- Page 1 PARADISE SERIES PORTABLE SPA OWNER’S MANUAL GENEVA • NIAGARA HAWAIIAN • TAHITIAN MARTINIQUE • KAUAI QUALITY SPAS AND GAZEBOS SINCE 1976.
-
Page 2: Table Of Contents
IMPORTANT SERVICE INFORMATION IMPORTANT SAFETY INSTRUCTIONS SET UP AND INSTALLATION • Site selection and preparation ....3 • Equipment compartment access ....3 •... -
Page 3: Important Service Information
With proper maintenance, your Caldera spa will provide you with many years of relaxation and dependable service. If you have any questions not addressed in this manual, call your Caldera dealer and he or she will be happy to assist you. Dealer: Address: Phone:... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS 1. DANGER - RISK OF ACCIDENTAL DROWNING. Extreme caution must be exercised to prevent unautho- rized access by children. To avoid accidents, ensure that children cannot use this spa unless they are under adult supervision at all times. -
Page 5: Set Up And Installation
SET UP AND INSTALLATION 10 ft. Slope 1 inch per 10 ft. for proper drainage. SITE SELECTION In order for your spa to function properly, it must be placed on a SMOOTH, LEVEL, SELF-DRAINING SURFACE. Concrete sloped at 1 inch per 10 feet is preferred so that rain water and water spillover will run off and not puddle underneath the spa (water under the spa for long peri- ods of time may cause the wood to deteriorate). -
Page 6: Electrical Installation
ELECTRICAL INSTALLATION Inputs from transformer Red (Hot) Black (Hot) White (Neutral) 240V WIRING SCHEMATIC DIAGRAM 240 VOLT INSTALLATION Your spa contains a Control Module designed to operate at 240V, 60Hz. Installation of a 50 amp. dedicated circuit is required. The Control Module must be hard wired directly to a supply circuit that is protected by a Ground Fault Circuit Interrupter (GFCI). -
Page 7: Start-Up Instructions
5. ADD START-UP CHEMICALS Add the spa water chemicals as directed by your Caldera dealer, by the instructions contained in your spa chemical kit or in the section titled “BALANCING THE SPA WATER”... -
Page 8: Installing The Spa Cover
9. INSTALL THE SPA COVER COVER INSTALLATION TIE-DOWN STRAP LOCK SCREW (2) • Place the cover squarely on the spa. • Position the tie-down locks included with your cover TOP VIEW - FEATURES 1. Power diverter 2. Air control 3. Air jets 4. -
Page 9: Customizing Your Massage
CUSTOMIZING YOUR MASSAGE Your Caldera spa offers numerous ways for you to cus- tomize your massage experience. Experimentation is the best way to find what feels best to you. Try sitting in dif- ferent seats, adjusting the Power Diverters, air controls and jet nozzles and turning each pump on or off. -
Page 10: Operation - Control Panel
OPERATION - CONTROL PANEL Mode touch pad Selects standard or economy operating mode LIGHT touch pad Controls the 3-way Mood Light HYDRO JETS touch pads Controls Hydro Jet pumps 1 and 2 Mode touch pad Selects standard or economy operating mode LIGHT touch pad Controls the 3-way Mood Light HYDRO JETS touch pad... -
Page 11: Standard Or Economy Mode
OPERATION - CONTROL PANEL STANDARD OR ECONOMY MODE When in ECONOMY mode, “ECON” flashes alternately with the water temperature on the LCD. The heater oper- ates only during skim/filter cycles to heat the spa water with the following exception: Should the spa water tem- perature fall below 20 F of set temperature, the heater will engage to heat the spa water to within 15... -
Page 12: Maintenance
To maintain the rich finish, apply a good quality tinted or clear stain every six months. Note: The stain used by Caldera is available from your Caldera dealer. Page 10... -
Page 13: Equipment Compartment Illustration
TYPICAL EQUIPMENT COMPARTMENT: GENEVA • NIAGARA • TAHITIAN • HAWAIIAN A. Caldera Pure Water Ozone system. (Option) B. Control Module/wiring access panel. C. Plugs/receptacles - spa component connection. D. Knife Valve (2), Hydro jet pump # 2. E. Union (2), Hydro jet pump # 2. -
Page 14: Filter Removal And Maintenance
Note: The filter cartridge should be replaced with a new cartridge approximately every 12 months. Replacement filter cartridges are available from your Caldera dealer. Refer to the back of this manual to determine the appro- priate size for your spa. -
Page 15: Spa Cover Care
SPA COVER CARE CLEANING AND VINYL CARE Keep the cover clean. As often as is necessary wash with mild soap and rinse with clean potable water. DO NOT USE SOLVENTS, PETROLE- UM PRODUCTS, ABRASIVE CLEANERS OR STRONG DETERGENTS. All vinyls contain plasticizers which migrate out and escape naturally over time. -
Page 16: Draining Your Spa
PUMP DRAIN PLUG LOCATION DRAIN PLUG Front view of pump 5. Follow the instructions on page 12 to remove the float- ing weir, basket and filter cartridge. Insert a shop vacuum hose into the suction line located in the bottom of the filter compartment (operate in the blow mode). -
Page 17: Balancing The Spa Water
Note: Many of the additives mentioned here are referred to by brand name. If your chemicals are a different brand, ask your Caldera dealer which additives are comparable, if necessary. The instructions below will assist you with balancing the spa water for the first time. You will need the following items to balance your spa water. -
Page 18: Water Maintenance
NOT cov- ered by your Caldera spa warranty. WATER PURIFICATION WITH OZONE (OPTION) The Caldera Pure Water Ozone system produces ozone to “burn out” water contaminants, bacteria and viruses through the process of oxidation. Ozone is continually pro-... -
Page 19: Spa Water Troubleshooting
• Adjust pH; add “SPA DOWN”. • Use clarifier. • Drain the spa, clean and refill. • Contact your Caldera dealer. • Shock the spa with “RENEW”. • Increase sanitizer level to recommended level. • Raise pH with “SPA UP”. -
Page 20: Spa Troubleshooting
If your spa doesn’t seem to be working the way you believe it should, please review the “START-UP” and “OPERATION” instructions in this manual. If this doesn’t help you correct the problem, follow the appropriate instructions below. If the problem still is not resolved, call your Caldera dealer. SYMPTOM... -
Page 21: Lcd Messages
112 pletely shut down. In such a condition, DO NOT ENTER THE WATER. Turn off all power to the spa and contact your Caldera dealer. Freeze Protection - If a potential freeze condition is detected, both Hydro jet pumps are automatically activated. - Page 22 NOTES Page 20...
- Page 23 NOTES Page 21...
-
Page 24: Spa Specifications
Caldera Pure Water Ozone system option: Mood light: Filter: *Dimensions, weights and capacities are approximate. Caldera Spas . . . Quality Spas and Gazebos Since 1976. PART #38666, REV. A (2/00) SPA SPECIFICATIONS* GENEVA 89 in. x 89 in. x 38 in.
Need help?
Do you have a question about the Paradise Series and is the answer not in the manual?
Questions and answers
Need instructions to remove side panel to access motor and removed drain plugs,not know how to get side off
To remove the side panel on a Caldera Series hot tub:
1. Remove the 2 screws from the bottom corners of the panel.
2. Locate the notches at the bottom of the panel.
3. Place your fingers at the center notch on one side and gently pull to release the first clip.
4. Move to the center notch on the other side and pull to release the second clip.
5. Lower and remove the panel.
This gives access to the motor and drain plugs.
This answer is automatically generated
How do I get my 2012 paradise Martinique out of spa LOCK? I have tried the tools menu way, is there another alternative to unlocking this spa?
Can I get a real owners manual? Caldera Kauai 2025 hot tub just recd??
Access motor with removal of side panel
