- Page 1 User Manual EC-WDS / EC-FDS / EC-FSS Series All in One Digital Signage Kiosk EC ELECTRONICS LIMITED COPYRIGHT 2020 ©...
-
Page 2: Table Of Contents
Assembly and Preparation ............10 Remote Control ................11 Change Battery ................... 11 Function For Remote Control ..............12 Installation Guide ................13 EC-WDS Series (32”, 43”, 49”, 55” & 65”) ..........13 9.1.1 Appearance ....................13 9.1.2 Specification ..................... 14 EC-FDS Series (43”, 49”... - Page 3 Digital Signage Kiosk User Manual 11.2 EC-FDS Series ..................... 21 11.2.1 Steps For Assembly With Casters ............22 11.3 EC-FSS Series ..................... 23 12. System Configuration ..............24 12.1 Home Screen ................... 24 12.2 System Menu Operation ................. 24 12.3 System Settings ..................
-
Page 4: Overview
Digital Signage Kiosk User Manual 1. OVERVIEW Thank you for purchasing the EC Line all-in-one digital signage kiosk, EC-Line is committed to continuously improve product quality and provide better after-sales service. In order to take full advantage of our devices, we strongly recommend that you take the time to read this manual before diving into software solution. - Page 5 (more than 100 mm from the wall) to provide adequate air circulation. It is strongly recommended that you use a EC Line Wall-Mount Bracket in order to provide adequate air circulation. The ventilation condition is depending on your kiosk model, please contact EC Line service department for further information.
-
Page 6: Precautions For Using Ac Adapter And Electrical Power
- If loosely connected, the poor connection may cause a fire or electric shock. • Be sure to use power cords and AC adapters provided or approved by EC Line. - The use of non-approved products may cause a fire or electric shock. - Page 7 Digital Signage Kiosk User Manual • Do not insert a conductor into one end of the power cable while the other end is connected to the input terminal on the wall. Do not touch the power cable right after plugging into the wall input terminal.
-
Page 8: Precautions For Moving The Product
Digital Signage Kiosk User Manual 5. PRECAUTIONS FOR MOVING THE PRODUCT WARNING • The kiosk is turned off and the AC power is unplugged. - It may cause electrocuted or the product can be damaged. • Remove all cables before moving the product. - It may cause electrocuted or the product can be damaged. -
Page 9: Precautions For Using The Product
Digital Signage Kiosk User Manual 6. PRECAUTIONS FOR USING THE PRODUCT WARNING • Do not disassemble, repair or modify the product at your own discretion. - Fire, electric shock or warping may result. - Contact the service center for inspection, calibration or repair. •... -
Page 10: Mounting On A Wall
• Do NOT install this product by yourself, injury or damage to the kiosk may cause. Please contact service personnel authorized by manufacturer. • It’s strongly recommended that tom use a EC Line Wall-Mount Bracket in order to provide adequate support of the weight and air circulation. -
Page 11: Assembly And Preparation
• Disconnect the power cord before moving or installing the monitor to avoid risk of electric shock. • Make sure to fix the stand on the floor since the set may fall when pushed. EC Line is not liable for any damages of the product or casualties due to not following this instruction. -
Page 12: Remote Control
Digital Signage Kiosk User Manual 8. REMOTE CONTROL The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully to use the monitor correctly. To install batteries, open the battery cover, place batteries (1.5 V AAA) matching + and - terminals to the labels inside the compartment, and close the battery cover. -
Page 13: Function For Remote Control
Digital Signage Kiosk User Manual FUNCTION FOR REMOTE CONTROL ** Function for “Source” is nil for some models... -
Page 14: Installation Guide
Digital Signage Kiosk User Manual 9. INSTALLATION GUIDE EC-WDS Series (32”, 43”, 49”, 55” & 65”) 9.1.1 APPEARANCE Front View Front View Side View... -
Page 15: Specification
Digital Signage Kiosk User Manual 9.1.2 SPECIFICATION... -
Page 16: Ec-Fds Series (43", 49" & 55")
Digital Signage Kiosk User Manual EC-FDS Series (43”, 49” & 55”) 9.2.1 APPEARANCE Front View Front View Side View... -
Page 17: Specification
Digital Signage Kiosk User Manual 9.2.2 SPECIFICATION... -
Page 18: Ec-Fss Series (55")
Digital Signage Kiosk User Manual EC-FSS Series (55”) 9.3.1 APPEARANCE Side View Front View Front View... -
Page 19: Specification
Digital Signage Kiosk User Manual 9.3.2 SPECIFICATION... -
Page 20: Packing Information
Digital Signage Kiosk User Manual 10. PACKING INFORMATION 10.1 EC-WDS Series Digital Signal All in One Kiosk Remote Control Wall Mount Kit Operation Manual Power Cord Antenna 2 set of Keys 10.2 EC-FDS Series Digital Signage All in one Kiosk... -
Page 21: Setup And Installation
We recommend you contact a technician for assistance when installing the wall mount bracket. EC Line is not responsible for any damage to the product or injury to yourself or others if you elect to install the wall mount on your own. -
Page 22: Ec-Fds Series
** Do not install your Wall Mount Kit while your product is turned on. It may result in personal injury due to electric shock ** For the content management, refer to our EC Line iconnect content management handbook. 11.2 EC-FDS Series 1. -
Page 23: Steps For Assembly With Casters
Tighten all casters with a 14mm wrench. 2. Connect the base and the digital poster with provided screws. Tighten all screws with an Allen wrench. The assembly is finished. ** For the content management, refer to our EC Line iconnect content management handbook. -
Page 24: Ec-Fss Series
2. Installation (Please contact EC Line authorized partner) 3. Connect the WIFI or ethernet cable 4. Setup IP address 5. Connect to the CMS cloud server ** For the content management, refer to our EC Line iconnect content management handbook. -
Page 25: System Configuration
Digital Signage Kiosk User Manual 12. SYSTEM CONFIGURATION 12.1 HOME SCREEN Once your screen has powered up and begins to play content press the “STOP” button on the remote control to go back to the Home Screen (Figure 1). Figure 1 12.2 SYSTEM MENU OPERATION From the Home Screen you can bring up the Main Menu by pressing the “SETUP”... -
Page 26: System Settings
Digital Signage Kiosk User Manual 12.3 SYSTEM SETTINGS The sub-menus within this section are: Display Language, Screen Mode, Screen Resolution, On Screen Clock, USB, Scrolling Text, Sync Settings, Restore to Factory Settings and Auto Start. To exit a sub-menu please press the “LEFT” navigation button the remote control, you can now navigate through the Main Menus sub-menus. -
Page 27: Switch Screen Mode
Digital Signage Kiosk User Manual 12.3.2 SWITCH SCREEN MODE Here you can set the screens orientation so as the OSD and content display correctly. There are 4 options as pictured below: • 0° (default landscape) - Displays in landscape with the locker door on the left-hand side. -
Page 28: Real Time Clock
Digital Signage Kiosk User Manual 12.3.4 REAL TIME CLOCK This option allows you to display a clock while content is playing. There are 5 options as pictured below: • Close: The screen doesn’t display time. • Top Left: The time will be displayed on top left of the screen. •... -
Page 29: Usb
Digital Signage Kiosk User Manual 12.3.6 This allows you to enable or disable the USB port. If you want to be able to update the screen please ensure this is turned on (blue). 12.3.7 SCROLLING TEXT This allows you to enable or disable the scrolling text function. If you have included scrolling text in your playlist (using the scheduling software) and want it to display please ensure this is turned on (blue). -
Page 30: Sync Settings
Digital Signage Kiosk User Manual 12.3.8 SYNC SETTINGS This is a network function only and is disabled on this screen. 12.3.9 RESTORE TO FACTORY SETTINGS Highlight “Yes” and press “PLAY” to restore factory settings; this will restore all system settings back to default. -
Page 31: Auto Start
Digital Signage Kiosk User Manual 12.3.10 AUTO START This feature allows your screen to start playing the pre-loaded content as soon as it has finished booting up. If you want to enable this feature (recommended) please ensure this is turned on (blue). 12.4 SYSTEM CONTROL To exit a sub-menu please press the “LEFT”... -
Page 32: Work Mode
Digital Signage Kiosk User Manual 12.4.1 WORK MODE This feature allows you set the update method for your screen. It should be set to “STANDALONE” 12.4.2 PLAY MODE This feature is only available if the screen is set to “STANDALONE” mode and should be set to “Open”. -
Page 33: Current Storage
Digital Signage Kiosk User Manual 12.4.3 CURRENT STORAGE This feature allows you to display content directly from a USB stick should you want to. We recommend that you set this feature to “Internal Memory” however if you want your content to displays directly from your USB stick (and not copy over) please select “USB”. 12.4.4 IMAGE DURATION This feature allows you to set default duration time for your images (when not using the... -
Page 34: Date & Time
Digital Signage Kiosk User Manual 12.5 DATE & TIME To exit a sub-menu please press the “LEFT” navigation button the remote control, you can now navigate through the Main Menus sub-menus. To set accurate values first select the top “date” field by pressing “PLAY”. Another window will now appear, allowing you to set your date values by using the navigation buttons on your remote control and the on screen “+”... -
Page 35: Power On/Off
Digital Signage Kiosk User Manual 12.6 POWER ON/OFF Here is where you can set up your screens on/off timer, should you want it to power on and off automatically at designated times. If you do not wish to set on/off times for your screen please set the “Control Mode”... -
Page 36: Timer Strategy
Digital Signage Kiosk User Manual 12.7 TIMER STRATEGY This feature allows you to schedule your screen to play at different volumes at different times of the day and switch to different AV inputs at different times of the day. 12.7.1 VOLUME TIMER To enable this feature, turn the slider on (blue). -
Page 37: Port Timer
Digital Signage Kiosk User Manual 12.7.2 PORT TIMER To enable this feature, turn the slider on (blue). New fields will now appear allowing you to set different AV inputs for different periods of the day. Navigate to a timer field and press “PLAY” on your remote control. Activate the timer then set a start and end time and an AV input. -
Page 38: File Management
Digital Signage Kiosk User Manual 12.8 FILE MANAGEMENT Here, you can check storage information such as memory capacity, used space and free space. You can also format the disk. You should be extremely careful here as formatting the disk will result in a total loss of data. 12.9 EXIT Highlighting and selecting this section will exit the Main Menu. -
Page 39: Troubleshooting
Digital Signage Kiosk User Manual 13. TROUBLESHOOTING Kiosk does not start Check the power is plugged in correctly to the power outlet. b) If the kiosk is working in high temperature environment that causes the kiosk automatically shut down in protection mode, please disconnect the power of the machine. - Page 40 Digital Signage Kiosk User Manual Manufacturer: EC LINE Thank you very much for using EC Line product For service, please contact service@ecline.com.hk www.eclinepos.com...
