EPSON Stylus Photo 1200
Environmental
Temperature
Operation
50 to 95 °F (10 to 35 °C)
Storage*
– 4 to 104 °F (–20 to 40 °C)
1 month at 104 °F (40 °C)
Transit*
–4 to 140 °F (–20 to 60 °C)
120 hours at 140 °F (60 °C)
Humidity
Operation
20 to 80% RH
Storage*
5 to 85% RH (without condensation)
* Stored in shipping container
Electrical
Specification
120V model
Input voltage range
99V to 132V
Rated frequency range
50 to 60 Hz
Input frequency range
49.5 to 60.5 Hz
Rated current
0.4A
Power consumption
Approx. 18 W (ISO 10561 Letter Pattern)
Approx. 5 W in standby mode
* Also designed for IT power systems with Phase to Phase voltage
220–240V

Safety Approvals

Safety standards
UL 1950, CSA 22.2 No. 950
EMC
FCC part 15 subpart B class B
Interfaces
Parallel interface
Forward channel
Specification
Description
Data format
8-bit parallel, IEEE-1284 compatibility mode
Synchronization
STROBE pulse
Handshake timing
BUSY and ACKNLG signals
Signal level
TTL compatible
Connector
57-30360 Amphenol connector or equivalent
4 - EPSON Stylus Photo 1200
240V model*
198V to 264V
0.2A
3/99
Reverse channel
Specification
Transmission mode
Adaptable connector
Synchronization
Handshaking
Signal level
Data transmission timing
Serial interface
Specification
Description
Standard
Based on RS-423
Synchronization
Synchronous
Bit rate
Approximately 1.8 Mbps
Handshaking
X-ON/X-OFF and DTR protocol
Word format
Data bit: 8 bits
Parity bit: None
Start bit: 1 bit
Stop bit: 1 bit
Connector
8-pin mini-DIN
Recommended cable
ImageWriter II serial cable (preferably Belkin
brand)
USB interface
Specification
Description
Standard
Based on Universal Serial Bus Specifications
Revision 1.0, Universal Serial Bus Device Class
Definition for Printing Devices Version 1.0
Bit rate
12 Mbps (full speed device)
Data encoding
NRZI
Adaptable
USB Series B
connector
Recommended
6.5 feet (2 meters) or less
cable length
Description
IEEE-1284 Nibble mode
57-30360 Amphenol connector or
equivalent
Refer to the IEEE-1284 specification
Refer to the IEEE-1284 specification
IEEE-1284 Level 1 device
Refer to the IEEE-1284 specification
