26 OPERATION
OPERATION
Before Use
Checklist
Clean the refrigerator.
Clean the refrigerator thoroughly and wipe off all dust that accumulated
during shipping.
CAUTION
• Do not scratch the refrigerator with a sharp object or use a detergent that
contains alcohol, a flammable liquid or an abrasive when removing any
tape or adhesive from the refrigerator. Remove adhesive residue by wiping
it off with your thumb or dish detergent.
• Do not peel off the model or serial number label or the technical
information on the rear surface of the refrigerator.
Open refrigerator doors and freezer drawers to ventilate the
interior.
The inside of the refrigerator may smell like plastic at first. Remove any
adhesive tape from inside the refrigerator and open the refrigerator doors
and the freezer drawers for ventilation.
Connect the power supply.
Check if the power supply is connected before use.
Turn off the icemaker.
Turn off the icemaker if the refrigerator is not yet connected to the water
supply.
NOTE
• The icemaker water valve may buzz if the icemaker is turned on while the
refrigerator is not connected to the water supply.
Wait for the refrigerator to cool.
Allow the refrigerator to run for at least two to three hours before putting
food in it. Check the flow of cold air in the freezer compartment to ensure
proper cooling.
CAUTION
• Putting food in the refrigerator before it has cooled could cause the food to
spoil, or a bad odor to remain inside the refrigerator.
The refrigerator makes a loud noise after initial operation.
This is normal. The volume will decrease as the temperature decreases.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LRFXS2503S and is the answer not in the manual?

Questions and answers

Related Manuals for LG LRFXS2503S

Summary of Contents for LG LRFXS2503S

  • Page 1 26 OPERATION OPERATION Before Use Checklist Clean the refrigerator. Clean the refrigerator thoroughly and wipe off all dust that accumulated during shipping. CAUTION • Do not scratch the refrigerator with a sharp object or use a detergent that contains alcohol, a flammable liquid or an abrasive when removing any tape or adhesive from the refrigerator.

  • Page 2: Control Panel Features

    OPERATION Control Panel Depending on the model, some of the following functions may not be available. The actual control panel may differ from model to model. Control Panel Features Ice Plus This function increases both ice making and freezing capabilities. Press the Ice Plus button to illuminate the icon and activate the function for 24 hours.

  • Page 3: Sabbath Mode

    Wi-Fi The Wi-Fi button, when used with the LG SmartThinQ app, allows the refrigerator to connect to a home Wi-Fi network. Refer to Smart Functions for information on the initial setup of the application. The Wi-Fi icon shows the status of the refrigerator's network connection.

  • Page 4: Ice And Water Dispenser

    • If ice or water dispenses unexpectedly, turn off the water supply and contact an LG Electronics Customer Information Center. • Never use a glass that is exceptionally narrow or deep.

  • Page 5: Detaching The In-Door Ice Bin

    Detaching the In-Door Ice Bin Gently push the handle to close the ice compartment. CAUTION • Only qualified service personnel from LG Automatic Icemaker Electronics service center should disassemble or repair the icemaker. In-Door Icemaker Gently pull the handle to open the ice compartment.

  • Page 6: Storing Food

    OPERATION Storing Food • Ice-making stops when the in-door ice bin is full. When full, the in-door ice bin holds approximately 6 to 8 (12-16 oz.) glasses of ice. Food Storage Tips • Foreign substances or frost on the ice-detecting Wrap or store food in the refrigerator in airtight sensor can interrupt ice production.

  • Page 7: Storing Frozen Food

    32 OPERATION • Non-polyethylene plastic containers Food How to Store • Containers without tight lids Leftovers Cover leftovers with plastic wrap or • Wax paper or wax-coated freezer wrap aluminum foil, or store in plastic • Thin, semi-permeable wrap containers with tight lids. NOTE Storing Frozen Food •...

  • Page 8: Glide'n'serve

    OPERATION • Fruit lets moist air out of the crisper for best To reassemble, insert the cover into the storage of fruit. refrigerator with both hands and lower it onto the guides. Removing/Assembling the Slightly tilt up the front, insert the crisper into Humidity Controlled Crispers the frame and push it back into place.

  • Page 9: Refrigerator Shelves

    34 OPERATION exposed to sudden temperature changes or CAUTION impact. • Do not place any items on the Glide'N'Serve cover. Store taller items, such as a gallon container or bottles, by pushing the front half of the shelf underneath the back half of the shelf. Pull the front of the shelf forward to return to a full shelf.

  • Page 10: Door-In-Door Compartment

    OPERATION Door-in-Door This feature is only available on some models. The Door-in-Door compartment allows for easy access to commonly used food items. To replace the door bins, slide the door bin in The outer Door-In-Door door includes two door above the desired support and push down bins, the Cheese &...
  • Page 11 36 OPERATION Durabase Using the Durabase CAUTION • If the Durabase divider is removed, there is enough open space for children or pets to crawl inside. To prevent accidental child and pet entrapment or suffocation risk, DO NOT allow children or pets to touch or go near the drawer. The Durabase divider allows you to organize the Durabase area into 2 sections.

  • Page 12: Smart Functions

    Internet service provider or refer to your power consumption and the number of door wireless router manual. openings. • LG SmartThinQ is not responsible for any • Remote Control network connection problems or any faults, malfunctions, or errors caused by network - Controls the Refrigerator Temperature, Fresh connection.

  • Page 13: Wireless Lan Module Specifications

    LG SmartThinQ Any changes or modifications in construction of application and register it again. this device which are not expressly approved by •...

  • Page 14: Smart Grid Function

    Load Reduction (TALR) mode. download. LG Electronics will also provide open source code Delay Appliance Load (DAL) to you on CD-ROM for a charge covering the cost The refrigerator responds to a DAL signal by...

  • Page 15: Smart Diagnosis™ Function

    LG Open API You can manage Smart Grid features for the LG Smart Refrigerator. Please check the detailed specifications on the notice page on us.smartthinq.com. API List Open the right refrigerator door.
  • Page 16 SMART FUNCTIONS your conversation with the specialist, who will then be able to assist you in using the information transmitted for analysis. NOTE • For best results, do not move the phone while the tones are being transmitted. • If the call center agent is not able to get an accurate recording of the data, you may be asked to try again.

  • Page 17: Maintenance

    42 MAINTENANCE MAINTENANCE Cleaning water, and rinse with hot water before drying. Do not use abrasive or harsh cleaners. WARNING Inside Walls • Use non-flammable cleaner. Failure to do so can result in fire, explosion, or death. • Allow freezer to warm up so the cloth will not stick.

  • Page 18: Air Filter

    MAINTENANCE Air Filter Replacing the Fresh Air Filter Replace the Fresh Air Filter: • Approximately every six months. • When the Replace Filter icon turns on. Press and hold the Fresh Air Filter button on • Use replacement air filter: LT120F the control panel for 3 seconds to reset the Rotate the filter cover counterclockwise to filter sensor.

  • Page 19: Replacing The Water Filter

    To purchase a replacement water filter: prevent any remaining water from spilling out of • Visit your local dealer or distributor the water filter. • Search using "water filter" on lg.com • Use replacement cartridge: LT1000P, LT1000PC or LT1000PCS CAUTION •...
  • Page 20 MAINTENANCE Close the water filter cover. The cover will click when closed correctly. After the water filter is replaced, dispense 2.5 gallons of water (flush for approximately 5 minutes) to remove trapped air and contaminants from the system. NOTE • Do not dispense the entire 2.5 gallon amount continuously.

  • Page 21: Performance Data Sheet

    46 MAINTENANCE Performance Data Sheet Model: LT1000P, LT1000PC, LT1000PCS NSF System Trade Name Code: MDJ64844601 The concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water leaving the system as specified in NSF/ ANSI Standard 42, Standard 53 and Standard 401.
  • Page 22 NOTE • While the testing was performed under standard laboratory conditions, actual performance may vary. For replacement filters, visit your local dealer or distributor or search under "water filters" on the lg.com website. For further assistance, contact the LG Electronics Customer Information Center.
