Summary of Contents for Northern Industrial Tools 998253
- Page 1 4.1 CU. FT. MIXER OWNER’S MANUAL WARNING: Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #998253...
-
Page 2: Intended Use
Thank you very much for choosing a NORTHERN MIXER + EQUIPMENT CO., INC. Product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it. -
Page 3: Work Area
SAVE THESE INSTRUCTIONS WORK AREA Keep work area clean, free of clutter and well lit. Cluttered and dark work areas can cause accidents. Do not use your mixer where there is a risk of causing a fire or an explosion; e.g. in the presence of flammable liquids, gasses, or dust. -
Page 4: Personal Safety
see chart. CHART FOR MINIMUM WIRE SIZE OF EXTENSION CORD: Nameplate AMPS CORD LENGTH 100' 150' 18 AWG 16 AWG 16 AWG 14 AWG 6-10 18 AWG 16 AWG 14 AWG 12 AWG 10-12 16 AWG 16 AWG 14 AWG 12 AWG 12-16 14 AWG... - Page 5 Store idle mixers. When mixers are not is use, store them in a dry, secure place out of the reach of children. Inspect mixers for good working condition prior to storage and before re-use. Maintain your mixers. It is recommended that the general condition of any mixer be examined before it is used.
- Page 6 8. Bend each side of the Pins outward so they do not fall out. 9. With two people, set the Lower Drum (17) with attached Support Arm (13) assembly into Stand assembly. See photo below. 10. Insert Hex Bolts (8) through holes from one side, then Flat Washer (4), Spring Washer (7) and Hex Nut (5) from the other side, and tighten with a wrench.
- Page 7 12. Attach Degree Adjusting Wheel (50) to Iron Tube - R.H. (15) shaft as shown above. a.) Insert Coil Spring (73) into lower hole of Degree Adjusting Wheel (50). b.) Press down on Arm until holes align on the Iron Tube -R.H.(15). c.) Insert the M10x65 Hex.
- Page 8 pointed in the direction of the Drum rotation (clockwise). When correct Mixer (28) position is found, go ahead to fix it. First, put one M8x25 Cross Head Bolt (32) from outside of the drum upper (or lower), and insert one Leather Washer (29) to the Bolt (32) from inside of the Drum. Then, put the Mixer (28) next to the Leather Washer (29) .
-
Page 9: Operation
23. Once the Pulley is pushed in all the way, use an Allen wrench to tighten the Set Screw (70) on the side of the Pulley hub. 24. Install the pulley Belt (68). Place Belt around Motor drive Pulley (54), then over the belt Pulley (45). -
Page 10: Maintenance
Switch Assembly (71) Motor Base Cover 6. Filling and emptying the Drum is best done with the Drum rotating. Warn i n g: Never leave the Cement Mixer running while unattended. Do not turn Mixer Off while full of cement. 7. -
Page 11: Diagram & Parts List
DIAGRAM & PARTS LIST Page of 13... - Page 12 Item Description Item Description Stand Iron Tube Fixture (R.H.) Hinge Bracket Flat Washer Hex. Bolt M8x70 Hex. Nut M10 Flat Washer Spring Washer Hex. Nut M8 Flat Washer Support Bracket Hex Bolt M6x20 Spring Washer Switch Mount Plate Hex. Bolt M8x65 Pulley (L) Hex.
- Page 13 WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • lead from lead-based paints, •...
