Wall Mounted Electric Heater

User instructions - please keep for future reference

Technical information

Power Supply: 220 - 240V ~ 50Hz

Wattage: 650W/1300W/2000W

Element Type: Quartz

Life of Lamp: Approximate maximum 3000 hours

Ingress Protection Rating: IP24

Insulation Class: I

Net Weight: 2Kg

Head Dimensions: H19 x W 49cm

All measurements are approximate

IMPORTANT – Carefully remove any packaging before use, but retain the safety instructions.

These instructions form part of the product.

Please take note of all of the safety warnings listed in these instructions.

Please read these instructions in their entirety and retain them for future reference.

These instructions should be stored with the product.

Produced in China for La Hacienda Ltd

Hangar 27, Site C, Aston Down Airfield, Nr Stroud, Glos, GL6 8HR, UK

Tools required (not included)

www.lahacienda.co.uk

WMQ2000

V1.0

10mm

Table of Contents

Do you have a question about the WMQ2000 and is the answer not in the manual?

Page 1 Please read these instructions in their entirety and retain them for future reference. These instructions should be stored with the product. Produced in China for La Hacienda Ltd Hangar 27, Site C, Aston Down Airfield, Nr Stroud, Glos, GL6 8HR, UK...
Page 2 Care and safe use guidelines IMPORTANT! KEEP FOR FUTURE REFERENCE. Thank you for choosing our indoor/outdoor Electric Heater. This manual will provide you with information necessary for the proper assembly, care and maintenance of your new product. Please take a few moments to thoroughly read the instructions and familiarise yourself with all the operational aspects of your new heater.
Page 3 Parts list 1 (1x) A (1x) B (4x) 2 (1x) C (4x) Prior to assembly; read the instructions carefully. Check all parts against the parts list. This product MUST NOT be used if the power cable is damaged. If there is damage, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
Page 4 Assembly instructions IMPORTANT - Remove any packaging before use, but retain the safety instructions and store them with this product. Please refer to diagram A on page 3 when following the instructions below. ASSEMBLY STEP 1 - Drill 4 holes into a suitably strong exterior wall by positioning the wall bracket (2) a minimum of 2m above the ground and then mark the hole positions using a pencil;...
