Adjustable Electric Heater
User instructions - please keep for future reference
Technical information
Power Supply: 220 - 240V ~ 50Hz
Wattage: 900W/1200W/2100W
Element Type: Halogen
Life of Lamp: Approximate maximum 5000 hours
Ingress Protection Rating: IP44
Net Weight: 13.5Kg
Dimensions: H 160-210 x Diam 58cm
All measurements are approximate
IMPORTANT – Carefully remove any packaging before use, but retain the safety instructions.
These instructions form part of the product.
Please take note of all of the safety warnings listed in these instructions.
Please read these instructions in their entirety and retain them for future reference.
These instructions should be stored with the product.
Produced in China for La Hacienda Ltd
Hangar 27, Site C, Aston Down Airfield, Nr Stroud, Glos, GL6 8HR, UK
Tools list
Tools required (not included)
www.lahacienda.co.uk
GS11
V1.0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for La Hacienda GS11
Summary of Contents for La Hacienda GS11
- Page 1 Please read these instructions in their entirety and retain them for future reference. These instructions should be stored with the product. Produced in China for La Hacienda Ltd Hangar 27, Site C, Aston Down Airfield, Nr Stroud, Glos, GL6 8HR, UK...
- Page 2 Care and safe use guidelines IMPORTANT! KEEP FOR FUTURE REFERENCE. Thank you for choosing our indoor/outdoor Electric Heater. This manual will provide you with information necessary for the proper assembly, care and maintenance of your new product. Please take a few moments to thoroughly read the instructions and familiarise yourself with all the operational aspects of your new heater.
- Page 3 Care and safe use guidelines DO NOT insert or allow foreign objects to enter any ventilation or opening on the heater, as • this may result in electric shock, fire, or damage to the heater. • To prevent a possible fire, DO NOT block the air vents. A heater has hot and arcing or sparking parts inside.
- Page 4 Parts list 1 (1x) 4 (1x) 7 (1x) 9 (1x) Pre-attached to part 1. 10 (1x) 5 (1x) A (2x) 8 (1x) 2 (1x) B (3x) C (4x) 6 (2x) Pre-attached to part 9. D (1x) 3 (1x) Prior to assembly: read the instructions carefully. Check all parts against the parts list. This product MUST NOT be used if the power cable is damaged.
- Page 5 Assembly instructions IMPORTANT - Remove any packaging before use, but retain the safety instructions and store them with this product. Please refer to diagram A on page 3 when following the instructions below. ASSEMBLY STEP 1 - Fix the bottom tube (8) to the base (9) using 3x bolts (B). STEP 2 - Place the pole cover (7) over the bottom tube (8).
