Summary of Contents for I-Tech NK-2b
- Page 1 User Manual dedicated KVM switch and rackmount screen technology NK-2e / NK-2b 1U Short Depth Keyboard Drawer i-Tech Company LLC TOLL FREE: (888) 483-2418 • EMAIL: info@itechlcd.com • WEB: www.iTechLCD.com...
- Page 2 Legal Information First English printing, July 2019 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 3: Table Of Contents
Contents NK-2e / NK-2b < Part. 1 > Package Content Structure Diagram & Dimension Installation Connection < Part. 2 > Specifi cations Keyboard / Mouse Specifi cations Environmental Conditions www.itechlcd.com... -
Page 4: Nk-2E / Nk-2B
NK-2e / NK-2b < Part 1 > < 1.1 > Package Content NK-2e or NK-2b unit X 1 - KC-2 6ft USB keyboard mouse cable X 1 ( Alternative for PS/2 KB / MS : KC-3 6 6ft Combo KB / MS cable ) - Pair of L-bracket with fastener screws X 1 <... - Page 5 Weight 441.6 x 400 x 44 mm 582 x 500 x 100 mm 8.6 kg 10.1 kg NK-2e / NK-2b 17.4 x 15.7 x 1.73 inch 22.9 x 19.7 x 3.9 inch 18.9 lb 22.2 lb * All dimensions stated are subject to change if options are selected / integrated to base model part codes...
- Page 6 < 1.3 > Installation- How to install L-bracket Step ■ Install left & right rear L-brackets with two fasteners shown above. ■ Leave the fasteners slightly loose. Step ■ Measure the depth of the front and rear mounting rails. ■ Align each rear L-bracket to a suitable length and tighten the fasteners.
-
Page 7: Connection
NK-2e / b < 1.4 > Connection to USB Server Keyboard Drawer KB / MS KC-2 USB KB mouse cable USB server < 1.4 > Connection to external KVM Keyboard Drawer KB / MS KC-2 USB KB mouse cable USB console KVM The keyboard drawer is hot-pluggable, but components of connected devices, such Caution : as the servers and KVM switch, may not be hot-pluggable. -
Page 8: Specifi Cations
< Part 2 > Specifi cations < 2.1 > Standard Keyboard / Mouse Specifi cations G keyboard integrated with touchpad G keyboard integrated with trackball 55 ± 5g Key force 3 ± 0.3mm Travelling distance > 10 million life cycle time Switch life Windows / Linux / Unix / Mac OS OS support... - Page 9 NK-2e / b < 2.1 > MAC Keyboard / Mouse Options MAC keyboard integrated with touchpad MAC keyboard integrated with trackball Supporting layouts America United States How to Use "MAC" Keyboard Keyboard Features Decrease display brightness Fast-forward Increase display brightness Mute sound Mission control * Only works with OS X Lion...
- Page 10 < 2.1 > SUN Keyboard / Mouse Options GS keyboard integrated with touchpad GS keyboard integrated with trackball Ca ps Scro ll Comp ose Ca ps Scro ll Comp ose GS keyboard integrated with touchpad / trackball ■ Incorporates SUN keys, including Stop, Cut, Paste, Compose, Copy and Help ■...
-
Page 11: Environmental Conditions
NK-2e / b < 2.2 > Environmental Conditions Temperature 0 to 55°C degree Operating Humidity 20~90%, non-condensing Altitude 16,000 ft Temperature -20 to 60°C degree Storage / Non-operating Humidity 5~90%, non-condensing Altitude 40,000 ft Shock 10G acceleration (11ms duration) Vibration 5~500Hz 1G RMS random www.itechlcd.com... - Page 12 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. www.itechlcd.com...
