.This may cause malfunction of the product and damage to the card. Do not repeatedly insert/remove the microSD card. If not inserted properly, the microSD card may cause product malfunctions and may get stuck in the product.
- Page 11 User Guide Updating Wi-Fi Update / OTA (Over-the-Air) Firmware 1. Connect to a wireless network. 2. When a new firmware version is available, the screen will display a Firmware Update Guide window. 3. Select [Update] and choose the items for update. 4.
- Page 12 User Guide Basic LCD Touchscreen Opera- 1. This device features a LCD touchscreen that allows you to perform operations by touch. tions Interact with the device by touching the screen to access various features. To prevent damage to the screen, do not use a sharp object or excessive force.
- Page 13 User Guide Menus 1. Touch and hold, then drag your finger to the right or left in the home screen to display menus. The CD library menu is displayed when music files are extracted with AK CD-RIPPER and songs are stored in the Ripping folder. Notification Bar Using the Device...
