- Page 1 User Manual ECMB002-S Digital Signage Media Box EC ELECTRONICS LIMITED COPYRIGHT 2020 ©...
-
Page 2: Table Of Contents
EC-MB002 Digital Signage Media Box User Manual CONTENT 1 Overview ..................3 2 Introduction ..................3 3 Packing Information ................ 3 4 Remote Control ................4 4.1 Change Battery ................... 4 4.2 Function For Remote Control ..............5 5 Installation Guide ................6 5.1 Appearance .................... - Page 3 EC-MB002 Digital Signage Media Box User Manual 6.4 System Control ..................15 6.4.1 Work Mode ................... 16 6.4.2 Play Mode ..................... 16 6.4.3 Current Storage ..................17 6.4.4 Image Duration ..................17 6.5 Date & Time ....................18 6.6 Power On/Off ..................... 19 6.7 Timer Strategy ...................
-
Page 4: Overview
EC-MB002 Digital Signage Media Box User Manual OVERVIEW Thank you for purchasing the EC Line all-in-one digital signage kiosk, EC-Line is committed to continuously improve product quality and provide better after-sales service. In order to take full advantage of our devices, we strongly recommend that you take the time to read this manual before diving into software solution. -
Page 5: Remote Control
EC-MB002 Digital Signage Media Box User Manual REMOTE CONTROL The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully to use the monitor correctly. To install batteries, open the battery cover, place batteries (1.5 V AAA) matching + and - terminals to the labels inside the compartment, and close the battery cover. -
Page 6: Function For Remote Control
EC-MB002 Digital Signage Media Box User Manual 4.2 FUNCTION FOR REMOTE CONTROL ** Function for “Source” is nil for some models... -
Page 7: Installation Guide
EC-MB002 Digital Signage Media Box User Manual INSTALLATION GUIDE 5.1 APPEARANCE Front View Rear View Front View with Antenna... -
Page 8: Specification
EC-MB002 Digital Signage Media Box User Manual 5.2 SPECIFICATION... -
Page 9: Connection To Display Unit
EC-MB002 Digital Signage Media Box User Manual 5.3 CONNECTION TO DISPLAY UNIT 5.3.1 Video Output ◼ HDMI – connect the HDMI cable between the media box and display unit ◼ VGA – connect the VGA cable between the media box and display unit 5.3.2 Connect the power supply that provided 5.3.3... -
Page 10: System Configuration
EC-MB002 Digital Signage Media Box User Manual SYSTEM CONFIGURATION 6.1 HOME SCREEN Once your screen has powered up and begins to play content press the “STOP” button on the remote control to go back to the Home Screen (Figure 1). Figure 1 6.2 SYSTEM MENU OPERATION From the Home Screen you can bring up the Main Menu by pressing the “SETUP”... -
Page 11: System Settings
EC-MB002 Digital Signage Media Box User Manual 6.3 SYSTEM SETTINGS The sub-menus within this section are: Display Language, Screen Mode, Screen Resolution, On Screen Clock, USB, Scrolling Text, Sync Settings, Restore to Factory Settings and Auto Start. To exit a sub-menu please press the “LEFT” navigation button the remote control, you can now navigate through the Main Menus sub-menus. -
Page 12: Switch Screen Mode
EC-MB002 Digital Signage Media Box User Manual 6.3.2 Switch Screen Mode Here you can set the screens orientation so as the OSD and content display correctly. There are 4 options as pictured below: • 0° (default landscape) - Displays in landscape •... -
Page 13: Real Time Clock
EC-MB002 Digital Signage Media Box User Manual 6.3.4 Real Time Clock This option allows you to display a clock while content is playing. There are 5 options as pictured below: • Close: The screen doesn’t display time. • Top Left: The time will be displayed on top left of the screen. •... -
Page 14: Usb
EC-MB002 Digital Signage Media Box User Manual 6.3.6 This allows you to enable or disable the USB port. If you want to be able to update the screen please ensure this is turned on (blue). 6.3.7 Scrolling Text This allows you to enable or disable the scrolling text function. If you have included scrolling text in your playlist (using the scheduling software) and want it to display please ensure this is turned on (blue). -
Page 15: Sync Settings
EC-MB002 Digital Signage Media Box User Manual 6.3.8 Sync Settings This is a network function only and is disabled on this screen. 6.3.9 Restore to Factory Settings Highlight “Yes” and press “PLAY” to restore factory settings; this will restore all system settings back to default. -
Page 16: Auto Start
EC-MB002 Digital Signage Media Box User Manual 6.3.10 Auto Start This feature allows your screen to start playing the pre-loaded content as soon as it has finished booting up. If you want to enable this feature (recommended) please ensure this is turned on (blue). 6.4 SYSTEM CONTROL To exit a sub-menu please press the “LEFT”... -
Page 17: Work Mode
EC-MB002 Digital Signage Media Box User Manual 6.4.1 Work Mode This feature allows you set the update method for your screen. 6.4.2 Play Mode This feature is only available if the screen is set to “STANDALONE” mode and should be set to “Open”. -
Page 18: Current Storage
EC-MB002 Digital Signage Media Box User Manual 6.4.3 Current Storage This feature allows you to display content directly from a USB stick should you want to. We recommend that you set this feature to “Internal Memory” however if you want your content to displays directly from your USB stick (and not copy over) please select “USB”. -
Page 19: Date & Time
EC-MB002 Digital Signage Media Box User Manual 6.5 DATE & TIME To exit a sub-menu please press the “LEFT” navigation button the remote control, you can now navigate though the Main Menus sub-menus. To set accurate values first select the top “date” field by pressing “PLAY”. -
Page 20: Power On/Off
EC-MB002 Digital Signage Media Box User Manual 6.6 POWER ON/OFF Here is where you can set up your screens on/off timer, should you want it to power on and off automatically at designated times. If you do not wish to set on/off times for your screen please set the “Control Mode”... -
Page 21: Timer Strategy
EC-MB002 Digital Signage Media Box User Manual 6.7 TIMER STRATEGY This feature allows you to schedule your screen to play at different volumes at different times of the day and switch to different AV inputs at different times of the day. 6.7.1 Volume Timer To enable this feature turn the slider on (blue). -
Page 22: Port Timer
EC-MB002 Digital Signage Media Box User Manual 6.7.2 Port Timer To enable this feature turn the slider on (blue). New fields will now appear allowing you to set different AV inputs for different periods of the day. Navigate to a timer field and press “PLAY” on your remote control. Activate the timer then set a start and end time and an AV input. -
Page 23: File Management
EC-MB002 Digital Signage Media Box User Manual 6.8 FILE MANAGEMENT Here, you can check storage information such as memory capacity, used space and free space. You can also format the disk. You should be extremely careful here as formatting the disk will result in a total loss of data. -
Page 24: Troubleshooting
EC-MB002 Digital Signage Media Box User Manual TROUBLESHOOTING Media Box does not start Check the power is plugged in correctly to the power outlet. If the media box does not boot after a sudden power failure or illegal shutdown, unplug the power from the power outlet, and plug in again after 1 minute. - Page 25 EC-MB002 Digital Signage Media Box User Manual Manufacturer: EC LINE Thank you very much for using EC Line product For service, please contact service@ecline.com.hk www.eclinepos.com...
