Quantum Audio QW1000/10D4 User Manual

Recommended Enclosures
sealed
QW1000/10D4
Sealed Enclosure
Box Volume 1.15cu ft.
Ported Enclosure
Box Volume 1.43cu ft.
Box Tuning 39Hz
Port Diameter 4in
Port Length 13in
QW1000/10S4
Sealed Enclosure
Box Volume 1.15cu ft.
Ported Enclosure
Box Volume 1.43cu ft.
Box Tuning 39Hz
Port Diameter 4in
Port Length 13in
QW1000/12D4
Sealed Enclosure
Box Volume 1.25cu ft.
Ported Enclosure
Box Volume 1.5cu ft.
Box Tuning 39Hz
Port Diameter 4in
Port Length 12in
QW1000/12S4
Sealed Enclosure
Box Volume 1.25cu ft.
Ported Enclosure
Box Volume 1.5cu ft.
Box Tuning 39Hz
Port Diameter 4in
Port Length 12in
Please Note: Our suggested box volumes are given as internal air requirements
DB Research L.L.P. • 302 Hanmore Industrial Parkway • Harlingen, TX 78550
ph: 877.787.0101 • fx: 956.421.4513 • www.dbdrive.net • tech Support: support@dbdrive.net
TM
ported
231 mm / 9.09 in
265 mm / 10.43 in
231 mm / 9.09 in
265 mm / 10.43 in
275 mm / 10.82 in
315 mm / 12.40 in
275 mm / 10.82 in
315 mm / 12.40 in
QW1000/10D4 - QW1000/10S4
QW1000/12D4 - QW1000/12S4
USER MANUAL
Installation Instructions | Owners Manual
Due to continuous improvement of the product, specifications are subject to change without notice.
