Printer Specifications

Printing
Printing method: Drop on demand 48-nozzle ink jet matrix
Printable columns and printing speed:
Printable
Character pitch
columns
10 cpi
136
12 cpi
163
15 cpi
204
17 cpi (10 cpi condensed)
233
20 cpi (12 cpi condensed)
272
cpi: characters per inch
cps: characters per second
Maximum
360 360 dpi text and graphics
resolution:
Printing
Bidirectional with logic-seeking for text
direction:
and graphics. (The auto print direction can
be set in the default-setting mode.)
Line spacing:
1/6 inch, 1/8 inch, or programmable in
1/360-inch increments
Ink Jet Printers
Printing speed
Printing speed
(Letter Quality)
(Draft)
150 cps
250 cps
180 cps
300 cps
225 cps
375 cps
257 cps
428 cps
300 cps
500 cps
Paper feed speed: 82 milliseconds per 1/6-inch line
2.2 inches/sec. for continuous paper
Input buffer:
64 KB when Mixed text/graphics option
in default-settings mode is set to ON
128 KB when Mixed text/graphics option
in default-settings mode is set to OFF
Internal fonts and character tables
Bitmap fonts:
Font
Draft
EPSON Roman
EPSON Sans Serif
EPSON Courier
EPSON Prestige
EPSON Script
Select other font/pitch combinations using ESC/P 2
commands.
Scalable fonts:
Font
EPSON Roman
EPSON Sans Serif
EPSON Roman T
EPSON Sans Serif H
Character tables: 1 italic and 7 graphics character tables
Character sets:
14 international character sets and
1 legal character set
Paper
Single sheets (paper feeder):
Width
182 to 420 mm (7.2 to 16.5 inches)
Length
182 to 297 mm (7.2 to 11.7 inches)
Thickness
0.065 to 0.11 mm (0.0026 to 0.0043 inches)
Weight
64 to 90 g/m
Quality
Bond paper, plain paper
Single sheets (manual insertion):
Width
182 to 420 mm (7.2 to 16.5 inches)
Length
182 to 420 mm (7.2 to 16.5 inches)
Thickness
0.065 to 0.11 mm (0.0026 to 0.0043 inches)
Weight
52 to 90 g/m
Quality
Bond paper, plain paper
Note:
Use recycled paper under normal temperature and humidity
conditions only. Poor quality paper may reduce print quality, as
well as cause paper jams and other problems. If you encounter
problems, switch to a higher grade of paper.
4/26/94
EPSON STYLUS 1000
10 cpi
12 cpi
15 cpi
Min. pt.
Max. pt.
8
32
8
32
8
32
8
32
2
(18 to 24 lb)
2
(14 to 24 lb)
EPSON STYLUS 1000-1
Proportional
Increments
2 pt
2 pt
2 pt
2 pt
