Meicheng SP-5028 User Manual

2x8 hdmi 1.3 over single cat5 cascading matrix switcher
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Meicheng
R
SP-5028
2x8 HDMI 1.3 over Single CAT5
Cascading Matrix Switcher
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP-5028 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Meicheng SP-5028

Summary of Contents for Meicheng SP-5028

  • Page 1 Meicheng SP-5028 2x8 HDMI 1.3 over Single CAT5 Cascading Matrix Switcher User Manual...

  • Page 2: Safety And Notice

    However, like all electronic equipments, the SP-5028 should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.
  • Page 3 HDMI 1.3c compliant HDCP compliant HDMI video distribution to up to 7 displays and one CAT5e Receiver or cascade to another SP-5028 Acts as a 2x1 HDMI switch plus a 1x8 HDMI over CAT5 splitter Minimizes the cable skew by adjustable 8-level equalization control...

  • Page 5: Panel Descriptions

    7. RJ-45 IN 1: for cascading from another SP-5028 or SP-5022 8. HDMI IN 2: for connecting to video source, SP-5012, SP-5018, or another SP-5028 9. RJ-45 OUT: for connecting to display through CV-715 or CV-715s; or for cascading to another SP-5022 or SP-5028 10.

  • Page 6: Dip Switch

    If the equipped display shows video but without audio, please try to set audio to 2 channel. Rotary Control In order to adapt the CAT5 cable, SP-5028 offers 8 level equalization control on the received HDMI signal. The strongest equalization is applied while the knob stops at number 0, while the weakest equalization happens at number 7.

  • Page 7: Hardware Installation

    3. Connect all HDMI outputs to the HDMI displays 4. Connect RJ-45 output to HDMI over CAT5 receiver through Cat-5e cable 5. Plug in 5V 4A DC power supply. 6. Power on the SP-5028 7. Power on the HDMI displays. 8. Power on the HDMI source(s).
  • Page 8 Notice 1. If the DVI or HDMI device requires the EDID information, please use EDID Reader/Writer to retrieve and provide DVI/HDMI EDID information. 2. All HDMI over CAT5 transmission distances are measured using Belden CAT5e 125MHz LAN cable and ASTRODESIGN Video Signal Generator VG-859C. 3.

  • Page 9: Limited Warranty

    Limited Warranty The SELLER warrants the SP-5028 2x8 HDMI 1.3 over Single CAT5 Cascading Matrix Switcher to be free from defects in the material and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should this product fail to be in good working order within 1 year warranty period, The SELLER, at its option, repair or replace the unit, provided that the unit has not been subjected to accident, disaster, abuse or any unauthorized modifications including static discharge and power surges.
  • Page 10 Te l : + 8 8 6 ( 2 ) 8 2 2 8 0 3 1 1 , F a x : + 8 8 6 ( 2 ) 8 2 2 8 0 3 1 9 Website : www.meicheng.com.tw Email : mei.cheng@msa.hinet.net...
