Product Name:
SKU #:
Thank you for purchasing this Luxen Home product. This product has been manufactured with the highest
standards of safety and quality.
PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY.
Unpack all parts from Styrofoam and bubble wrap inside the carton to ensure there are no missing or damaged
parts. If any parts are missing or damaged, do not attempt to assemble or use the product.
CARTON CONTENTS:
Description
Fountain
Pump
Compatible Pumps for this fountain:
Pump Model No.
JR450
JB450
YH707
Tools required for assembly: No tools required for assembly.
Assembly Instructions:
1. Unpack the contents of the box and check to make sure that all items are accounted for and in good
condition.
2. Select a flat, level surface for the assembly and final location of your fountain.
3. Insert the water supply tube into the pump outlet from the opening in the back of the fountain base. Place
the pump upright in the fountain and draw the pump power cord out of the fountain back.
4. Add clean water to the fountain. The water level should be approximately 30mm lower than the edge of the
basin.
5. Connect the power cable to outlet. If installed properly, water flow in the fountain will begin shortly.
6. Please do not use the electrical plug in wet weather conditions. Please note: On first use, there may be air in
the pump. It may take several minutes until all the air escapes.
7. To eliminate the possibility of water damage around your fountain, check for leaks and excessive splashing
after the initial setup of your fountain. It is highly recommended that this fountain be placed in an area
where it cannot be damaged.
8. Do not leave your fountain running for extended periods of time when no one is present to observe the
performance.
9. Check the area around your fountain on a regular basis to ensure that there is no leakage.
10. Please refresh the fountain with water each week to ensure it in good condition.
Resin Cascading Pitchers Outdoor Fountain
WHF609
Quantity
1
1
Contact: sales@winsomehouse.com
Instruction Manual
Please save this manual for future reference.
Advertisement
Table of Contents
Related Manuals for Luxen Home WHF609
Summary of Contents for Luxen Home WHF609
- Page 1 Resin Cascading Pitchers Outdoor Fountain SKU #: WHF609 Thank you for purchasing this Luxen Home product. This product has been manufactured with the highest standards of safety and quality. PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY. Unpack all parts from Styrofoam and bubble wrap inside the carton to ensure there are no missing or damaged parts.
- Page 2 Please save this manual for future reference. Product Name: Resin Cascading Pitchers Outdoor Fountain SKU #: WHF609 11. Do not add any harmful chemicals to the water as it may alter the finish. Note: The above diagram is for illustrative purposes only. Contact: sales@winsomehouse.com...
- Page 3 Instruction Manual Please save this manual for future reference. Product Name: Resin Cascading Pitchers Outdoor Fountain SKU #: WHF609 Pump Instructions: Special Warnings and Cautions: CAUTION: • The pump has been evaluated for use with water only. • Risk of electric shock. Do not remove cord and strain relief. Do not connect conduit to pump.
- Page 4 Product Name: Resin Cascading Pitchers Outdoor Fountain SKU #: WHF609 WARNINGS: 1. To reduce the risk of electric shock, connect only to a properly grounded, grounding type receptacle. 2. To reduce the risk of electric shock, use only on portable self-contained fountains no larger than 5 feet in any dimension.
- Page 5 Product Name: Resin Cascading Pitchers Outdoor Fountain SKU #: WHF609 TIPS AND TROUBLESHOOTING: 1. Ensure that the pump’s flow control switch is set to maximum (+) before operating. Once the flow is established, the pump can be adjusted downward to the desired level.
