- Page 1 ANEP BOX-C PIT EMERGENCY TELEPHONE SYSTEM FOR LIFT www.anepstore.com...
-
Page 2: Table Of Contents
SUMMARY TECHNICAL CHARACTERISTICS PAGE 4 1.1 - Technical characteristics 1.2 - Factory settings 1.3 - Connecting ANEP BOX-C module RECOMMANDATIONS PAGE 6 PROGRAMMING MODE PAGE 7 3.1 - Enter programming mode 3.1.1 - Exit programming mode 3.1.2 - Addressing 3.1.3 - Simplified programming 3.2 - GSM Mode... - Page 3 6.1 - Enable call to SVA 6.2 - Making the call to SVA 6.3 - Tests made 6.3.1 - Audio reception test 6.3.2 - ANEP BOX-C serial number verification 6.3.3 - Installation telephone number check 6.3.4 - Audio test 6.3.5 - End of test...
-
Page 4: Technical Characteristics
• Programmable by 12 key keypad • 2 inputs from the pit flooding detector • 1 dual fonction key : passenger trapped acknowledge and test call to ANEP voice server • 1 key for technician alarm • Up to 6 telephone numbers may be stored •... -
Page 5: Connecting Anep Box-C Module
1.3 - Connecting ANEP BOX-C module Powered flood sensor Dry contact flood sensor phone line ANEP BOX-C Version #1 09/22//2014... -
Page 6: Recommandations
RECOMMANDATIONS before handling any ANEP products, ensure the equipement has been disconnected from all power supplies. The performance of telephone line equipement depends largely upon the characteristics of the telephone line. Particular care must be taken when cabling the phone line to avoid damaging the standard line characteristics. -
Page 7: Programming Mode
• Access to the programming mode is only possible if the phone line is hung up. ( Beware if several modules share the same line ) • The BOX-C keypad is used to program all the parameters. • To avoid unwanted modifications, the programming mode is protected by an access... - Page 8 3.1.2 - Addressing Several BOX-C modules may be installed on the same telephone line (max 8). The address of EVERY module must be configured. After entering the acces code to enter programming mode, enter the following sequences : # 303 then 1 # if module 1 ( lift 1 )
-
Page 9: Exit Programming Mode
3.1.3 - Simplified programming BOX-C automatically detects wheter the call button is NO or NC. It is therefore necessary to connect the call button BEFORE connecting inputs and the telephone line SEQUENCE COMMENTS KEYS (Factory default : 123) Access code to enter programming mode... -
Page 10: Gsm Mode
3.2 - GSM mode The GSM mode should be activated when BOX-C is connected to a GSM gateway. To activate this mode: In programming mode: Enter the sequence #405# To come back to normal mode (PSTN) In programming mode: ... -
Page 11: Erase A Number
3.4 - Memory attribution 3.4.1 - Transfer method The BOX-C may be programmed to interface with the call center, utilizing the available software and specifications. To communicate with call centers, ANEP unit can transfer its ID information and establish a two-way voice communication either : •... -
Page 12: Enabling And Adjustment Of Parameters
A «site record» must first be established in the software ANEPCENTER® (refer to the manual ANEPCENTER®) During programmation mode exit, BOX-C performs a periodic call immediately NOTE: During cyclic call, the central (AnepCenter or compatible) receiving the call can reprogram the clock of the C-BOX. -
Page 13: Changing The Access Code Programming
(1 = min / 15 = max gain) Loudspeaker gain settings: After entering the access code programming Press the # 408 and a value of 1 to 15, then # (1 = min / 15 = max gain ) ANEP BOX-C Version #1 09/22//2014... -
Page 14: Configuration Of The Dual Call Mode
« is enabled, the caretaker will have to acknowledge the call by entering the sequence « #1 « on his phone keypad. Without this acknowledgment, BOX-C will call back to the call center up to 6 times. -
Page 15: Connecting The Flood Sensor (Option)
(OPTION) 4.1 - Flood sensor input ANEP BOX-C possesses a function which allows the detections of water in the pit. An optional kit consisting of a sensor and bracket may be connected to the corresponding input. Two types of flood sensor can be connected:... -
Page 16: Operation
The unit automatically Hang Up if an eng aged signal is detected or if the call timeout is reached. ANEP BOX-C plays a melody 10 seconds before hanging up at the timeout limit. Note : If the called number is eng.gd or does not answers = (10 rings), the unit calls the secondary telephone number in its memory. -
Page 17: Call To Anep's Voice Server (Sva)
CALL TO ANEP’S VOICE SERVER (SVA) 6.1 - Enable call to SVA Enter the access code to programming mode then press the SVA button (green key). Special case : make a call to SVA from from behind a PABX : Pressing the «0»... -
Page 18: Tests Made
6.3.1 - Audio reception test - The dialling and data transmission are audible in the loud-speaker. 6.3.2 - ANEP BOX-C serial number verification - The serial number of the unit is annouced by the SVA. 6.3.3 - Installation telephone number check - The telephone number of the caller is annonced by SVA. -
Page 19: Keypad Programming
Line voltage normal ( > = 28V) #404# GSM enabled #405# #406# Analog phone line mode enabled Microphone volume adjustment (De 1 à 15). #407...# Loudspeaker volume adjustement(De 1 à 15). #408...# Adjusting the level of emissions of DTMF codes #409...# ANEP BOX-C Version #1 09/22//2014... - Page 20 NOTE ANEP BOX-C Version #1 09/22/2014...
- Page 21 NOTE ANEP BOX-C Version #1 09/22//2014...
- Page 22 NOTE ANEP BOX-C Version #1 09/22/2014...
- Page 23 à la précision, à la fiabilité ou au contenu du document. ANEP se réserve le droit de réviser ce document ou de le retirer à n’ importe quel moment sans préavis.
- Page 24 4 bis rue de Paris 94470 Boissy-Saint-Léger - FRANCE Tel : +33 1 45 98 34 44 / Fax : +33 1 45 69 75 45 www.anepstore.com...
