Scan to see the online manual.
OWNER'S MANUAL
FRENCH DOOR
REFRIGERATOR
Read this owner's manual thoroughly before operating the
appliance and keep it handy for reference at all times.
ENGLISH
LRYDS3106* / LRYKS3106* / LRYUS3106* / LRYXS3106* / LRYDC2606* /
LRYKC2606* / LRYUC2606* / LRYXC2606* / LRFOC2606* / LRFXC2606* / LCFC26XS*
/ LRFXS3106* / LLFOC2606* / LF31S6360* / LF26C6360* / LF31T6230* /
LL31H6530*
www.lg.com
MFL69497046
Copyright © 2022-2024 LG Electronics Inc. All Rights Reserved.
Rev.04_042224
Advertisement
Table of Contents
Related Manuals for LG LL31H6530 Series
Summary of Contents for LG LL31H6530 Series
- Page 1 LRYDS3106* / LRYKS3106* / LRYUS3106* / LRYXS3106* / LRYDC2606* / LRYKC2606* / LRYUC2606* / LRYXC2606* / LRFOC2606* / LRFXC2606* / LCFC26XS* / LRFXS3106* / LLFOC2606* / LF31S6360* / LF26C6360* / LF31T6230* / LL31H6530* www.lg.com MFL69497046 Copyright © 2022-2024 LG Electronics Inc. All Rights Reserved. Rev.04_042224...
-
Page 2: Table Of Contents
Ice and Water Dispenser In-Door Ice Bin Automatic Icemaker Storing Food Crisper Drawers Glide‘N’Serve Refrigerator Shelves InstaView Door-in-Door Door Bins Durabase 43 SMART FUNCTIONS LG ThinQ Application Smart Grid Function Smart Diagnosis Feature 48 MAINTENANCE Cleaning Air Filter Water Filter 54 TROUBLESHOOTING... -
Page 3: Read All Instructions Before Use
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Safety Messages Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and follow all safety messages. - Page 4 IMPORTANT SAFETY INSTRUCTIONS • Do not bend or pinch the power cord excessively or place heavy objects on it. • When positioning the appliance, ensure the supply cord is not trapped or damaged. • Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance. Operation •...
- Page 5 IMPORTANT SAFETY INSTRUCTIONS • Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer. • Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance. •...
- Page 6 IMPORTANT SAFETY INSTRUCTIONS Risk of Fire and Flammable Materials This symbol alerts you to flammable materials that can ignite and cause a fire if you do not take care. This appliance contains a small amount of isobutane refrigerant (R600a), which is combustible. When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged.
-
Page 7: Product Overview
PRODUCT OVERVIEW PRODUCT OVERVIEW Product Features The images in this guide may be different from the actual components and accessories, which are subject to change by the manufacturer without prior notice for product improvement purposes. Exterior † This feature is only available on some models. Dispenser Control Panel Sets the dispenser mode. - Page 8 PRODUCT OVERVIEW Freezer Frozen food compartment Interior † This feature is only available on some models. Standard Door / InstaView Door Model:...
- Page 9 PRODUCT OVERVIEW Door-in-Door Model: InstaView Door-in-Door Model: LED Interior Lighting Lights up the inside of the refrigerator.
- Page 10 10 PRODUCT OVERVIEW Air Filter Reduces odors inside the refrigerator compartment. In-Door Icemaker (Refrigerator) Automatically produces and stores ice. Door Mullion Prevents the cold air in the refrigerator from escaping when the doors are closed. CAUTION • To reduce the risk of scratching the door or breaking the center door mullion, make sure that the folding door mullion is folded in before closing the left-hand door.
- Page 11 PRODUCT OVERVIEW Durabase and Durabase Divider Provides storage for large frozen food items.
- Page 12 12 PRODUCT OVERVIEW Product Specifications The appearance and specifications listed in this manual may vary due to constant product improvements. Electrical requirements: 115 V, 60 Hz Min. / Max. water pressure: 20 - 120 psi (138 - 827 kPa) Model Description Net weight LRYDS3106*...
-
Page 13: Installation
INSTALLATION INSTALLATION Before Installing Installation Overview Please read the following installation instructions first after purchasing this product or transporting it to another location. Unpacking the Refrigerator Choosing the Proper Location Disassembling/Assembling Connecting the Water Line Leveling and Door Alignment WARNING •... -
Page 14: Choosing The Proper Location
14 INSTALLATION Unpacking the Refrigerator kPa), you can install a booster pump to compensate for the low pressure. WARNING • Use two or more people to move and install the refrigerator. Failure to do so can result in back Electricity injury or other injury. - Page 15 INSTALLATION Dimensions and Clearances • Check the dimensions of the appliance and the installation path to ensure there is sufficient room to move the refrigerator through doors or narrow openings. • If an opening is too narrow to fit the refrigerator through, remove the refrigerator doors. See Removing/ Assembling the Doors and Drawers in this manual.
- Page 16 16 INSTALLATION LRYKS3106* LRYKC2606* Dimension/Clearance LRYXS3106* LRYXC2606* LF31S6360* LF26C6360* Depth without Handle 34 1/4'' (869 mm) 29 1/8” (739 mm) Width 35 3/4'' (908 mm) 35 /34” (908 mm) Height to Top of Case 68 7/8'' (1750 mm) 68 7/8”(1750 mm) Height to Top of Hinge 70 1/4''(1785 mm) 70 1/4''(1785 mm)
-
Page 17: Removing/Assembling Handles
INSTALLATION Removing/Assembling Assembling Refrigerator Handles Handles If needed, reassemble the mounting These instructions are for models which ship with fasteners on the door with a 1/4 in. Allen the handles assembled. For models shipped with wrench. the handles disassembled, follow the instructions included in the handle package. -
Page 18: Removing/Assembling Doors And Drawers
18 INSTALLATION located at the bottom of the front side of the cover Place the handle on the door by fitting the with a flat-head screwdriver. handle footprints over the mounting fasteners and tightening the set screws with a 3/32 in. Allen wrench. •... - Page 19 INSTALLATION Rotate the hinge lever counterclockwise. Lift the top hinge free of the hinge lever latch CAUTION • When lifting the hinge free of the latch, be careful that the door does not fall forward. Rotate the hinge lever clockwise. Lift the top hinge free of the hinge lever latch CAUTION...
- Page 20 20 INSTALLATION WARNING • Be careful of sharp hinges on both sides of the drawer. • When you lay the drawer down, be careful not to damage the floor. • Do not sit or stand on the freezer drawer. • To prevent accidents, keep children and pets away from the drawer.
- Page 21 INSTALLATION Grasp the drawer on each side and hook the drawer supports into the rail tabs located on Replace the ice bin(s) in the drawer. Insert the both sides. Durabase basket in the rail assembly. CAUTION • Do not hold the handle when removing or replacing the drawer.
- Page 22 22 INSTALLATION Fit the hinge over the hinge lever latch Fit the hinge over the hinge lever latch and slot it into place. Rotate the lever and slot it into place. Rotate the lever counterclockwise to secure the hinge. clockwise and fasten the hinge. Connect all the wire harnesses .
-
Page 23: Connecting Refrigerator To Water Supply
INSTALLATION • Wear eye protection during installation to NOTE prevent injury. • Disassembling/Assembling the Water Lines Water Pressure You will need a cold water supply. Water Pressure Collet Tube Insert line Clip • Models with water filter: • Gently press the collet and insert the tube until - 20 - 120 psi (138 - 827 kPa) only one line shows on the tube. - Page 24 24 INSTALLATION it may already have the required fittings at either Compression Nut end. Ferrule (sleeve) Flush out the tubing into a bucket. • Flush out the tubing coming from the home • If your existing copper water line has a flared water supply until the water is clear.
-
Page 25: Leveling And Door Alignment
INSTALLATION may take several more turns, and be sure to ¼ in. Compression Nut turn both leveling legs the same amount. Ferrule (sleeve) Refrigerator Connection Door Alignment The door alignment method may differ depending on the model. Turn the water on at the shutoff valve. •... -
Page 26: Turning On The Power
26 INSTALLATION the height. Turn the nut to the right to raise the • Do not insert the snap ring on the hinge of the door or to the left to lower it. outer door section. Right Refrigerator Door NOTE The right refrigerator door does not have an adjustable nut. -
Page 27: Operation
OPERATION OPERATION Before Use Checklist Clean the refrigerator. Clean the refrigerator thoroughly and wipe off all dust that accumulated during shipping. CAUTION • Do not scratch the refrigerator with a sharp object or use a detergent that contains alcohol, a flammable liquid or an abrasive when removing any tape or adhesive from the refrigerator. -
Page 28: Control Panel
28 OPERATION Control Panel Depending on the model, some of the following functions may not be available. The actual control panel may differ from model to model. Control Panel Features Refrigerator Control Panel † This feature is only available on some models. Type A Type B Type C... - Page 29 OPERATION Type E Refrigerator Indicates the set temperature of the refrigerator compartment in Celsius (°C) or Fahrenheit (°F). The default refrigerator temperature is 37 °F (3 °C). Press the Refrigerator button repeatedly to select a new set temperature from 33 °F to 43 °F (1 °C to 7 °C). NOTE •...
- Page 30 Wi-Fi The Wi-Fi button, when used with the LG ThinQ app, allows the refrigerator to connect to a home Wi-Fi network. Refer to Smart Functions for information on the initial setup of the app. The Wi-Fi indicator shows the status of the refrigerator's network connection. The indicator illuminates when the refrigerator is connected to the Wi-Fi network.
- Page 31 OPERATION NOTE • During operation, the function stops if the Water button is pressed. It resumes automatically after 1 hour. • The function runs automatically for 10 minutes every hour without requiring you to press the Self Care button. • UVnano is a compound word derived from the words UV and its unit, a nanometer. Lock The lock function disables every other button on the display.
-
Page 32: Sabbath Mode
• The dispenser and InstaView are disabled in • If ice or water dispenses unexpectedly, turn off Sabbath mode, on applicable models. the water supply and contact an LG Electronics Customer Information Center. • Never use a glass that is exceptionally narrow or deep. -
Page 33: In-Door Ice Bin
• If discolored ice is dispensed, check the water Before Using the In-Door Ice Bin filter and water supply. If the problem continues, contact an LG Electronics Customer Information The icemaker stops producing ice when the indoor Center. Do not use the water or ice until the ice bin is full. -
Page 34: Automatic Icemaker
34 OPERATION Detaching the In-Door Ice Bin CAUTION • Only qualified service personnel from an LG Electronics service center should disassemble or repair the icemaker. Gently pull the handle to open the ice Gently push the handle to close the ice compartment. - Page 35 OPERATION In-Door Icemaker Freezer Icemaker (Cubed Ice) This feature is only available on some models. Auto Shutoff (feeler arm) Feeler Arm NOTE Before Using the Freezer Icemaker • This automatic freezer icemaker produces 12 This feature is only available on some models. cubes at a time, 50-110 pieces within a 24 hour The feature may vary depending on model period if conditions are favorable.
- Page 36 36 OPERATION • The Craft Ice icemaker produces 1 batch of NOTE round ice (3 pieces) at a time. • Ice cubes which are stored in the ice bin for a • In 3 ICE mode, the Craft Ice icemaker produces long time may clump together and be difficult to 1 batch of round ice (3 pieces) about every 24 separate.
-
Page 37: Storing Food
OPERATION Food Storage Tips • The pad attached to the bottom of the ice bin is designed to reduce the sound of the ice Wrap or store food in the refrigerator in airtight dropping. Do not remove the pad. and moisture-proof material unless otherwise noted. -
Page 38: Crisper Drawers
38 OPERATION • Leftovers have food odor and taste transfer throughout the refrigerator and could also dry out frozen food. - Cover leftovers with plastic wrap or aluminum foil, or store in plastic containers with tight Packaging Recommendations lids. • Rigid plastic containers with tight-fitting lids •... -
Page 39: Glide'n'serve
OPERATION used for large party trays, deli items and beverages. (This drawer should not be used to store vegetables that require high humidity.) Press the Select button to choose between Produce (Cold), Deli (Colder) and Meat (Coldest). Lift the front of the cover up with both hands until it detaches from the back wall of the cabinet, and pull it out. - Page 40 40 OPERATION Adjusting the shelves to fit items of different heights will make finding the exact item you want easier. Using the Folding Shelf This feature is only available on some models. Store taller items, such as a gallon container or bottles, by pushing the front half of the shelf underneath the back half of the shelf.
-
Page 41: Instaview
OPERATION Door-in-Door Compartment To access the Door-in-Door compartment, lightly press the button on the right refrigerator door handle. InstaView This feature is only available on some models. InstaView Compartment Knock twice on the glass to turn the LED light inside the InstaView on or off. The LED light turns off automatically after 10 seconds. -
Page 42: Durabase
42 OPERATION with the rubber drawer stops on the top is toward the inside of the freezer. To assemble the bin, slide it in above the desired support and push down until it snaps into place. CAUTION • Regularly detach and wash the storage bins and shelves;... -
Page 43: Smart Functions
When Ice Plus is finished, you will receive a push message. Run the LG ThinQ application and sign in with • Smart Diagnosis your existing account or create an LG account to sign in. - Page 44 • To reconnect the appliance or add another user, • Reorient or relocate the receiving antenna. press and hold the Wi-Fi button for 3 seconds to temporarily turn it off. Run the LG ThinQ • Increase the separation between the equipment application and follow the instructions in the and the receiver.
-
Page 45: Smart Grid Function
LG Electronics will also provide open source code FCC RF Radiation Exposure to you on CD-ROM for a charge covering the cost Statement... -
Page 46: Smart Diagnosis Tm Feature
46 SMART FUNCTIONS LG Open API according to the signal. The refrigerator will respond to the signals received from the utility You can manage Smart Grid features for the LG company as long as product performance is Smart Refrigerator. maintained. - Page 47 Using Audible Diagnosis to Diagnose Issues Follow the instructions below to use the audible diagnosis method. • Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow the instructions for audible diagnosis provided in the LG ThinQ application.
-
Page 48: Maintenance
48 MAINTENANCE MAINTENANCE Cleaning Proximity Sensor This feature is only available on some models. WARNING A proximity sensor is installed on the bottom of the refrigerator door. The build-up of dust may • Use non-flammable cleaner. Failure to do so can affect the proximity sensor performance. -
Page 49: Air Filter
MAINTENANCE vents. Do not remove the panel covering the Align tabs on the filter cover with hooks condenser coil area. on the refrigerator wall. Rotate the air filter cover clockwise until the Air Filter hooks engage and the cover locks in place. This feature is only available on some models. - Page 50 - Visit your local dealer or distributor gallons of water (flush for approximately 5 minutes) to remove trapped air and - Search using "water filter" on lg.com contaminants from the system. - Use replacement cartridge: LT1000P, LT1000PC, LT1000PCS or ADQ747935** NOTE •...
- Page 51 MAINTENANCE CAUTION • LG strongly recommends that you use LG- authorized water filters to prevent water quality issues, water leakage and appliance malfunction. For further assistance, call: • 1-800-243-0000 (USA) • 1-888-542-2623 (Canada)
- Page 52 52 MAINTENANCE Performance Data Sheet Model: LT1000P, LT1000PC, LT1000PCS NSF System Trade Name Code: MDJ64844601 The concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water leaving the system as specified in NSF/ ANSI Standard 42, Standard 53 and Standard 401.
- Page 53 NOTE • While the testing was performed under standard laboratory conditions, actual performance may vary. For replacement filters, visit your local dealer or distributor or search under "water filters" on the lg.com website. For further assistance, contact the LG Electronics Customer Information Center.
-
Page 54: Troubleshooting
54 TROUBLESHOOTING TROUBLESHOOTING FAQs Frequently Asked Questions What are the best temperature settings for my refrigerator and freezer? The default setting for the refrigerator is 37° Fahrenheit (3° Celsius). The default setting for the freezer is 0° Fahrenheit (-18° Celsius). Adjust these settings as necessary to keep food at desired temperatures. - Page 55 TROUBLESHOOTING Before Calling for Service Review this section before calling for service; doing so will save you both time and money. Cooling Problem Possible Cause & Solution Refrigerator is not The refrigerator control is set to OFF (some models). cooling or has no •...
- Page 56 56 TROUBLESHOOTING Problem Possible Cause & Solution Interior moisture Weather is humid. buildup. • Humid weather allows additional moisture to enter the compartments when the doors are opened leading to condensation or frost. Maintaining a reasonable level of humidity in the home will help to control the amount of moisture that can enter the compartments.
- Page 57 TROUBLESHOOTING Problem Possible Cause & Solution Refrigerator or Unit is installed in a hot location. Freezer section is too • The refrigerator should not be operated in temperatures above 110 °F (43 °C). warm. A large amount of food or hot food was added to either compartment. •...
- Page 58 58 TROUBLESHOOTING Problem Possible Cause & Solution Icemaker is not Reverse osmosis filtration system is used. making enough ice. • Reverse osmosis filtration systems can reduce the water pressure below the minimum amount and result in icemaker issues. (Refer to the Connecting the Water Line section.) Tubing connecting refrigerator to house supply valve is kinked.
- Page 59 TROUBLESHOOTING Problem Possible Cause & Solution Ice has bad taste or The ice storage bin needs to be cleaned. odor. • Empty and wash the bin (discard old cubes). Make sure that the bin is completely dry before reinstalling it. Icemaker is making Icemaker shutoff (arm/ sensor) is obstructed.
- Page 60 60 TROUBLESHOOTING Problem Possible Cause & Solution Water is not New installation or water line recently connected. dispensing. • Dispense 2.5 gallons of water (flush for approximately 5 minutes) to remove trapped air and contaminants from the system. Do not dispense the entire 2.5 gallon amount continuously.
- Page 61 TROUBLESHOOTING Problem Possible Cause & Solution Water has bad taste Refrigerator was recently installed. or odor. • Dispense 2.5 gallons of water (flush for approximately 5 minutes) to remove trapped air and contaminants from the system. Do not dispense the entire 2.5 gallon amount continuously.
- Page 62 62 TROUBLESHOOTING Problem Possible Cause & Solution The interior of the The refrigerator is located near a fire source, such as a fireplace, chimney, or candle. refrigerator is • Make sure that the refrigerator is not located near a fire source, such as a fireplace, covered with dust or chimney or candle.
- Page 63 During Wi-Fi setup, the app is requesting a password to connect to the product (on certain phones). • Locate the network name which starts with "LG" under Settings > Networks. Note the last part of the network name. - If the network name looks like LGE_Appliance_XX-XX-XX, enter lge12345.
- Page 64 Should your LG Refrigerator ("Product") fail due to a defect in materials or workmanship under normal and proper use, during the warranty period set forth below, LG will, at its option, repair or replace the Product. This limited warranty is valid only to the original retail purchaser of the Product ("You") and applies only when purchased lawfully and used within the United States including U.S.
- Page 65 Or by mail: LG Electronics Customer Service P.O. Box 240007 Huntsville, AL 35813 ATTN: CIC PROCEDURE FOR RESOLVING DISPUTES: ALL DISPUTES BETWEEN YOU AND LG ARISING OUT OF OR RELATING IN ANY WAY TO THIS LIMITED WARRANTY OR THE PRODUCT SHALL BE RESOLVED EXCLUSIVELY THROUGH BINDING ARBITRATION, AND NOT IN A COURT OF GENERAL JURISDICTION.
- Page 66 Notice of Dispute. In the event you intend to commence an arbitration proceeding, you must first notify LG in writing at least 30 days in advance of initiating the arbitration by sending a letter to LG at LG Electronics, USA, Inc. Attn: Legal Department- Arbitration 111 Sylvan Avenue, Englewood Cliffs, NJ 07632.
- Page 67 (b) the date on which the product was purchased; (c) the product model name or model number; and (d) the serial number (the serial number can be found (i) on the product; or (ii) online by accessing https:// www.lg.com/us/support/repair-service/schedule-repair-continued and clicking on “Find My Model & Serial Number”).
- Page 68 ARE NOT PERMITTED. PLEASE SEE THE SECTION TITLED “PROCEDURE FOR RESOLVING DISPUTES” BELOW. Should your LG Refrigerator ("Product") fail due to a defect in materials or workmanship under normal and proper use, during the warranty period set forth below, LG Electronics Canada, Inc. ("LGECI") will, at its option, repair, replace or pro rate the Product upon receipt of proof of the original retail purchase.
- Page 69 (ASC), as determined by LG Canada. If your Product is located outside a 150 km radius from a ASC, as determined by LG Canada, it will be your responsibility to bring the Product, at your sole expense, to the ASC for in-warranty repair.
- Page 70 If you and LG are unable to resolve the dispute within 30 days of LG’s receipt of the Notice of Dispute, the dispute shall be resolved by binding arbitration in accordance with the procedure set out herein.
- Page 71 Limited Warranty. Opt Out. You may opt out of this dispute resolution procedure. If you opt out, neither you nor LG can require the other to participate in an arbitration proceeding. To opt out, you must send notice to LG no later than 30 calendar days from the date of the first consumer purchaser’s purchase of the product by...
- Page 72 LG Customer Information Center For inquiries or comments, visit www.lg.com or call: U.S.A. 1-800-243-0000 1-888-542-2623 CANADA Register your product Online! www.lg.com...
